5 Mechanical Installation

5.1 Unpacking and Inspection

Check the completeness of the delivery content according to the package list on
the crate. The following contents should be within the scope of delivery.
No. Name
A Logger3000
B Documents
Communication
C
terminal resistor
D Network cable
E Antenna
F Hanger
Fastener
G
combination
H OT terminal
I Nylon cable ties
B
A
F
E
I
Fig. 5-1 scope of delivery
Description
-
Quick User Manual, quality certificate, packing list,
product test report, and warranty card.
12x120Ω (note: if there are more than 15 devices
connected to the RS485 bus, it is advisable to
connect a 120Ω terminal resistor in parallel to the A
and B cable on the first and last of the bus).
Length: 1x2m
-
2
Cross-recessed pan-head tapping screw
RNBL5-4
to fix the cable
C
G
10
D
H
