VIPA System SLIO
PS-CM | | Manual
HB300 | PS-CM | | en | 17-16
PS 007-1ABxx, CM 001-1BAxx
www.vipa.com/en/service-support/manual

Advertisement

Table of Contents
loading

Related Manuals for YASKAWA VIPA System SLIO

Summary of Contents for YASKAWA VIPA System SLIO

  • Page 1 VIPA System SLIO PS-CM | | Manual HB300 | PS-CM | | en | 17-16 PS 007-1ABxx, CM 001-1BAxx www.vipa.com/en/service-support/manual...
  • Page 2 VIPA GmbH Ohmstr. 4 91074 Herzogenaurach Telephone: 09132-744-0 Fax: 09132-744-1864 Email: info@vipa.com Internet: www.vipa.com SLIO_PS-CM,3,GB - © 2017...

  • Page 3: Table Of Contents

    VIPA System SLIO Table of contents Table of contents General........................4 1.1 Copyright © VIPA GmbH ................. 4 1.2 About this manual..................... 5 1.2.1 Safety information..................6 Basics and mounting..................... 7 2.1 Safety information for users................7 2.2 System conception................... 8 2.2.1 Overview......................

  • Page 4: General

    VIPA System SLIO General Copyright © VIPA GmbH General 1.1 Copyright © VIPA GmbH All Rights Reserved This document contains proprietary information of VIPA and is not to be disclosed or used except in accordance with applicable agreements. This material is protected by the copyright laws. It may not be reproduced, distributed, or...

  • Page 5: About This Manual

    VIPA System SLIO General About this manual VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany Telefax: +49 9132 744-1204 EMail: documentation@vipa.de Technical support Contact your local VIPA Customer Service Organization representative if you encounter problems with the product or have questions regarding the product. If you are unable to locate a customer service centre, contact VIPA as follows: VIPA GmbH, Ohmstraße 4, 91074 Herzogenaurach, Germany...

  • Page 6: Safety Information

    VIPA System SLIO General About this manual > Safety information 1.2.1 Safety information Applications conforming The system is constructed and produced for: with specifications communication and process control general control and automation tasks industrial applications operation within the environmental conditions specified in the technical data...

  • Page 7: Basics And Mounting

    VIPA System SLIO Basics and mounting Safety information for users Basics and mounting 2.1 Safety information for users Handling of electrostatic VIPA modules make use of highly integrated components in MOS-Technology. These sensitive modules components are extremely sensitive to over-voltages that can occur during electrostatic discharges.

  • Page 8: System Conception

    VIPA System SLIO Basics and mounting System conception > Overview 2.2 System conception 2.2.1 Overview System SLIO is a modular automation system for assembly on a 35mm mounting rail. By means of the peripheral modules with 2, 4 or 8 channels this system may properly be adapted matching to your automation tasks.

  • Page 9: Components

    VIPA System SLIO Basics and mounting System conception > Components 2.2.2 Components CPU (head module) Bus coupler (head module) Line extension Periphery modules Accessories CAUTION! Only modules of VIPA may be combined. A mixed operation with third- party modules is not allowed!
  • Page 10 VIPA System SLIO Basics and mounting System conception > Components CAUTION! Bus interface and power module may not be separated! Here you may only exchange the electronic module! Line extension In the System SLIO there is the possibility to place up to 64 modules in on line. By means of the line extension you can divide this line into several lines.

  • Page 11: Accessories

    VIPA System SLIO Basics and mounting System conception > Accessories Electronic module The functionality of a SLIO periphery module is defined by the electronic module, which is mounted to the terminal module by a sliding mechanism. With an error the defective module may be exchanged for a functional module with standing installation.

  • Page 12: Dimensions

    VIPA System SLIO Basics and mounting Dimensions 2.3 Dimensions Dimensions CPU 01xC Dimensions CPU 01x HB300 | PS-CM | | en | 17-16...
  • Page 13 VIPA System SLIO Basics and mounting Dimensions Dimensions bus coupler and line extension slave Dimensions line extension master HB300 | PS-CM | | en | 17-16...

  • Page 14: Mounting

    VIPA System SLIO Basics and mounting Mounting > Mounting CPU 01x Dimension periphery module Dimensions electronic module Dimensions in mm 2.4 Mounting Requirements for UL compliance use – Use for power supply exclusively SELV/PELV power supplies. – The System SLIO must be installed and operated in a housing according to IEC 61010-1 9.3.2 c).
  • Page 15 VIPA System SLIO Basics and mounting Mounting > Mounting CPU 01x Proceeding Mount the mounting rail! Please consider that a clearance from the middle of the mounting rail of at least 80mm above and 60mm below, respectively 80mm by deployment of shield bus carriers, exist.
  • Page 16 VIPA System SLIO Basics and mounting Mounting > Mounting CPU 01x Mounting periphery modules Before mounting the periphery modules you have to remove the bus cover at the right side of the CPU by pulling it forward. Keep the cover for later mounting.

  • Page 17: Wiring

    VIPA System SLIO Basics and mounting Wiring > Wiring CPU 01x 2.5 Wiring CAUTION! Consider temperature for external cables! Cables may experience temperature increase due to system heat dissi- pation. Thus the cabling specification must be chosen 5°C above ambient...
  • Page 18 VIPA System SLIO Basics and mounting Wiring > Wiring CPU 01x Insert a suited screwdriver at an angel into the square opening as shown. Press and hold the screwdriver in the opposite direction to open the contact spring. Insert the stripped end of wire into the round opening. You can connect wires with a cross section of 0.08mm...
  • Page 19 VIPA System SLIO Basics and mounting Wiring > Wiring CPU 01x PM - Power module For wires with a core cross-section of 0.08mm up to 1.5mm Pos. Function Type Description not connected DC 24V DC 24V for power section supply...

  • Page 20: Wiring Periphery Modules

    VIPA System SLIO Basics and mounting Wiring > Wiring periphery modules Shield attachment Shield bus carrier Shield bus (10mm x 3mm) Shield clamp Cable shield To attach the shield the mounting of shield bus carriers are necessary. The shield bus carrier (available as accessory) serves to carry the shield bus to connect cable shields.
  • Page 21 VIPA System SLIO Basics and mounting Wiring > Wiring periphery modules Wiring procedure Pin number at the connector Opening for screwdriver Connection hole for wire Insert a suited screwdriver at an angel into the square opening as shown. Press and hold the screwdriver in the opposite direction to open the contact spring.

  • Page 22: Wiring Power Modules

    VIPA System SLIO Basics and mounting Wiring > Wiring power modules 2.5.3 Wiring power modules Terminal module terminals Power modules are either integrated to the head module or may be installed between the periphery modules. With power modules, terminals with spring clamp technology are used for wiring.
  • Page 23 VIPA System SLIO Basics and mounting Wiring > Wiring power modules Standard wiring (1) DC 24V for power section supply I/O area (max. 10A) (2) DC 24V for electronic power supply bus coupler and I/O area PM - Power module For wires with a core cross-section of 0.08mm...
  • Page 24 VIPA System SLIO Basics and mounting Wiring > Wiring power modules Fusing The power section supply is to be externally protected with a fuse, which corresponds to the maximum current. This means max. 10A is to be protected with a 10A fuse...
  • Page 25 VIPA System SLIO Basics and mounting Wiring > Wiring power modules Power module 007-1AB10 (1) DC 24V for power section supply I/O area (max. 10A) (2) DC 24V for electronic power supply bus coupler and I/O area (3) DC 24V for power section supply I/O area (max. 4A)

  • Page 26: Demounting

    VIPA System SLIO Basics and mounting Demounting > Demounting CPU 01x Attach the cables with the accordingly stripped cable screen and fix it by the shield clamp with the shield bus. 2.6 Demounting 2.6.1 Demounting CPU 01x Proceeding CAUTION! CPU part and power module may not be separated! Here you may only exchange the electronic module! Power-off your system.
  • Page 27 VIPA System SLIO Basics and mounting Demounting > Demounting CPU 01x Pull the CPU forward. For mounting turn all the locking lever of the CPU to be mounted upwards. To mount the CPU put it to the left periphery module and push it, guided by the stripes, to the mounting rail.

  • Page 28: Demounting Periphery Modules

    VIPA System SLIO Basics and mounting Demounting > Demounting periphery modules 2.6.2 Demounting periphery modules Proceeding Exchange of an electronic Power-off your system. module For the exchange of a electronic module, the electronic module may be pulled for- ward after pressing the unlocking lever at the lower side of the module.
  • Page 29 VIPA System SLIO Basics and mounting Demounting > Demounting periphery modules Pull the module. For mounting turn the locking lever of the module to be mounted upwards. To mount the module put it to the gap between the both modules and push it, guided by the stripes at both sides, to the mounting rail.

  • Page 30: Trouble Shooting - Leds

    VIPA System SLIO Basics and mounting Trouble shooting - LEDs Pull the module group forward. For mounting turn all the locking lever of the module group to be mounted upwards. To mount the module group put it to the gap between the both modules and push it, guided by the stripes at both sides, to the mounting rail.
  • Page 31 VIPA System SLIO Basics and mounting Trouble shooting - LEDs Reason: At this position a module is placed, which does not correspond to the configured module. Remedy: Match configuration and hardware structure. Module failure Behaviour: After PowerON all of the RUN LEDs up to the defective module are flashing.

  • Page 32: Installation Guidelines

    VIPA System SLIO Basics and mounting Installation guidelines 2.8 Installation guidelines General The installation guidelines contain information about the interference free deployment of a PLC system. There is the description of the ways, interference may occur in your PLC, how you can make sure the electromagnetic compatibility (EMC), and how you manage the isolation.
  • Page 33 VIPA System SLIO Basics and mounting Installation guidelines Proof the correct fixing of the lead isolation. – Data lines must be laid isolated. – Analog lines must be laid isolated. When transmitting signals with small ampli- tudes the one sided laying of the isolation may be favourable.

  • Page 34: General Data

    VIPA System SLIO Basics and mounting General data 2.9 General data Conformity and approval Conformity 2014/35/EU Low-voltage directive 2014/30/EU EMC directive Approval Refer to Technical data others RoHS 2011/65/EU Restriction of the use of certain hazardous substances in electrical and electronic equipment...
  • Page 35 VIPA System SLIO Basics and mounting General data Mounting conditions Mounting place In the control cabinet Mounting position Horizontal and vertical Standard Comment Emitted interference EN 61000-6-4 Class A (Industrial area) Noise immunity EN 61000-6-2 Industrial area zone B EN 61000-4-2...

  • Page 36: Power Modules

    VIPA System SLIO Power modules Safety precautions Power modules 3.1 Safety precautions Appropriate use The Power modules were designed and constructed: to be installed on mounting rail along with System SLIO components for installation in a cabinet with sufficient ventilation...

  • Page 37: 007-1Ab00 - Dc 24V 10A

    VIPA System SLIO Power modules 007-1AB00 - DC 24V 10A 3.2 007-1AB00 - DC 24V 10A Properties If the 10A for the power section supply of the I/O area is no longer sufficient, you may use the power module. So you have also the possibility to define isolated groups. The power module is externally to be supplied with DC 24V.
  • Page 38 VIPA System SLIO Power modules 007-1AB00 - DC 24V 10A Pin assignment For wires with a cross section of 0.08mm up to 1.5mm Pos. Function Type Description not connected DC 24V Feed-in DC 24V power section supply Feed-in ground GND...
  • Page 39 VIPA System SLIO Power modules 007-1AB00 - DC 24V 10A Deployment The following figure shows the standard cabling of the power supply by means of a bus coupler. DC 24V for power section supply I/O area (max. 10A) DC 24V for electronic power supply bus coupler and I/O area...

  • Page 40: Technical Data

    VIPA System SLIO Power modules 007-1AB00 - DC 24V 10A > Technical data 3.2.1 Technical data Order no. 007-1AB00 Type PM 007 - Power module Module ID Technical data power supply Input voltage (rated value) DC 24 V Input voltage (permitted range) DC 20.4...28.8 V...
  • Page 41 VIPA System SLIO Power modules 007-1AB00 - DC 24V 10A > Technical data Order no. 007-1AB00 Weight including accessories Gross weight Environmental conditions Operating temperature 0 °C to 60 °C Storage temperature -25 °C to 70 °C Certifications UL certification...

  • Page 42: 007-1Ab10 - Dc 24V 4A, Dc 24V/5V 2A

    VIPA System SLIO Power modules 007-1AB10 - DC 24V 4A, DC 24V/5V 2A 3.3 007-1AB10 - DC 24V 4A, DC 24V/5V 2A Properties If the 3A for the electronic power supply of the I/O area is no longer sufficient, you may use the power module.
  • Page 43 VIPA System SLIO Power modules 007-1AB10 - DC 24V 4A, DC 24V/5V 2A Pin assignment For wires with a cross section of 0.08mm up to 1.5mm Pos. Function Type Description not connected DC 24V Feed-in DC 24V power section supply...
  • Page 44 VIPA System SLIO Power modules 007-1AB10 - DC 24V 4A, DC 24V/5V 2A WARNING! Please consider within wiring the maximum load current of the contacts. With the System SLIO this is max. 10A. Deployment The following figure shows the standard cabling of the power supply by means of a bus coupler.
  • Page 45 VIPA System SLIO Power modules 007-1AB10 - DC 24V 4A, DC 24V/5V 2A Expansion by the power With a sum current greater than 3A the LEDs may not be activated. When the power module 007-1AB10 module 007-1AB10 is placed, further modules may be placed besides the power module at the backplane bus, whose sum current of electronic power supply does not exceed 2A.

  • Page 46: Technical Data

    VIPA System SLIO Power modules 007-1AB10 - DC 24V 4A, DC 24V/5V 2A > Technical data 3.3.1 Technical data Order no. 007-1AB10 Type PM 007 - Power module Module ID Technical data power supply Input voltage (rated value) DC 24 V Input voltage (permitted range) DC 20.4...28.8 V...
  • Page 47 VIPA System SLIO Power modules 007-1AB10 - DC 24V 4A, DC 24V/5V 2A > Technical data Order no. 007-1AB10 Weight including accessories Gross weight Environmental conditions Operating temperature 0 °C to 60 °C Storage temperature -25 °C to 70 °C...

  • Page 48: Clamp Modules

    VIPA System SLIO Clamp modules 001-1BA00 - 8xDC 24V clamps Clamp modules 4.1 001-1BA00 - 8xDC 24V clamps Properties This clamp module is a "potential distributor module". The DC 24V of the power section supply may be accessed by 8 clamp connectors of the terminal. The backplane bus is looped through the module.
  • Page 49 VIPA System SLIO Clamp modules 001-1BA00 - 8xDC 24V clamps Pin assignment For wires with a cross section of 0.08mm up to 1.5mm Pos. Function Type Description DC 24V DC 24V power section supply DC 24V DC 24V power section supply...

  • Page 50: Technical Data

    VIPA System SLIO Clamp modules 001-1BA00 - 8xDC 24V clamps > Technical data 4.1.1 Technical data Order no. 001-1BA00 Type CM 001 - Potential distributor module Module ID Clamp parameter Terminal voltage max. DC 30 V Terminal current max. 10 A Total current per module, max.

  • Page 51: 001-1Ba10 - 8Xdc 0V Clamps

    VIPA System SLIO Clamp modules 001-1BA10 - 8xDC 0V clamps 4.2 001-1BA10 - 8xDC 0V clamps Properties This clamp module is a "potential distributor module". The ground GND of the DC 24V power section supply may be accessed by 8 clamp connectors of the terminal. The back- plane bus is looped through the module.
  • Page 52 VIPA System SLIO Clamp modules 001-1BA10 - 8xDC 0V clamps Pin assignment For wires with a cross section of 0.08mm up to 1.5mm Pos. Function Type Description DC 0V Ground GND power section supply DC 0V Ground GND power section supply...

  • Page 53: Technical Data

    VIPA System SLIO Clamp modules 001-1BA10 - 8xDC 0V clamps > Technical data 4.2.1 Technical data Order no. 001-1BA10 Type CM 001 - Potential distributor module Module ID Clamp parameter Terminal voltage max. DC 0 V Terminal current max. 10 A Total current per module, max.

  • Page 54: 001-1Ba20 - 4Xdc 24V And 4Xdc 0V Clamps

    VIPA System SLIO Clamp modules 001-1BA20 - 4xDC 24V and 4xDC 0V clamps 4.3 001-1BA20 - 4xDC 24V and 4xDC 0V clamps Properties This clamp module is a "potential distributor module". The DC 24V respectively ground GND of the power section supply may be accessed by 4 clamp connectors each of the terminal.
  • Page 55 VIPA System SLIO Clamp modules 001-1BA20 - 4xDC 24V and 4xDC 0V clamps Pin assignment For wires with a cross section of 0.08mm up to 1.5mm Pos. Function Type Description DC 24V DC 24V power section supply DC 24V DC 24V power section supply...

  • Page 56: Technical Data

    VIPA System SLIO Clamp modules 001-1BA20 - 4xDC 24V and 4xDC 0V clamps > Technical data 4.3.1 Technical data Order no. 001-1BA20 Type CM 001 - Potential distributor module Module ID Clamp parameter Terminal voltage max. DC 30 V Terminal current max.
