9.1.8. Looper Touch Strip
Looper Touch Strip
This menu item enables you to set the values the Looper will receive and transmit when
touched.
9.1.8.1. MIDI Send/Receive
Use this menu to specify whether the KeyStep Pro's Looper Touch Strip will send MIDI
and react to incoming MIDI messages. The range of transmitted and recognized values is
detailed below in
9.1.8.2. MIDI CC
Use the value field to select the MIDI CC number that the Looper Touch Strip will use to
transmit and receive.
9.1.8.3. Using the Looper Touch Strip with a DAW
When the MIDI Send/Receive parameter is enabled, the activity on the can be recorded into
a DAW. By default, MIDI CC 9 values will be sent, but you can select a different MIDI CC#
as described above.
The Looper Touch Strip will send only the following values:
Looper Touch Strip Region
1/4
1/8
1/16
1/32
release value
However, if you draw a controller curve for the Looper Touch Strip in your DAW, the KeyStep
Pro will respond to the values in the following way:
MIDI CC value received
1-25
26-50
51-75
76-100
124
MIDI Send/Receive
MIDI CC
Using the Looper Touch Strip with a DAW
Values
[OFF (d), Send, Receive, Both]
[1-127], 9 (d)
[p.136].
MIDI CC value
25
50
75
100
0
Looper Touch Strip region selected
1/4
1/8
1/16
1/32
Arturia - User Manual Keystep Pro - KeyStep Pro Configuration
