7 Commissioning

7.1 Inspection before Commissioning

No. Inspection item
1 All cables are intact, well-insulated and the dimension is proper
2 All cables are connected correctly and firmly
The polarity of the power supply cable is correct. The ground
3
cable is reliably grounded

7.2 Commissioning Steps

Tab. 7-1 Commissioning Steps
Step Content
1 Inspection before commissioning
2 Logger3000 is powered on
Connect the debugging PC to the ETH1 port of the
Logger3000 through the network cable (default IP address of
3 ETH1: 192.168.0.100). Log in the Logger3000 through the IE
or GOOGLE browser. The O & M password of the
Logger3000 is adamg1
Make sure the device is firmly connected to the Logger3000
4 and open the device (close the circuit breakers on the two
side of the inverter).
Refer to 8.9.2 Serial Port Settings to set the port that the
e device is located to collection function and set the baud
5
rate, check bit, data bit, and stop bit. The default setting is
9600bps, 8 data bit, 2 stop bit, and no check bit.
Set the devices that connect to the Logger3000 through the
management function. If the devices connected for the first
time is Sungrow string inverter, search the device and
6 allocate address by referring to 8.8.1 Search Device. Other
r devices can connect to the Logger3000 by referring to 8.8.2
Device Operation. For other devices, please preset the
device communication address.
20
