Item Name
st
A 1 navigation menu
nd
B 2 navigation menu
C Function display area
D System time
E User
F Info icon

8.5 WEB Menus

st
The 1 navigation menu includes: Monitoring, Management, Settings, and
Maintenance.
The logic structure of the O & M user menu is shown below.
Description
Display the main function modules of WEB
After selecting the 1
or set the corresponding info through the 2
navigation menu
Display the present selected check or set
function interface
Display the present system time
Display the present login user
：Internet access
：CPU use rate
：memory use rate
：hardware use rate
：total number of online devices
24
st
function module, check
nd
