3.2 Order code of Temposonics
1 2 3 4 5
R H 5
a b c
a Sensor model
R H 5 Rod
b Design
B Base unit (only for replacement)
J Threaded fl ange M22×1.5-6g (rod Ø 12.7 mm)
M Threaded fl ange M18×1.5-6g (standard)
S Threaded fl ange ¾"×16 UNF-3A (standard)
T Threaded fl ange ¾"×16 UNF-3A (with raised-face)
c Mechanical options
A Standard
B Bushing on rod end (only for design »M«, »S« & »T«)
M Thread M4 at rod end (only for design »M«, »S« & »T«)
V Fluorelastomer seals for the sensor electronics housing
d Stroke length
X X X X M 0025...7620 mm
Standard stroke length (mm)
25... 500 mm
500... 750 mm
750...1000 mm
1000...2500 mm
2500...5000 mm
5000...7620 mm
X X X . X U 001.0...300.0 mm
Standard stroke length (in.)
1... 20 in.
20... 30 in.
30... 40 in.
40...100 in.
100...200 in.
200...300 in.
Non-standard stroke lengths are available;
must be encoded in 5 mm / 0.1 in. increments
e Number of magnets
X X 01...30 position(s) (1...30 magnet(s))
RH5
®
6 7 8 9 10 11 12
d e
Ordering steps
5 mm
10 mm
25 mm
50 mm
100 mm
250 mm
Ordering steps
0.2 in.
0.4 in.
1.0 in.
2.0 in.
4.0 in.
10.0 in.
13 14 15 16 17
D 5 6 1 U
f g
f Connection type
6 2 × M12 female connectors (5 pin),
D 5
1 × M8 male connector (4 pin)
g System
1 Standard
h Output
1 POWERLINK, position and velocity
U 3 0
(1...30 position(s))
1 POWERLINK, position and velocity,
U 3 1
internal linearization (1...30 position(s))
NOTICE
• Specify magnet numbers for your sensing application and
order separately.
• The number of magnets is limited by the stroke length.
The minimum allowed distance between magnets (i.e. front face
of one to the front face of the next one) is 75 mm (3 in.).
• Use magnets of the same type for multi-position measurement,
e.g. 2 × U-magnet (part no. 251 416-2).
• If the option for internal linearization (U311) in
chosen, select a suitable magnet.
I 6 I
18 19 20
3 1
h
h
"Output" is
