3.3 Nameplate

Order code

MAC address

Serial number

Date of Production

Fig. 1: Example of nameplate of a R-Series V RH5 sensor with POWERLINK output

•

certified

• EAC certified

• EPSG certified

RP5 (profile sensor):

• Sensor

• Position magnet (not valid for RP5 with design »O«)

• 2 mounting clamps up to 1250 mm (50 in.) stroke length +

1 mounting clamp for each 500 mm (20 in.) additional stroke length

RH5 (rod sensor):

• RH5-B: Base unit (without flange/rod assembly),

3 socket screws M4

• RH5-J/M/S/T: Sensor, O-ring

RH5SA0080U01D561U301

MAC: 00-03-CA-00-58-F6

S/N: 19020950

12JAN2019

I 7 I

R-Series V POWERLINK

Temposonics

Operation Manual
