Police Emergency
Figure 4: Panic Keys

Internal Speaker Operation

All keypads emit standard tones for key presses, entry delay and system alerts. The
speaker also provides distinct burglary, fire, zone monitor and prewarn cadences. The
keypads provide an alternate prewarn with alarm cadence that occurs when the status list
displays a zone alarm.

Backlighting

On Thinline Icon keypads, both the logo and keyboard light when a key is pressed or the
speaker sounds. During an alarm condition, the keyboard and logo backlight turns Red.
When all alarm conditions are cleared from the display, the Red display turns off and the
lighted areas return to the user-selected brightness.
Digital Monitoring Products, Inc.
Fire
Emergency
| 7360/7363 Installation and Programming Guide
TITLE SELECT KEYS
Panic Left Two Keys
Center Two Keys
Fire Right Two Keys
Table 1: Panic Keys and Zones
ZONE NUMBER
19
29
39
7
