AMP Research PowerStep 75101-01A Installation Manual page 5

Note: Steps 1-8 shown on driver side.
Repeat these steps on passenger side.
Counting large oval sill holes from the front,
remove covering (plug or tape) from the
below indicated mounting points.
QUAD CAB: 3rd and 7th from the front.
1
MEGA CAB: 3rd and 8th from the front.
Install rear mounting bracket
TABS REST ON EDGE
3
After drilling apply
paint to prevent
rusting.
5
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
13
Bracket must be flush with the
sidewall before riveting.
1/8"
6
– D O D G E R A M
T M
Prepare brackets for install
3
13
2
Fasten down rear mounting bracket
3
(PULL BACK ON BOLT
WHILE TIGHTENING)
10
4
X2
12
5/12
NOTE FOR MEGA CAB:
Remove tape and cut as
indicated for Mega Cab
rear driver bracket if not
already done.
DRIVER REAR BRACKET SHOWN
TORQUE
16 ft-lbs. (22 N-m)
13
TORQUE
1.5 ft-lbs. (2 N-m)
7
IM75101 rev 01.31.18
10
13 mm
10
3
1/8"
