- Page 1 BG-LVPTZ-12XHSURP Full HD PTZ Camera User Manual - 0 -...
- Page 2 Attention Improper operations may damage the product structure and result in mechanical failure. Please note the following tips: Do not move the camera by grabbing the head. Move the camera by holding the bottom with one or both hands. Please do not rotate the lens and holder manually no matter the camera is power on or off;...
- Page 3 This manual introduces functions, installations and operations for this PTZ camera in detail. Please read this manual carefully before installation and use. 1. Cautions 1.1 Avoid damage to product caused by heavy pressure, strong vibration or immersion during transportation, storage and installation. 1.2 Housing of this product is made of organic materials.
-
Page 4: Table Of Contents
Content 1. Camera Installation ............................2 1.1 Camera Introduction ..........................2 1.2 Interfaces and Connection ........................3 1.3 Mounting Brackets ........................... 3 2. Product Overview .............................. 7 2.1 Dimension ..............................7 2.2 Accessories............................... 8 2.3 RS-232 Interface ............................8 2.4 Main Features ............................9 2.5 Specifications ............................ -
Page 5: Camera Installation
1. Camera Installation 1.1 Camera Introduction Figure 1.1 Interface of BG-LVPTZ-12XHSURP 10. 3G-SDI Output Interface Camera Lens 11. USB2.0 Interface (U-disk memory) Camera Base 12. CVBS Output Interface Remote Control Receiving Indicator 13. Audio Input Interface (Line-in) Infrared Receiver 14. RS232 Control Interface (input) Tripod Screw Hole 15. -
Page 6: Interfaces And Connection
1.2 Interfaces and Connection 1) After power on and self-check, the camera will automatically return to the preset 0 position if it’s pre-set. 2) The default address for the IR remote control is 1#. If the menu restored to factory defaults, the remote control default address will restore to 1#. 1.3 Mounting Brackets Notes: Ceiling or wall mounting brackets can only be mounted on template and concrete wall. - Page 7 1) Wall Mounting:...
- Page 9 2) Ceiling Mounting...
-
Page 10: Product Overview
2. Product Overview 2.1 Dimension Figure 2.2 Product Dimension... -
Page 11: Accessories
2.2 Accessories Please check below standard and optional accessories when unpacking the box. Standard Accessory Optional Accessory Power adapter Wireless Remote Control IR Remote Control Ceiling Mount RS232 Cable Wall Mount User Manual 2.3 RS-232 Interface 1) RS-232 Interface Definition Connection to PC or Camera Controller Camera WindowsDB-9... -
Page 12: Main Features
3) RS232 (DB9) Port Definition Definition Port Data Carrier Detect Receive Data Transmit Data Data Terminal Ready System Ground Data Set Ready Request to Send Clear to Send Ring Indicator 4) VISCA networking as shown below: Camera cascade connection Camera 1 Camera 2 1.DTR 1.DTR... -
Page 13: Specifications
Quiet Pan / Tilt Movement: with high accuracy step driving motor, camera can pan / tilt extremely quiet and smooth. Auto sleep function: Auto sleep/wake up function with low power consumption, less than 400mw. Multiple presets: Up to 255 presets (10 presets via remote control). IR / Wireless Remote Control: Users can choose IR remote control or wireless remote control according to different conditions. - Page 14 Power Consumption Maximum: 12W IPC Features Video Encoding Format H.265、H.264 Code Stream Support dual streaming output, main code stream and sub-code stream Main stream：1920×1080、1280×720、640×480 Video Format Sub stream：1920×1080、1280×720、640×480 、640×360 320×240、320×180 Video Bitrates 64Kbps～40960Kbps Audio Compression AAC、MP3、G.711A Format Audio Bitrates 32Kbps、48Kbps、64Kbps、96Kbps、128Kbps TCP/IP、RTSP、RTMP、ONVIF、GB/T28181；...
-
Page 15: Remote Control
3. Remote Control 3.1 Match Code for Wireless Remote Control One-to-One Code Matching: Press the "SET" and "*" keys combined for 3 seconds, LED indicator starts flashing. Camera receives the signal and powers on; LED indicator will go off if code matches successfully. The camera can be controlled by this remote control only after one-to-one code pairing. - Page 16 2. Camera Selection Select the camera address to control. 3. Focus Control Auto: auto focus mode Manual: manual focus mode Focus + (near):Press【FOCUS +】 key (Valid only in manual focus mode) Focus - (far): Press【FOCUS -】 key (Valid only in manual focus mode) Press and hold the keys, the action of focus will keep continue and stop as soon as the key is released.
- Page 17 6. Pan/Tilt Control Up: press Down: press Left: press Right: press Back to middle position: press“【HOME】” Press and hold the up/down/left/right key, the pan/tilt movements will keep running, from slow to fast, until it runs to the endpoint; stop as soon as the key is released. 7.
-
Page 18: Menu Introduction
9. Key Combination 1) 【#】+【#】+【#】: Clear all presets 2) 【*】+【#】+【6】: Restore factory defaults 3) 【*】+【#】+【3】: Menu set to Chinese 4) 【*】+【#】+【4】: Menu set to English 5) 【*】+【#】+【9】: Flip switch 6) 【*】+【#】+Auto: Enter aging mode 7) 【#】+【*】+Auto: Exit aging mode 8) 【*】+【#】+Manual: Restore the default user name, password, and IP address 9) 【#】... -
Page 19: Network Configuration
2). English Menu 4. Network Configuration 4.1 Network Connection Direct connection: Connect the camera and computer by network connecting cable. Internet connection mode: Connect the camera to Internet by Router or Switcher and user can login the device by browser web page. Note: Please do not put the power cable and network cable in places where can be easily touched, to prevent video unstable signal transmission due to poor contact of cables. -
Page 20: Ie Login
To verify whether the network segment has been successfully added, click the “Start” and select “Operation” to input cmd, then click CONFIRM and open DOS command window, ping 192.168.5.26 and press Enter key to display information as shown below: After camera power on and self-check, follow the steps above to verify network connection. Open DOS command window, ping 192.168.5.163 and press Enter key. -
Page 21: Streaming
Chrome login is available after firmware update, but only support basic configuration and preview video, no functions of record video, voice volume, video capture and playback. 2). Download and Install Plug in for IE login If it’s the first time to login via IE browser, the login page will prompt “Playback plug-in is not installed, please download and install!”... -
Page 22: Software Upgrading
2). Push Video Stream Configurations -> Video Configure-> Stream Publish Push RTMP stream to public network server, the stream camera must be on the public network, otherwise it will fail to connect to server. Host address: server address, which can be either a domain name or an IP address Host port: server default port number Stream name: live/test (live/ XXX) Username and password: the username and password set by the server, or leave it empty... -
Page 23: Maintenance And Troubleshooting
3). Click "browse" to select .mrg update file, then click upgrade button to finish software upgrading. 4). Camera reboot after completion of firmware update. It prompts with "successful upgrade". Log in to check the firmware version to make sure software upgrade successful. Then click "restore factory default", reboot and restore parameters to factory default (default IP 192.168.5.163, user name: admin;... - Page 24 b. Whether there is shaking machine or objects around the camera 4) Remote control not works a. Remote control address is set to 1 (if the machine is set back to the factory defaults, remote control addresses need to be back to 1 too) b.
-
Page 25: Warranty
6. Warranty BZBGEAR wants to assure you peace of mind. We're so confident in the quality of our products that along with the manufacturer's one-year limited warranty, we are offering free second-year warranty coverage upon registration*! Taking advantage of this program is simple: 1. -
Page 26: Mission Statement
7. Mission Statement BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind. AV solutions can cost a pretty penny, and new technology only adds to it. We believe everyone deserves to see, hear, and feel the advancements made in today’s AV world without having to break the bank. BZBGEAR is the solution for small to medium-sized applications requiring the latest professional products in AV. -
Page 27: Copyright Statement
8. Copyright Statement All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual contains no guarantee, standpoint expression or other implies in any form. Product specification and information in this manual is for reference only and subject to change without notice.
