MODEL G0889/G0889Z
13" BENCHTOP PLANER
OWNER'S MANUAL
(For models manufactured since 12/18)
5012917
COPYRIGHT © DECEMBER, 2018 BY GRIZZLY INDUSTRIAL, INC. REVISED APRIL, 2019 (BL)
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
#JL20134 PRINTED IN TAIWAN
V2.04.19
