Midea i5 Extra Instruction Manual page 8

13mm
15mm
拖地操作
Mopping operation
1
抹布正贴于抹布支架上。
Attach the mop to the holder.
3
注水。
Fill the water.
15mm
14
13mm
2
按压水箱按键，取出水箱。
Press the button on tank and remove
the tank.
4
将水箱装到抹布支架上。
Mount the water tank onto the mop
holder.
5
再将水箱组件插入到主机上。
Then insert the water tank assembly into
the appliance.
注意 Caution
1. 请勿在地毯上使用抹布组件
2. 抹布支架和抹布必须组合使用
3. 水箱中缺少或清理抹布时，不必抬起机器，直接从后方抽取和安装
4. 拖地完成后，清空水箱
1. Do not use mop tank assembly on the carpet;
2. The mop holder and mop must be used in combination;
3. When the mop is missing or be cleaned in the water tank, it is not necessary to lift the appliance
but extract it directly and install from the rear;
4. After floor is mopped, clear the water tank.
13mm
6
按" "键，开始拖地工作。
Press '' '' and start mopping.
15
13mm
15mm
15mm
