1

Remove the Cover

1.
Insert a flat screwdriver into
one of the slots on the bottom
of the keypad and gently lift
the screwdriver handle toward
you while pulling the halves
apart. See Figure 2. Repeat
with the other slot.
2.
Using your hands, gently
separate the front from the
base and set the front and
components aside.
Digital Monitoring Products, Inc.

INSTALL THE 7360/7363

|
7360/7363 Installation and Programming Guide
Cover
Base
Figure 2: Removing Cover
3
