U-Line H-3620 Quick Start Manual

π
H-3620, H-4730
ADHESIVE TRANSFER
TAPE DISPENSER
TOOL NEEDED
Phillips Screwdriver
(optional)
A
Figure 1
1. Depress (A) and lift to open
cover. (See Figure 1)
E
Figure 4
To start application:
4. Place applying roller (E) on
surface, depress trigger and pull
dispenser. (See Figure 4)
PAGE 1 OF 2
1-800-295-5510
uline.com
OPERATION
B
Figure 2
2. Place tape roll on hub, insert
slot (B) in tape core slot.
(See Figure 2)
Figure 5
To end application:
5. Keep roller on surface, release
trigger and pull dispenser to
break adhesive. (See Figure 5)
Figure 3
C
3. Depress trigger and thread tape
leader/liner as shown. Stop end
of leader at point (C). Release
trigger and rotate rewind hub
(D) counter-clockwise to tighten
liner. Close cover. (See Figure 3)
G
Figure 6
Liner tension adjustment:
6. Press down (G) black center
tension adjuster. Turn (H)
clockwise to tighten the tension
of the liner. Turn (I) to loosen.
(See Figure 6)
D
I
H
0914 IH-3620
