Labels & Cosmetics - Grizzly G0890 Owner's Manual

312
G0890
G0891
311
310
grizzly.com
REF PART # DESCRIPTION
301 P0890301 DISCONNECT POWER LABEL
302 P0890302 MACHINE ID LABEL (G0890)
302 P0891302 MACHINE ID LABEL (G0891)
303 P0890303 READ MANUAL LABEL
304 P0890304 ADD OIL LABEL
305 P0890305 STOP OIL FILL TAG
306 P0890306 ELECTRICITY LABEL
307 P0890307 TOUCH-UP PAINT, GRIZZLY GREEN
Safety labels help reduce the risk of serious injury caused by machine hazards. If any label comes
off or becomes unreadable, the owner of this machine MUST replace it in the original location
before resuming operations. For replacements, contact (800) 523-4777 or www.grizzly.com.
BUY PARTS ONLINE AT GRIZZLY.COM!
-56-
Scan QR code to visit our Parts Store.
Labels & Cosmetics
Specifications WARNING!
Motor: 3 HP, 230V, 1-Ph, 60 Hz, 12A To reduce the risk of serious injury when using this machine:
Cutterhead: 4 Spirals, 48 Inserts 1. Read and understand owner's manual before operating.
Insert Size: 15 x 15 x 2.5mm 2. Always wear approved safety glasses and respirator.
Replacement Inserts: H9893 3. Disconnect power before changing inserts, removing
Cutterhead Speed: 5200 RPM parts, or doing maintenance, service, or adjustments.
Feed Rates: 16, 28 FPM 4. Only plug power cord into a grounded outlet.
Max. Depth of Cut: 1/8"
5. Do not wear loose clothing, gloves, jewelry, or other items
Min. Stock Thickness: 3/16" that can get entangled. Tie back long hair and roll up sleeves.
Min. Stock Length: 6" 6. Ensure machine is correctly set up before starting.
Max. Cutting Width: 15"
7. Do not plane two boards of varying thickness at same time.
Max. Cutting Height: 6" 8. Never plane material smaller than 6" long or
Weight: 302 lbs. 302
9. Keep fingers clear of pinch point between stock and table.
175370
10. Stand clear of board ends during cutting operation.
11. Inserts are sharp! Use extreme caution when servicing.
12. Never reach into cutting area while machine is running.
13. Do not expose to rain or use in damp or wet locations.
14. Prevent unauthorized use by children or untrained users.
301
Specifications WARNING!
Motor: 3 HP, 230V, 1-Ph, 60 Hz, 12A To reduce the risk of serious injury when using this machine:
Cutterhead: 3 Knife, 2-5/8" Dia. 1. Read and understand owner's manual before operating.
Knife Size: 15" x 1" x 1/8" 2. Always wear approved safety glasses and respirator.
Replacement Knives: G6701 3. Disconnect power before changing blades, removing
Cutterhead Speed: 5200 RPM parts, or doing maintenance, service, or adjustments.
Feed Rates: 16, 28 FPM 4. Only plug power cord into a grounded outlet.
Max. Depth of Cut: 1/8" 5. Do not wear loose clothing, gloves, jewelry, or other items
Min. Stock Thickness: 3/16" that can get entangled. Tie back long hair and roll up sleeves.
Min. Stock Length: 6" 6. Ensure machine is correctly set up before starting.
Max. Cutting Width: 15" 7. Do not plane two boards of varying thickness at same time.
Max. Cutting Height: 6" 8. Never plane material smaller than 6" long or
Weight: 300 lbs. 9. Keep fingers clear of pinch point between stock and table.
175370
1 . 0 S a t n d c e l r a f o b o a d r e n d s
1 . 1 K n v i e s a e r s h r a ! p U s e e t x
12. Never reach into cutting area while machine is running.
1 . 3 D o n t o e x p o s e o t a r n i r o u
14. Prevent unauthorized use by children or untrained users.
313
/ 3 " thick.
16
303
To reduce risk of death
or serious injury, read
manual BEFORE using
machine.
To get a new manual, call
(800) 523-4777 or go to
/ 3 " thick. www.grizzly.com.
16
d r u n i g c u t t n i g o p r e t a o i . n
e r m e c a t u o i n w h e n s e v r c i n i . g
s e n i d a m p r o w t e o l c t a o i n . s
305
CHECK OIL
LEVEL BEFORE USING!
REFER TO
OWNER'S MANUAL
FOR OIL TYPE AND
AMOUNT.
306
307
308
INJURY HAZARD!
To reduce the risk of serious personal
injury, do not remove this cover while the
machine is running or connected to power.
Always disconnect power before servicing.
INJURY HAZARD! EYE/EAR/LUNG
To reduce risk of short INJURY HAZARD!
and long-term injury,
Always wear safety
wear safety glasses,
glasses, ear protection,
hearing protection, and
a respirator when using and respirator when
using this machine.
this machine.
REF PART #
308 P0890308
309 P0890309
310 P0890310
311 P0890311
312 P0890312
312 P0891312
313 P0890313
304
NOTICE
Add SAE 30 oil every 24 hours of operation.
309
WARNING! WARNING!
DESCRIPTION
INJURY HAZARD LABEL
EYE/EAR/LUNG LABEL
GRIZZLY.COM LABEL
GRIZZLY NAMEPLATE–LARGE
MODEL NUMBER LABEL (G0890)
MODEL NUMBER LABEL (G0891)
TOUCH-UP PAINT, GRIZZLY BEIGE
G0890/G0891 (Mfd. Since 06/19)
