- Page 1 INSTALLATION & MAINTENANCE GUIDE Low Voltage Landscape Lighting ® ONE HydroPro LED In-Grade Light ® AWL-710IR-X-BBZ (Dimmable) Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) w w w. a m p l i g h t i n g . c o m...
- Page 2 INSTALLATION & MAINTENANCE GUIDE AMP ONE HydraPro™ LED In-Grade Light AWL-710IR-X-BBZ (Dimmable) Important: Please Read Before Installation This fixture is intended for installation in accordance with local codes and the National Electric Code (NEC). Failure to adhere to these codes and instructions may result in serious injury, property damage and void the warranty.
- Page 3 Package Contents A. (1) Fixture B. (1) Stake Parts Required (sold separately) A. (1) AMP ONE Design-Master ® Remote Control Product Dimensions 4” 2” w w w. a m p l i g h t i n g . c o m –3–...
- Page 4 INSTALLATION & MAINTENANCE GUIDE AMP ONE HydraPro™ LED In-Grade Light AWL-710IR-X-BBZ (Dimmable) Install Stake Board Determine the desired location for mounting the fixture. Hammer the stake into the ground until flange of stake is flush to grade. To avoid damage to the stake, place a board on top of the stake while hammering.
- Page 5 Wire Connection Pigtail Wire Connectors Main Supply Cable Strip both leads from the luminaire pigtail. Using two wire connectors (sold seperately), connect the leads from the luminaire to the main supply cable. w w w. a m p l i g h t i n g . c o m –5–...
- Page 6 Install/Replace Glare Guard Remove Faceplate Loosen the screws and remove the Screw faceplate from the fixture. Faceplate Fixture Install Glare Guard Attach the glare guard onto the Screw fixture and secure it with the screws previously removed. Glare Guard Fixture customersupport@amplighting.com •...
- Page 7 –7–...
- Page 8 Help Hotline: 1-813-978-3900 • Mon-Fri 9am-6pm (EST) Specifications and product details subject to change without notice. © Copyright 2019, AMP Lighting, Lutz FL USA 33549 • All rights reserved. ® customersupport@amplighting.com • 813.978.3900 w w w. a m p l i g h t i n g . c o m is-AWL-710IR-BBZ-ver7.pdf...
