Figure 251 Connecting the SATA optical drive cable
Connecting the front I/O component cable
assembly
The front I/O component cable assembly is a two-to-one cable attached to the right chassis ear.
Connect the cable to the front I/O component connector on the system board as shown in
252.
Figure 252 Connecting the front I/O component cable assembly
(1) Front I/O LED cable
(2) USB 3.0 connector cable
192
Figure
