Digital Watchdog Star-Light Plus DWC-D4583WTIR User Manual page 26

OSD Menu_Motion (cont.)
The camera can detect movement and display an alarm on the screen when movement is detected.
DET WINDOW
SENSITIVITY
MOTION OSD
TEXT ALARM
4
SIGNAL OUT
5
RETURN
Text alarm
4
Setup a text to appear on the screen when motion is detected.
- Window motion:
- Camera moving:
- Bright change:
5
Signal out (off, on)
- Off:
- On:
MOTION
MOTI
5
OFF
OFF
ON
Will appear when a motion alarm is detected in the set motion window.
Will appear if the camera is shaken abruptly.
Will appear if the camera detects sudden changes in brightness.
Signal output is disable regardless of motion detection.
Signal output will be activated when motion is detection in the motion window.
26
DET WINDOW
WINDOW USE 0
WINDOW ZONE ON
DET H-POS 1
DET V-POS 1
DET H-SIZE 77
DET V-SIZE 58
RETURN
