Technical specifications

General technical specifications
Technical specifications
Transmission speeds supported
Interfaces
Connection to PROFIBUS
•
Maximum current consumption on the PROFIBUS interface
when connecting network components (for example optical
network components)
Supply voltage from backplane bus (rated voltage)
Current consumption
From the S7-400 backplane bus
Power dissipation
Permitted ambient conditions
Operating temperature
•
Transport/storage temperature
•
Relative humidity
•
Operating altitude
•
Degree of protection
Construction
Dimensions W x H x D (mm)
Weight
In addition to this, all the information in the S7-400/M7-400 reference manual "Module Data"
/3/ (Page 42) in the section "General Technical Specifications" on the topics listed below
applies to the CP 443-5 Extended.
● Electromagnetic compatibility
● Transportation/storage conditions
● Mechanical and climatic environmental conditions
● Information on insulation checks, protection class and degree of protection
CP 443-5 Extended
Manual, 11/2018, C79000-G8976-C162-09
Value
9.6 kbps, 19.2 kbps, 45.45 kbps
93.75 kbps, 187.5 kbps, 500 kbps
1.5 Mbps, 3 Mbps, 6 Mbps, 12 Mbps
1 x 9-pin D-sub female connector (RS-485)
100 mA at 5 V
5 V DC
0.6 A typical at 5 V
3 W
0 °C to +60 °C
•
-40 °C to +70 °C
•
maximum 95% at +25 °C
•
up to 2000 m above sea level
IP 20
25 x 290 x 210
Approx. 650 g
