1.0 GENERAL SPECIFICATIONS

Electrical requirements:
115 volt model
230 Volt model
Speed:
115 volt model
230 Volt model
Motion
Maximum Capacity
H5500-02
H5500-15
H5500-50
Dimensions WxLxH
Included accessories
Weight
Operating conditions

2.0 INSTALLATION OF THE ROTATOR

2.1 UNPACKING

Before starting the installation, carefully examine the rotator:
Open the box and carefully remove the padding. Check to see that
the rotator has not been damaged during transportation. Keep the
packing material until you are sure the rotator works properly.
Make sure that all of the accessories are included.
Carefully lift the unit from the box.
Be sure that the following information is included on the serial number
located on the bottom of the unit: Serial number, Product number,
Electrical rating.
Check that the power cord has the correct configuration that matches
the outlet according to your local standards.
If any damage occurred during transportation, contact your carrier
immediately.
115V ±10% 50/60Hz, 0.03A
230V ± 10% 50/60Hz, 0.015A
24 rpm
20 rpm
Rotating
36 x 1.5ml or 2.0 ml tubes
10 x 15ml tubes
12 x 5/7ml tubes
6 x 50 ml tubes
21.3 X 10.2 X 12.6 cm
Rotisserie 36 x 1.5ml or 2.0 ml tubes
(H5500-02)
0.8 kg
4ºC to 65ºC, up to 85% RH,
non-condensing
