rough country 92179211200 Manual

Roof for can-am commander; can-am maverick

Advertisement

Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be
sure you have all needed parts and know where they go.
If question exist, please call us @1-800-222-7023. We will be happy to answer any questions concerning this product.
Check all fasteners for proper torque. Check to ensure for adequate clearance between all components.
Periodically check all hardware for tightness.

KIT CONTENTS:

(2) Roof Sections
(1) 5' H Molding
(2) Edge Assembly Tab
(1) Center Assembly Part
(8) 1/4" x 3/4" Bolts
(8) 1/4" Acorn Nuts
(16) 1/4" Flat Washers
(4) 1/4" x 1" Bolts
(8) 1/4" x 1" Fender Washers
(4) 2" P-Clamp
1. Working from one side to the other slide the H molding on to one of the roof
sections. ( Leave some overhang of the molding on each side to be trimmed
flush with the edge after the roof assembly is complete).
Working from one side to the other slide the second roof half into the H molding. (Make sure to get them tight togeth-
2.
er). See
Photos 2A & 2B.
Can-Am 2011-20 Commander/2013-19 Maverick Roof
Thank you for choosing Rough Country for all your UTV needs.

Installation Instructions

Photo 1
See Photo 1.
Photo 2A
92179211200

TOOLS NEEDED:

1/4" Drill
Drill Motor
7/16" Socket/Wrench
Ratchet
Marker
Knife or Scissors
Photo 2B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 92179211200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for rough country 92179211200

  • Page 1 92179211200 Can-Am 2011-20 Commander/2013-19 Maverick Roof Thank you for choosing Rough Country for all your UTV needs. Please read instructions before beginning installation. Check the kit hardware against the kit contents shown below. Be sure you have all needed parts and know where they go.
  • Page 2 3. Place the assembly part into the roof and transfer the ¼” holes through the roof with the hand drill one at a time put- ting in the ¼”-20 x ¾” bolts with a 1” fender washer on the top of the roof and ¼” washer on the bottom inside the assembly part securing them with the acorn nuts.
  • Page 3 5. Using a knife or scissors cut the H molding off flush with the roof edge. See Photo 9. 6. Place the assembled roof on top of your Commander UTV. See Photo 10. Photo 9 Photo 10 7. Place (2) P-Clamps on the ROPS in the front corners of the roof where you can fit a bolt through with the 1” fender washer on the top of the roof.
  • Page 4 Thank you for choosing Rough Country for all your UTV needs. By purchasing any item sold by Rough Country, LLC, the buyer expressly warrants that he/she is in compliance with all applicable, State, and Local laws and regulations regarding the purchase, ownership, and use of the item. It shall be the buyers responsibility to comply with all Federal, State and Local laws governing the sales of any items listed, illustrated or sold.
