HySecurity HyNet Gateway SFP 4/1 Installation Manual page 6

HyNet Gateway
Snip off lug and strip
wire. Connect flying
lead to +24VDC
terminal block.
4
RED
TERMINAL
BLOCKS
(+24V) (-24V)
DRIVE
1
2
3
4
5
6
7
8
9
10
11
12
14
15
16
17
18
19
20
21
22
23
24
LED
Tact
LIMIT
button
RPM
Smart Touch Controller
CAUTION
Drawing is not to scale.
6
D0720 Rev. B
BLACK
TERMINAL
BLOCKS
POWER RS485
STOP BUTTON
OPEN BUTTON
CLOSE BUTTON
REMOTE OPEN AND
RADIO CONTROL
OPEN/CLOSE
OPEN PARTIAL
INTERLOCK OPEN
TIME CLOCK OPEN
FREE EXIT DETECTOR
DISABLE EXIT DETECTOR
DISABLE CLOSE TIMER
INSIDE OBSTRUCTION
VEHICLE DETECTOR
OUTSIDE OBSTRUCTION
VEHICLE DETECTOR
SHADOW/RESET
VEHICLE DETECTOR
SENSOR 1
COM
SENSOR COM
NO
DO NOT USE
SENSOR 2
DO NOT USE
STATUS
SENSOR 3
DO NOT USE
CHARGER
AC LOSS
HySecurity
LOCK INTERLOCK
MX000585
VERSION
S/N
EMERG CLOSE
FIRE DEPT OPEN
Smart Touch Controller
DUAL GATE RADIO OPTIONS
S 1
COM A B COM OPEN +24V +24V COM
DO NOT connect to +24V tabs at base of
Smart Touch Controller. Only use the +24V
connections on the power supply terminal
block.
RS-485 ports
Pin 1, COM
RS-485
Connector
RS-485
port
Pin 1, +24V
Installer supplied
shielded cable
HyNet Attachment Kit: MX3868
Connect to RS-485 port on
3
Smart Touch Controller.
NOTE: More detailed wiring information
is shipped with the HyNet.
Wire harness
(supplied in box)
Supply RJ-45 network
connection
HyNet
RS-485 Connector
1
Attach shielded cable
2
to wire harness.*
*Measure distance between
HyNet and Controller
connections for appropriate
shielded cable length.
© 2019 www.hysecurity.com
5
Attach to RS-485
port on HyNet.
