2.2 Block Diagram

An overview of the EFR32xG21 2.4 GHz 10 dBm with EFP Wireless Starter Kit is shown in the figure below.
Simplicity
Connector
Connector
EXP
Header
User Buttons
& LEDs
silabs.com | Building a more connected world.
RJ-45 Ethernet
Connector
UART
AEM
Packet Trace
Debug
Debug
ETM Trace
GPIO
GPIO
Figure 2.2. Kit Block Diagram
UG422: EFR32xG21 2.4 GHz 10 dBm with EFP Wireless Starter Kit User's Guide
Board
Controller
Multiplexer
EFR32xG21
Wireless SoC
Inverted-F SMA
PCB Antenna Connector
Hardware Overview
USB Mini-B
Connector
EFP0104
I2C
PMIC
Rev. 0.1 | 6
