OSD Menu_Setup

SETUP
SET
1
2
COMM
OUTPUT
LANGUAGE
CAM TITLE
RESET
RETURN
COMM
1
Adjust the camera's ID and baudrate. The camera's default protocol is Pelco-D.
- Cam ID:
- Baudrate:
- Confirm:
NOTE: Set confirm to "on" after setting the camera's ID and baudrate. Be sure to press
"Save&Exit" button on the EXIT Menu.
Output
2
- Framerate:
- FREQ:
- Analog mode:
- Confirm:
NOTE :
Set confirm to "on" after setting the camera's output values.
Be sure to press "Save&Exit" button on the EXIT Menu.
CAM ID
BAUDRATE
CONFIRM
RETURN
ENG
OFF
OFF
Provide an ID number for the camera (0 ~ 255).
Select the baudrate from the following options: 2400, 4800, 9600 (default),
57600 and 115200 bps.
Off, on
Set the camera's display frame rate and resolution. Select from:
5MP/1944p_20 (HD-A/HD-T only), 4MP/1440_30P,
2.1MP/1080p_30, 720p_30.
When the camera's image appears flickering, you can change its frequency
to adjust the image. Select from 60HZ and 50HZ.
Set the camera's video signal output:
HD-A: HD-Analog (supports up to 5MP @ 20fps)
HD-T: HD-TVI (supports up to 5MP @ 20fps)
HD-C: HD-CVI (supports up to 4MP @ 30fps)
CVBS (supports up to 960H @ 30fps)
Off, on
29
COMM
1 FRAME RATE
9600 FREQ
OFF ANALOG MODE HD_T
CONFIRM
RETURN
OUTPUT
1440p 30
60HZ
OFF
