AMP Research PowerStep 75101-01A Installation Manual page 3

A
F
1
x2
Running board assembly
2
x2
Front Bracket
5
x2
Idler Linkage
www.amp-research.com
A M P R E S E A R C H P O W E R S T E P
(A) End cap left (x1)
(B) End cap right (x1)
(C) T-nut insert (x2)
(D) Socket cap screw (x2)
(E) End cap wedge right (x1)
(F) End cap wedge left (x1)
3
Driver Rear Bracket
6
x2
Motor Linkage
– D O D G E R A M
T M
DRIVER REAR BRACKET
7
Wire Harness
3/12
C
E
D
B
PASSENGER REAR BRACKET
4
Passenger Rear Bracket
8
Controller STA
IM75101 rev 01.31.18
