Si5380 Evaluation Board User's Guide
The Si5380-EVB is used for evaluating the Ultra Low Jitter, Any-
Frequency, 12-output JESD204B Clock Generator. The Si5380
employs 4th generation DSPLL technology to enable clock gen-
eration for LTE/ JESD204B applications which require the high-
est level of jitter performance. The Si5380-EVB has four inde-
pendent input clocks and a total of 12 outputs. The Si5380-EVB
can be easily controlled and configured using Silicon Labs' Clock
Builder Pro™ (CBPro™) software tool.
silabs.com | Smart. Connected. Energy-friendly.
EVB FEATURES
• Powered from USB port or external power
supply
• Onboard 54 MHz XTAL or Reference SMA
Inputs allow holdover mode of operation on
the Si5380
• CBPro™ GUI programmable VDD supply
allows device to operate from 3.3, 2.5, or
1.8 V
• CBPro™ GUI programmable VDDO
supplies allow each of the ten primary
outputs to have its own supply voltage
selectable from 3.3, 2.5, or 1.8 V
• CBPro™ GUI-controlled voltage, current,
and power measurements of VDD and all
VDDO supplies
• Status LEDs for power supplies and
control/status signals of Si5380
• SMA connectors for input clocks, output
clocks and optional external timing
reference clock
Rev. 1.1
