Subscriber Administration - Avaya Definity G3 / ProLogix Configuration Note

AVAYA DEFINITY G3 / ProLogicx
o For coverage Point1, assign the Hunt Group number created for the
INTUITY ports.

5.5 SUBSCRIBER ADMINISTRATION

o To program subscribers stations for integration, enter
'CHANGE STATION xxxx'. Follow these steps for each telephone:
•
Name: Enter a valid name entry.
•
Coverage Path: Enter the number you previously assigned to the
coverage path for the INTUITY system.
•
LWC Reception? see notes below
•
LWC Activation? n
•
Message Waiting Indicator? y (analog stations only)
•
These are the only changes required for integration. Do not
change any other field.
NOTES:
•
All users stations with message-waiting indicators must be
programmed with:
•
LWC Reception? msa-spe
•
Audible Message Waiting Indicator is supported in conjunction with
lamps only if this optional feature is enabled on the PBX.
6.0 CONFIGURING THE INTUITY
o The following define the steps required on the Intuity
HINT: When changes to the Switch Interface Administration are
completed, a message appears on the screen indicating to restart the
INTUITY voice system. However, this task is not required after each
step. Once ALL changes are completed the system must then be
restarted.
NOTE: The Switch Selection Menu can only be viewed. Changes to the
switch selection menu can be called into the TSO.
•
Switch Selection
Select "Switch Interface Administration" menu
Select "Switch Selection" menu
Administer parameters as follows:
Country: <Press F2 {CHOICES}>.
Switch: Prologix Mode Code
