Adjusting the Camera angle
Panning 360º
Tilting 75º
Warning:
- Do not rotate more than 360 ˚
- Do not twist the camera's bracket too
many times.
Adjusting the camera angle
Adjust the camera angle while the camera is
fixed on the ceiling. Pan is used to rotate the
camera's body to left and right, and Tilt is
used to adjust the tilt. Rotating the lens by
its axis is called Rotation.
Rotation 350º
- Panning: 360°
- Rotation: 350°
- Tilting: 75°
Adjusting the camera lens
1. Remove the camera's dome by pressing
on the sides of the camera body.
2. Use the joystick on the base of the
camera to adjust the zoom and focus.
16
a. Up: zoom in
b. Down: zoom out
c. Left: near
d. Right: far
