Level Plus
®
Liquid-Level Sensors
SENS
RS
O
With Temposonics
®
Technology
M-Series Model MR
Analog Transmitter
Document Part Number
551409 Revision A
Brief Operation Manual For Safe Use

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Level Plus M-Series MR and is the answer not in the manual?

Questions and answers

Related Manuals for MTS Systems Level Plus M-Series MR

Summary of Contents for MTS Systems Level Plus M-Series MR

  • Page 1 ® Level Plus ® Liquid-Level Sensors SENS With Temposonics ® Technology M-Series Model MR Analog Transmitter Document Part Number 551409 Revision A Brief Operation Manual For Safe Use...
  • Page 2 Level Plus ® Liquid-Level Sensors - M-Series Model MR Analog Transmitter Brief Operation Manual for Safe Use, Document Number: 551409 Revision A, 04/13 (US) MTS Sensors...

  • Page 3: Contact Information

    Monday - Thursday: 8:00 a.m. to 5:00 p.m. Fax: +1-919-677-2343 Friday: 8:00 a.m. to 4:00 p.m. E-mail: sensorsinfo@mts.com REMITTANCE ADDRESS: http://www.mtssensors.com MTS Systems Corporation MAILING AND SHIPPING ADDRESS: Sensors Division MTS Systems Corporation NW 5872 Sensors Division P.O. Box 1450...

  • Page 4: Table Of Contents

    Model MR Brief Operation Manual for Safe Use Table of Contents Contact information United States .................. i Germany ..................i Japan ....................i Safety Instructions Intended Use ..................1 Installation, commissioning and operation ........1 Special conditions for use in explosion-hazardous areas ....1 Model number identification Model number configuration ............

  • Page 5: Safety Instructions

    Model MR Brief Operation Manual for Safe Use Safety Instructions Safety instructions The Brief Operation Manual for Safe Use contains safety instructions. For further information do consult the Operation and Installation Manual, document no.: 550720, available on the Level Product CD, part no.: 550766 supplied with your level transmitter or cost free download at www.mtssensors.com.

  • Page 6: Model Number Identification

    Model MR Brief Operation Manual for Safe Use Model Number Identification Model number configuration for ATEX approval TRANSMITTER MODEL Magnetostrictive transmitter TYPE Analog output level transmitter INPUT POWER 24 Vdc OUTPUT 4-20 mA Single loop with HART = 4-20 mA Dual loops with HART HOUSING TYPE NEMA Type 4X, 316L stainless steel with blue cable P = NEMA Type 4X, 316L stainless steel with blue cable...

  • Page 7: Marking

    Model MR Brief Operation Manual for Safe Use Model Number Identification, Marking & Entity Parameters LENGTH (Order length based on unit of measurement) 13-17 Rigid or Sanitary transmitter: 508 mm (20 in.) to 7620 mm (300 in.) = Teflon: 508 mm (20 in.) to 6096 mm (240 in.) Flexible transmitter: 3048 mm (120 in.) to 12,192 mm (480 in.) except ATEX IIB max.

  • Page 8: Basic Wiring Is Installation

    Model MR Brief Operation Manual for Safe Use Basic Wiring IS Installation Non Hazardous Area Hazardous Area Certified Safety Barriers 24 Vdc Supply- Transmitter Voltage I (A) 4-20 I.S. Ground connection Figure 1. Safety barrier connections Wiring connections Figure 2. NEMA 4X housing with integrated cable. Loop 1 (+) Loop 2 (+) Loop 1 (–)

  • Page 9: Safety Barrier Examples

    Model MR Brief Operation Manual for Safe Use Basic Wiring, Accessories Loop 1 (–) Loop 2 (–) Loop 1 (+) Loop 2 (+) Earth Ground Figure 4. Dual-cavity housing Safety barrier examples Maximum Maximum current Maximum power Maximum resistance Number of Supplier Type voltage...

  • Page 10: Ec Declaration Of Conformity

    Model MR Brief Operation Manual for Safe Use EC Declaration of Conformity ® Level Plus Liquid-Level Sensors - M-Series Model MR Analog Transmitter Brief Operation Manual for Safe Use, Document Number: 551409 Revision A, 04/13 (US) MTS Sensors...
  • Page 11 Level Plus ® Liquid-Level Sensors - M-Series Model MR Analog Transmitter MTS Sensors Brief Operation Manual for Safe Use, Document Number: 551409 Revision A, 04/13 (US)

  • Page 12: Auf Dem Schüffel

    Document Part Number: 551409 Revision A, 04/13 (US) MTS, Temposonics and Level Plus are registered trademarks of MTS Systems Corporation. All other trademarks are the property of their respective owners. Printed in USA. Copyright © 2013 MTS Systems Corporation. All Rights Reserved in all media.
