Summary of Contents for BZB Gear BG-UPTZ-12XHSU
- Page 1 BG-UPTZ-12XHSU BG-UPTZ-20XHSU BG-UPTZ-30XHSU Full HD PTZ Camera User Manual...
- Page 2 Attention Improper operations may damage the product structure and result in mechanical failure. Please note the following tips: Do not move the camera by grabbing the head. Move the camera by holding the bottom with one or both hands. Please do not rotate the lens and holder manually regardless of camera being powered on or off;...
- Page 3 This manual introduces functionality, proper installation and operations for this PTZ camera in details. Please read this manual carefully before installation and use. 1. Cautions 1.1 Avoid product damage caused by heavy pressure, strong vibration or immersion during transportation, storage and installation.
-
Page 4: Table Of Contents
Content 1. Camera Installation ............................2 1.1 Camera Introduction ..........................2 1.2 Interfaces and Connection ........................3 1.3 Mounting Brackets ........................... 3 2. Product Overview .............................. 7 2.1 Dimensions .............................. 7 2.2 Accessories............................... 8 2.3 RS-232 Interface ............................8 2.5 Rotary DIP Switch ............................ 9 2.6 Main Features ............................ -
Page 5: Camera Installation
1. Camera Installation 1.1 Camera Introduction Figure 1.1 10. Audio Input Interface (Line-in) 1. Camera Lens 11. Rotary DIP Switch 2. Camera Base 12. RS232 Control Interface (input) 3. Remote Control Receiving Indicator 13. RS232 Control Interface (output) 4. Infrared Receiver 14. -
Page 6: Interfaces And Connection
1.2 Interfaces and Connection Figure 1.3 Wiring Diagram 1) After powering on and self-starting, the camera will automatically return to the preset (0) position once it’s pre-set. 2) The default address for the IR remote control is 1#. If restored to factory defaults, note that the remote control default address will be restored to 1#. 1.3 Mounting Brackets Notes: Ceiling or wall mounting brackets should only be installed on sturdy walls rated to support mounted objects. - Page 7 1) Wall Mounting:...
- Page 9 2) Ceiling Mounting...
-
Page 10: Product Overview
2. Product Overview 2.1 Dimensions Figure 2.2 Product Dimension... -
Page 11: Accessories
2.2 Accessories Standard Accessories Optional Accessories Power adapter Ceiling Mount IR Remote Control Wall Mount RS232 Cable User Manual USB3.0 Cable 2.3 RS-232 Interface 1) RS-232 Interface Definition Connection to PC or Camera Controller Camera WindowsDB-9 1.DTR 1.DCD 2.DSR 2.RXD 3.TXD 3.TXD 4.GND... -
Page 12: Rotary Dip Switch
3) RS232 (DB9) Port Definition Definition Port Data Carrier Detect Receive Data Transmit Data Data Terminal Ready System Ground Data Set Ready Request to Send Clear to Send Ring Indicator 4) VISCA networking as shown below: Camera cascade connection Camera 1 Camera 2 1.DTR 1.DTR... -
Page 13: Main Features
2.6 Main Features This model series is packed with functions, superior performance, and rich video output interfaces. Featuring advanced ISP processing algorithms, offering vivid and high-resolution video with a strong sense of depth and fantastic color rendition. It supports H.264/H.265 encoding which makes motion video more fluent and clearer under low bandwidth conditions. - Page 14 USB3.0 interface video format: Main-Stream: YUY2/MJPEG/NV12/H.264/H.265: 1920×1080P30,1280×720P30,1024×576P30,960×540P30,800×448P30,720×480P30,640×360P3 0, 640×480P30,320×176P30 Sub-Stream: YUY2/NV12: 640×360P30,640×480P30,320×176P30 MJPEG/H.264/H.265: 1920×1080P30,1280×720P30, 1024×576P30,960×540P30,800×448P30,720×480P30,640×360P30, 640×480P30,320×176P30 View Angle 60.9°(W) 72.5°(W) 55.8° (W) 65.1°(W) 6.43°(T) 6.3°(T) 3.2°(T) 2.34°(T) F1.6 – F3.0 F1.8 – F2.4 F1.6 – F4.7 F1.5～ F3.0 Digital Zoom Minimum 0.5Lux (F1.8, AGC ON) Illumination...
-
Page 15: Remote Control
TCP/IP, RTSP, RTMP, ONVIF, GB/T28181 Network Protocols Network VISCA control protocol. Supports remote upgrade, reboot and reset USB Communication UVC (Video)，UAC (UAC) PTZ Parameter Pan/Tilt Rotation ±170°, -30°～+90° Pan Control Speed 0.1 - 60°/sec Tilt Control Speed 0.1- 30°/sec Preset Speed Pan: 60°/sec, Tilt: 30°/sec Preset Number 255 presets (10 presets via remote control) -
Page 16: Keys Introduction For Ir Remote Control
Sleep Mode and Wake Up: Press any key to wake up the camera from sleep mode. 3.2 Keys Introduction for IR Remote Control 1). In this manual, “press the key” means a click rather than a long-press, and a special note will be given if a long-press for more than one second is required. - Page 17 Set Preset: press 【SET PRESET】 button, and then press the number key 0-9 to set preset positions. Note: 10 presets via remote control. Call Preset: Press a number key 0-9 directly to call a preset position. Clear Preset: press 【CLEAR PRESET】 button, and then press the number key 0-9 to clear preset positions.
-
Page 18: Menu Introduction
9. Key Combination 1) 【#】+【#】+【#】: Clear all presets 2) 【*】+【#】+【6】: Restore factory defaults 3) 【*】+【#】+【3】: Menu set to Chinese 4) 【*】+【#】+【4】: Menu set to English 5) 【*】+【#】+【9】: Flip switch 6) 【*】+【#】+Auto: Enter aging mode 7) 【#】+【*】+Auto: Exit aging mode 8) 【*】+【#】+Manual: Restore the default username, password, and IP address 9) 【#】... - Page 19 2). Menu Tree...
-
Page 20: Network Configuration
4. Network Configuration 4. Network Connection 4.1 Connection Mode Direct connection: Connect the camera directly to the computer by using an ethernet cable. Internet connection mode: Connect the camera and computer to a router or switch and access via the local area network (LAN). Note: Ensure power and network connections are secured to prevent video issues caused by poor connection quality. -
Page 21: Web Browser Login
For the following steps refer to the diagram below. Click on the bubble for “Use the following IP address” In the IP address field enter a non-conflicting IP address on the same subnet as the camera. If there is another device with the same IP address you will not be able to connect. -
Page 22: Streaming
4.3 Streaming 1). Video Stream Capture Configurations -> Video Configure-> Video Encode Configure the parameters according to the network environment. Note: stream name live/av0 (live/ XXX) For example: The default IP address of the camera is 192.168.5.163. The way to obtain the RTSP video stream is as below rtsp://192.168.5.163:554/live/av0（av0 main stream）... -
Page 23: Serial Port Communication And Control
Push RTMP stream to public network server, the stream camera must be on the public network, otherwise it will fail to connect to server. Host address: server address, which can be either a domain name or an IP address Host port: server default port number Stream name: live/test (live/ XXX) Username and password: the username and password set by the server, or leave it empty Access URL：rtmp://host domain name: host port/live/xxx... -
Page 24: Visca Protocol Control Command
Returned when a command cannot be executed due to Command current conditions. For example, when commands z0 61 41 FF Executable controlling the focus manually are received during auto focus. 5.2 VISCA Protocol Control Command Command Function Command packet Note AddressSet Broadcast 88 30 0p FF... - Page 25 Command Function Command packet Note 8x 01 04 04 02 FF Down 8x 01 04 04 03 FF Direct 8x 01 04 44 00 00 0p 0q FF pq: B Gain Full Auto 8x 01 04 39 00 FF Automatic Exposure mode Manual 8x 01 04 39 03 FF Manual Control mode...
- Page 26 Command Function Command packet Note B&W-Mode 8x 01 04 63 04 FF CAM_Picture effect Picture effect Setting 8x 01 04 63 00 FF Reset 8x 01 04 3F 00 pq FF pq: Memory Number (=0 to 254) CAM_Memory 8x 01 04 3F 01 pq FF Corresponds to 0 to 9 on the Remote Commander Recall...
-
Page 27: Visca Protocol Inquiry Command
5.3 VISCA Protocol Inquiry Command Command Command Packet Return Packet Note y0 50 02 FF CAM_PowerInq 8x 09 04 00 FF y0 50 03 FF Off (Standby) CAM_ZoomPosInq 8x 09 04 47 FF y0 50 0p 0q 0r 0s FF pqrs: Zoom Position y0 50 02 FF Auto Focus... - Page 28 y0 50 04 FF B&W CAM_MemoryInq 8x 09 04 3F FF y0 50 0p FF p: Memory number last operated. y0 50 02 FF SYS_MenuModeInq 8x 09 06 06 FF y0 50 03 FF y0 50 02 FF CAM_LR_ReverseInq 8x 09 04 61 FF y0 50 03 FF y0 50 02 FF CAM_PictureFlipInq...
-
Page 29: Pelco-D Protocol Command List
5.4 Pelco-D protocol command list Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 0xFF Address 0x00 0x08 Pan Speed Tilt Speed Down 0xFF Address 0x00 0x10 Pan Speed Tilt Speed Left 0xFF Address 0x00 0x04 Pan Speed Tilt Speed Right 0xFF Address 0x00... -
Page 30: Maintenance And Troubleshooting
Call Preset 0xA0 Address 0x00 0x07 0x00 Preset ID 0xAF Query Pan Position 0xA0 Address 0x00 0x51 0x00 0x00 0xAF Query Pan Position Response 0xA0 Address 0x00 0x59 Value High Byte Value Low Byte 0xAF Query Tilt Position 0xA0 Address 0x00 0x53 0x00... -
Page 31: Warranty
7. Warranty BZBGEAR wants to assure you peace of mind. All BZBGEAR cameras and camera-related products include our Stress-Free Three-Year Warranty. For complete warranty information, please visit BZBGEAR.com/warranty. For questions, please call 1.888.499.9906 or email support@bzbgear.com. 8. Mission Statement BZBGEAR manifests from the competitive nature of the audiovisual industry to innovate while keeping the customer in mind.
