OSD Menu_Privacy (cont.)
You can hide some parts of the camera's view to protect privacy and sensitive data. A total of 24
privacy masking zones are available, including 16 square zones and 8 polygon shaped zones.
Polygon
2
- Zone num: Select the zone number between 0~7.
- Zone disp: Select to show or hide the selected zone.
- POS0-X: Move the zone's upper left angle left and right.
- POS0-Y: Move the zone's upper left angle up and down.
- POS1-X: Move the zone's upper right angle left and right.
- POS1-Y: Move the zone's upper right angle up and down.
- POS2-X: Move the zone's lower right angle left and right.
- POS2-Y: Move the zone's lower right angle up and down.
- POS3-X: Move the zone's lower left angle left and right.
- POS3-Y: Move the zone's lower left angle up and down.
- Y level: The higher the number, the brighter the color of the zone will appear.
- CR level: The higher the number, the more red tone will be added to the zone's color.
The lower the number, the more green will be added to the zone's color.
- CB level: The higher the number, the more red tone will be added to the zone's color.
The lower the number, the more red will be added to the zone's color.
- Trans: Set the mask's transparency level from 0~3. The default value is 2.
PRIVACY
PRIV
BOX OFF
POLYGON ON
RETURN
28
POLYGON
ZONE NUM 0
ZONE DISP ON
POS0-X 80
POS0-Y 5
POS1-X 88
POS1-Y 5
POS2-X 88
POS2-Y 13
POS3-X 80
POS3-Y 13
Y LEVEL 10
CB LEVEL 10
CR LEVEL 10
TRANS 2
