Pin Signal name
1 FIRSTPORTC Bit 7
2 GND
3 FIRSTPORTC Bit 6
4 GND
5 FIRSTPORTC Bit 5
6 GND
7 FIRSTPORTC Bit 4
8 GND
9 FIRSTPORTC Bit 3
10 GND
11 FIRSTPORTC Bit 2
12 GND
13 FIRSTPORTC Bit 1
14 GND
15 FIRSTPORTC Bit 0
16 GND
17 FIRSTPORTB Bit 7
18 GND
19 FIRSTPORTB Bit 6
20 GND
21 FIRSTPORTB Bit 5
22 GND
23 FIRSTPORTB Bit 4
24 GND
25 FIRSTPORTB Bit 3
26 GND
27 FIRSTPORTB Bit 2
28 GND
29 FIRSTPORTB Bit 1
30 GND
31 FIRSTPORTB Bit 0
32 GND
33 FIRSTPORTA Bit 7
34 GND
35 FIRSTPORTA Bit 6
36 GND
37 FIRSTPORTA Bit 5
38 GND
39 FIRSTPORTA Bit 4
40 GND
41 FIRSTPORTA Bit 3
42 GND
43 FIRSTPORTA Bit 2
44 GND
45 FIRSTPORTA Bit 1
46 GND
47 FIRSTPORTA Bit 0
48 GND
49 +5 V
50 GND
Table 6. Main connector pin out
Pin
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
18
Signal name
SECONDPORTC Bit 7
GND
SECONDPORTC Bit 6
GND
SECONDPORTC Bit 5
GND
SECONDPORTC Bit 4
GND
SECONDPORTC Bit 3
GND
SECONDPORTC Bit 2
GND
SECONDPORTC Bit 1
GND
SECONDPORTC Bit 0
GND
SECONDPORTB Bit 7
GND
SECONDPORTB Bit 6
GND
SECONDPORTB Bit 5
GND
SECONDPORTB Bit 4
GND
SECONDPORTB Bit 3
GND
SECONDPORTB Bit 2
GND
SECONDPORTB Bit 1
GND
SECONDPORTB Bit 0
GND
SECONDPORTA Bit 7
GND
SECONDPORTA Bit 6
GND
SECONDPORTA Bit 5
GND
SECONDPORTA Bit 4
GND
SECONDPORTA Bit 3
GND
SECONDPORTA Bit 2
GND
SECONDPORTA Bit 1
GND
SECONDPORTA Bit 0
GND
+5 V
GND
