1997-1998 Moto Guzzi Centauro
Parts List
1
Power Commander
1
USB Cable
1
CD-ROM
1
Installation Guide
1
Power Adapter
2
Power Commander Decals
2
Dynojet Decals
1
Velcro
Strip
®
1
Alcohol Swab
The ignition MUST be turned
OFF before installation!
You can also download the Power
Commander software and latest maps
from our web site at:
www.powercommander.com
PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION
Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com
i718-411
Installation Instructions
Button Adjustment Display
Faceplate Buttons
Expansion Port
USB Port
1997-1998 Moto Guzzi Centauro - PCIII USB - 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dynojet Power Commander III 718-411
Summary of Contents for Dynojet Power Commander III 718-411
- Page 1 Commander software and latest maps from our web site at: www.powercommander.com PLEASE READ ALL DIRECTIONS BEFORE STARTING INSTALLATION Dynojet Research 2191 Mendenhall Drive North Las Vegas, NV 89081 (800) 992-4993 www.powercommander.com i718-411 1997-1998 Moto Guzzi Centauro - PCIII USB - 1...
- Page 2 Remove seat assembly. Place the PCIII in the tail section tem- porarily. Stock Connector Route the wiring harness from the PCIII towards each cylinder. Route the harness between the battery and the frame going under the frame rails. NOTE: It does not matter which lead goes to which injector.
- Page 3 Plug the TPS connectors from the PCIII in-line of the stock connectors Stock Connector (Fig. D). PCIII Connectors Ground the wire from the PCIII to the negative side of the battery (Fig. E). Mount the PCIII in one of two places. Either in the tool tray area or between the frame and the battery.
