Validity:
● BXT3-13 from series no A/17020001
● BXT3-16 from series no B/17020001
● BXT3-19 from series no C/17020001
Manufacturer
Signode
c/o Signode Industrial Group GmbH
Orgapack Packaging Technology
Silbernstrasse 14
Postfach 595
8953 Dietikon 1, SWITZERLAND
www.sigpse.com
Changes:
Version
Date
V 03.17
16.03.2017 ak/hp
V 07.17
30.06.2017 ak/hp
2 von 37
ENGLISH
Visa
Description
DRAFT
1. Version
Service Manual BXT3-13/16/19
V 07.17
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the BXT3-13 and is the answer not in the manual?
Questions and answers
ERROR CODE E53
Error code E53 for the Signode BXT3-13 indicates that the power transmission from the motor to the cam disk is either completely interrupted or has significant slippage.
This answer is automatically generated
@Mr. Anderson
@Mr. Anderson Can I do something to repair it at the plant?
@Mr. Anderson
@Mr. Anderson What is a fix for an Error 53
Hi we are having problems with the strapper pulling the tape right. It now just keeps spinning and chewing the tape instead of gripping and pulling the tape right. Have pulled it apart and cleaned it out and still does it.
The issue of the Signode BXT3-13 strapper spinning and chewing the tape instead of gripping and pulling it correctly could be caused by:
1. Worn or damaged feed wheel – The feed wheel may not be gripping the strap properly, causing it to slip and get chewed instead of being pulled correctly.
2. Faulty bearing pins (#61) – Loose or misaligned bearing pins can affect the feed wheel's function.
3. Malfunctioning freewheel (#13) – A defective freewheel in the base plate can cause improper tensioning and strap feeding.
4. Bevel wheel with pinion (#12) issues – If this component is worn or damaged, it may prevent proper strap movement and gripping.
Possible solutions include checking and replacing the feed wheel, inspecting the bearing pins for a tight fit, and replacing the freewheel or bevel wheel with pinion if necessary.
This answer is automatically generated
