OVERVIEW
The Infinea TAB allows mobile employees to convert their iPad into a powerful
solution for retail, warehousing, supply chain, ticketing and hospitality
industries. The Infinea TAB includes optional 1D or 2D barcode scanner, 3-track
encrypted magnetic stripe reader, optional Bluetooth support, and RFID.
!
F F e e a a t t u u r r e e s s
: :
Battery:
Rechargeable Li-ion Battery – (700-1100) mAh
Charging via USB to computer
Magnetic Card Reader:
3-Track Head
Swipe Speed: Minimum of 1.97 in/sec
MTBF: 1 million swipes
Barcode Scanner:
Class II - 1D/2D Imager
Single / Multi-scan mode
1D - MTBF: 30K hours (Laser Diode & Mirror Unit 10K hours)
2D - MTBF: 40K hours (Imager & Focus LED)
Indicators:
Visual - 2 LEDs for device status
I/O Connectors:
30-pin plug iPod dock connector
10-pin female Mini-B USB connector for charging and
synchronization
!
