Cash Drawer
1
2
*This jumper is for compatibility with earlier Epson printers. Pins 3-4 are the default
configuration for these jumpers unless ordered.
"
"(
J7 3-4* Pin #
1
2
3
4
5
6
1
2
3
4
5
6
Epson/Axiohm
Frame Ground
Drawer Drive - (Ground)
Status Switch +
Drawer Drive + (24V Switched)
Drawer Drive - (Ground)
No Connect
Status Switch - (Ground)
Frame Ground
No Connect
Drawer Drive - (Ground)
Status Switch +
Drawer Drive + (24V Switched)
Drawer Drive - (Ground)
Status Switch - (Ground)
Appendix
