i5 Extra
TEL 400-8899-315
江苏美的清洁电器股份有限公司
地址：苏州市相城经济开发区漕湖大道39号
编码：215000
网址：www.midea.com
版本号：i5 Extra10-06-R2.7
执行标准 : GB4706.7-2014 / GB4706.1-2005 / GB4343.1-2009 / GB17625.1-2012
Jiangsu Midea Cleaning Appliances Co.,Ltd
Address : No.39 Caohu Avenue, Xiangcheng Economic Development Zone, Suzhou
Post : 215000
www.midea.com
Version No. : i5 Extra10-06-R2.7
Executive standard :GB4706.7-2014 / GB4706.1-2005 / GB4343.1-2009 / GB17625.1-2012
02878
PN:161750000
吸尘器
使用说明书
VACUUM CLEANER
INSTRUCTIONS MANUAL
微信扫一扫，服务立马到
使用产品前请仔细阅读本说明书，并请妥善保管
Please keep this instruction Manual carefully,
and read it before operating
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Midea i5 Extra
Summary of Contents for Midea i5 Extra
- Page 1 地址：苏州市相城经济开发区漕湖大道39号 编码：215000 网址：www.midea.com 版本号：i5 Extra10-06-R2.7 执行标准 : GB4706.7-2014 / GB4706.1-2005 / GB4343.1-2009 / GB17625.1-2012 Jiangsu Midea Cleaning Appliances Co.,Ltd Address : No.39 Caohu Avenue, Xiangcheng Economic Development Zone, Suzhou Post : 215000 www.midea.com Version No. : i5 Extra10-06-R2.7 Executive standard :GB4706.7-2014 / GB4706.1-2005 / GB4343.1-2009 / GB17625.1-2012 微信扫一扫，服务立马到...
- Page 2 13mm 13mm 目录 Contents 产品介绍 Product Introduction 方正兰亭中粗黑 14 pt 15mm 15mm Gotham Bold 14 pt 6.4mm 方正兰亭中粗黑 14 pt 蓝色部分：宽6mm 高8mm Gotham Bold 14 pt 白边部分：宽6.8mm 高8.8mm 产品介绍 Product Introduction Product Operation 使用说明 产品介绍页所有箭头面积大致相同 Product Maintenance 维护保养 异常处理 Trouble Shooting Safety Introduction 安全说明...
- Page 3 产品介绍 Product Introduction 主机图解 部件介绍 Illustration of appliance Introduction of components 碰撞板 储尘盒 Bumper 滤网 Dust bin Filter 摄像头 启动/暂停 Camera 海绵 Start / Pause Sponge 面盖 滤网架 Cover Filter holder 水箱 尘盒按键 Water tank Dust bin button 充电座 电源开关 Docking station 尘盒...
- Page 4 13mm 13mm 使用说明 Product Operation 15mm 15mm 主要操作 注意 Caution Main operation 1. 将充电座靠墙边放置，并尽可能放置在空旷位置，充电座周围1.5m范围内无障碍物为佳； 2. 移除地面上的玻璃、陶瓷等易碎品，避免扫地机发生碰撞时损坏物品； 整机充电 3 .移除地面上的电线等杂物，方便扫地机工作更加顺畅； Appliance Charging 4. 移除地面上的插线板，避免扫地机清扫到插线板上时造成触电等安全问题。 放置好充电座：把充电座置于靠墙边位置，并 打开机器面盖内电源滑动开关； 5. 整机运行时有气流高速流动声属于正常现象。 移除充电座周围所有障碍物，如下图所示。 Switch the power on after open 1. Put the docking station against the wall, and place it as far as possible in an open position. It is Put the docking station well：Place the the cover;...
- Page 5 13mm 13mm 15mm 15mm 注意 Caution 重点清扫：在选定区域进行螺旋式清扫； 有效延长电池寿命方法: Spot cleaning: start to cleaning by Spiral mode in certain zone. a. 首次使用请让机器充满12个小时； c. 如果长时间不使用机器,请将电池充满电，然后取出置于通风且干燥的地方； b. 电量不足时，请尽快进行充电； d. 如果机器超过3个月不使用，请用充电器对机器进行一次12小时充电。 沿边清扫：沿障碍物边界进行清扫； Edge cleaning: cleaning by the edge of obstacle. To e ectively extend battery life, you should: a.
- Page 6 Caution 注意 The 1 step: Download Midea Smart Home App; Scan this two-dimension code or search “Midea Smart Home” in Mobile App market and then 若机器处于睡眠状态，按主机“ ”键使机器从睡眠状态切换到暂停状态，再按一次开始清扫。 click its icon to download. If the appliance is in sleep state, press the “...
- Page 7 13mm 13mm 15mm 15mm 添加智能吸尘器 配网操作指引 Add Appliance Operating instructions for network accessing configuration 第一步：添加设备 The 1 step: Add 方式一：扫一扫 点击App主界面“+”按钮，在下拉菜单中点击“扫一扫”，扫描吸尘器正面的产品二维码。 Method Ⅰ: Scan Click “+” key on the main screen of App and select “Scan” from the drop-down menu to scan the product QR code on the front side of the cleaner.
- Page 8 13mm 13mm 15mm 15mm 拖地操作 Mopping operation 抹布正贴于抹布支架上。 按压水箱按键，取出水箱。 再将水箱组件插入到主机上。 按“ ”键，开始拖地工作。 Attach the mop to the holder. Press the button on tank and remove Then insert the water tank assembly into Press ‘‘ ’’ and start mopping. the tank. the appliance.
- Page 9 13mm 13mm Product Maintenance 维护保养 15mm 15mm 边刷清洁 取出海绵; 取出过滤网; Cleaning of side brush Take out the filter; Take out the sponge; 检查边刷是否受损或有异物； Check whether the side brush is damaged or has wrapped; 用清洁工具或抹布清洁边刷； Clean the side brush with a cleaning tool or a rag; 若发生卷曲或变形，可将边刷取下置于温水中约5秒；...
- Page 10 13mm 13mm 15mm 15mm 水箱清洁 擦干水箱并晾干，请勿暴晒。 Water tank cleaning Wipe the water tank and leave it dry. No sunlight exposure is allowed. 拖地完后，从主机尾部抽出水箱组件，拆下抹布支架和抹布； After the floor is mopped, pull out the water tank assembly from the rear of the main unit and remove the mop holder and mop.
- Page 11 13mm 13mm 15mm 15mm 滚刷组件清洁 用清洁工具或软布清洁滚刷棒和滚刷盖板。（滚刷棒可用水洗） Cleaning of brushroll assembly Clean the brushroll bar and brushroll cover with a cleaning tool or a soft cloth. (brushroll can be washed with water) 取下滚刷盖板。 Take the brushroll cover down. 注意 Caution 滚刷棒水洗完将水晾干后再按原拆装顺序返回安装。 向上打开滚刷压块，取出滚刷体。...
- Page 12 13mm 13mm 异常处理 TROUBLE SHOOTING 15mm 15mm In case of mis-function, please refer to the following table. 本品在使用时如发现异常，请先查阅下表。 Problem Possible reason Solution 异常情况 可能原因 处理方法 - The power switch is not turned on - Power on the appliance 充电时未打开电源开关 打开电源开关 The appliance cannot while charging 主机无法充电...
- Page 13 13mm 13mm TROUBLE SHOOTING 异常处理 15mm 15mm In case of mis-function, please refer to the following table. 本品在使用时如发现异常，请先查阅下表。 Problem Cause Troubleshooting Solution 症状 可能原因 故障排除检查 处理方法 - The mobile phone shall be accessed - Judge if the mobile phone 1. 手机网络重连 to network once again;...
- Page 14 China RoHS 中国RoHS 中国RoHS管控物质或元素 中国RoHS管控物质或元素 Substances or elements restricted by China RoHS Substances or elements restricted by China RoHS 零部件名称 Part Name Part Name 零部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 （Pb） （Hg） （Cd） （Cr（VI）...
- Page 15 If others want to use App to operate same cleaner, they just required to be invited on App by the ● ● （如果老用户没有在手机App上删除设备，当新用户配网成功后，此时老用户App上该设备被自动删除。）； family creator to join in (on the condition that the invitee has downloaded Midea Smart Home App and registered for an account); 吸尘器成功配网后，进行以下操作会导致WiFi设置被清除，需要重新配网：在设备上长按“ ”超过3秒，...
- Page 16 SAFETY INSTRUCTIONS 安全说明 SAFETY 安全警告 WARNING Do not place the appliance close to heat sources, radiation, or burning cigarette. 请勿将吸尘器接近热源，辐射或者燃烧的烟头，严禁吸入下列物体: ● ● Do not use the appliance to remove the following objects: 1. 水及溶剂等一切液体； (1) All liquids such as water and solvents. 2.
- Page 17 WARRANTY INFORMATION 保修须知 15mm 15mm Midea appliance strictly comply with government policies . 美的智能吸尘器严格遵照国家“新三包”规定进行保修服务。 Our company provide free maintenance service for the products operated under normal usage. 用户在正常使用产品的情况下，提供相关免费维修服务。 Two-year warranty for household appliance , three-year warranty for motor, three-month warranty for ●...
- Page 18 1. This warranty card should be immediately filled after purchase. 2. Keep this warranty card for your records; it does not need to be returned to Midea. 3. Bring / provide the warranty card and original invoice for service requests.
