Installation Steps - Dynojet Power Commander III 705-411 Installation Instructions

Unscrew this connector
PCIII
i705-411 www.powercommander.com
Screw the female end of
the PCIII into the harness
Loosen these bolts
Stock harness
PCIII connectors
Stock connector
1 Lift the rear section.
2 Remove the left hand side fair-
ing.
3 Locate the plug that resides in
between the two throttle bodies
(Fig. A). This plug has a round,
silver retaining ring on the end
of it.
4 Unscrew this connector by turn-
ing it counter-clockwise.
Note: You may want to route the wires
for the PCIII from the tail sec-
tion to this area before plugging
it in. This will make for a
cleaner installation.
5 Plug the female connector from
the PCIII into the wiring harness
(Fig. B).
6) Plug the male connector from
the PCIII into the stock female
connector on the bracket
(Fig. C).
1998-2001 Ducati 996 - PCIII USB - 2
