Table 11 8SFF drive cage installation locations
8SFF drive cage
HDD-Cage-8SFF-2U
HDD-Cage-8SFF-2U-NVMe-1
HDD-Cage-8SFF-2U-NVMe-2
HDD-Cage-8SFF-2U-2
HDD-Cage-8SFF-2U-NVMe-3
HDD-Cage-8SFF-2U-3
Procedure
The procedure is the same for installing an 8SFF drive cage in different installation locations. This
section installs a drive cage in drive cage bay 1 for 8SFF SAS/SATA drives.
To install a front 8SFF drive cage:
Power off the server. For more information, see
1.
Remove the server from the rack. For more information, see
2.
Remove the security bezel, if any. For more information, see
3.
Install the front 8SFF drive cage:
4.
a. Remove the drive cage bay blank over the drive cage bay, as shown in
b. Install the drive cage into the server, as shown in
Install drives in the front 8SFF drive cage. For more information, see
5.
drives."
Paste the drive label on the server's front panel above the drive cage bay.
6.
Connect AUX signal cable, data cable, and power cord to the front 8SFF drive backplane. For
7.
more information, see
Install the removed security bezel. For more information, see
8.
Rack-mount the server. For more information, see
9.
10. Connect the power cord. For more information, see
11. Power on the server. For more information, see

Installing an optical drive

Preparing for the installation

Use Table 12
the optical drive.
Table 12 Optical drive installation locations
Optical drive
USB 2.0 optical drive
SATA optical drive
"Front 8SFF SAS/SATA drive
to determine the location of the optical drive you are installing depending on the type of
Installation location
Connect the optical drive to a USB 2.0 or USB 3.0 connector on the server.
IMPORTANT:
Only the 8SFF server supports the SATA optical drive.
Install the optical drive in drive cage bay 1 of the 8SFF server. For the
location of drive cage bay 1, see "Front panel view."
Installation location
Drive cage bay 1 for 8SFF SAS/SATA drives
Drive cage bay 1 for 8SFF NVMe SSDs
Drive cage bay 2 for 8SFF NVMe SSDs
Drive cage bay 2 for 8SFF SAS/SATA drives
Drive cage bay 3 for 8SFF NVMe SSDs
Drive cage bay 3 for 8SFF SAS/SATA drives
"Powering off the
Figure
cabling."
"Rack-mounting the
"Connecting the power
"Powering on the
74
server."
"Removing the server from a
"Replacing the security
Figure
92.
"Installing SAS/SATA
"Installing the security
server."
cord."
server."
rack."
bezel."
90.
bezel."
