Parts Names

Vent
Mic connector
Lens
Cables:
Audio, UTP, RS485, alarm
Mic
BNC cable
Power cable
RS 485
BK D+
WH D-
UTP
ALARM
BLUE +
WHITE -
Test video cable slot
10
Dome cover
Tilt stopper screw
Joystick
