Removal of Non-Shrouded
Offset Suspensions
1.
Rotate front hook of suspension
toward center of case to disengage.
2.
Pull up to disengage second tab in
front.
3.
Pull suspension forward from the
suspension hook in the rear of the
offset bracket.
4.
Remove offset brackets by sliding
bracket forward (4a) and rotating out
(4b).
1
REAR END OF
SUSPENSION
Top View
4b
2
3
4a
OFFSET
BRACKET
Page 4 of 16
939504872 Rev D
