BZB Gear BG-EPTZ-UH4K User Manual

All-in-One ePTZ Camera User Manual
1
Camera Interface
①
⑤
No. Description
1 Lens
2 Array Microphone
3 Brackets with Damper
2
Packing Box
ePTZ Camera × 1
USB 3.0 Cable × 1
4K Audio Integrated
②
③
④
⑥
No. Description
4 Product Label
5 USB 3.0 Interface
6 HDMI 2.0 Interface
*
IR Remote Control × 1
User Manual × 1
3
Remote Control Specification
No.
1 Power Key
①
②
2
④
③
⑤
3 Volume Key Speaker volume reduce or
⑦
⑥
4 Speaker
⑧ 5 Mic Mute Key
6 Bluetooth Key
7 Menu Key
⑨
⑩
8
⑫
⑪
9
10 Preset
⑬
11 Focus Key
*
12 Zoom Key
13 Number Key
*NOTE: Features not available on the BG-EPTZ-UH4K.
4
Camera
Video
Sony 1/2.5" CMOS
System
4K@3820*2160
Pixel
Zoom 4X Digital Zoom @1080P
Lens F=2.8mm FOV 130°
White
Auto / Indoor /Outdoor/ ONE PUSH, Manual
Balance
USB Function
Video 4K@30,25fps; 1080p@30,25fps;
Output 1080i@60,50,30,25fps; 720p@60,50fps
Encoding
UVC
Protocol
Video
Audio Function
Built-in
Audio
Voice
Pickup
Range
HDMI Interface
Video 4K@30,25fps; 1080p@30,25fps;
Output 1080i@60,50,30,25fps; 720p@60,50fps
Encoding
Audio
Output
ePTZ Support, 4X Digital Zoom @1080P
USB 3.0
Type B Female
Interface
HDMI 2.0
Key Function
After pressing, the camera
enters standby mode
Answer/
Hang up Key Answer/Hang up the call*
increase*
Mute Key
Enter/Exist Menu
Camera PTZ Press HOME button, the camera
Control Key return to the middle position
Preset Press "Preset"+Number(1-9) to
Setting Key save the corresponding Preset
Press "Reset"+Number(1-9) to
Reset Key reset the corresponding Preset
[AUTO]:Automatic focus
[MANUAL]: Manual focus
[FAR]: Manual focus, make
the far object clearer
[NEAR]: Manual focus, make
the near object clearer
[+ ]means increase
[- ]mean decrease
Cooperate with setting /
calling Preset
Min 0.02Lux @ F1.8,
Illumination AGC ON
Digital Noise
Reduce
Shutter 1/30s ~ 1/10000s
Auto Focus Support
H.265 / H.264 / MJPEG
Support
UVC1.0 - UVC1.5
YES
USB 3.0
8Meters
H.265 / H.264 / MJPEG
N/A
Compatible with all interfaces below
USB3.0, support video, control, power
supply, audio input and output
Compatible with HDMI 2.0, 1.4, 1.3A, 1.3
and other interfaces, only supports video
transmission
*
*
2D, 3D
