TP48200A-DX12A1 Telecom Power
User Manual
Item Specifications
Input frequency
Power factor
THD
DC output Output voltage range
Default output voltage
Output power
Regulated voltage precision
Ripple and noise
Psophometrically weighted noise
Current imbalance
AC input AC input overvoltage protection threshold
protection
AC input overvoltage recovery threshold
AC input undervoltage protection threshold
AC input undervoltage recovery threshold
DC output DC output overvoltage protection threshold
protection
AC surge Type 1 + Type 2
protection
10 kA (8/20 μs) in differential mode; 20 kA (8/20 μs) in common mode
DC surge
protection
Safety IEC/EN60950-1
compliance
Mean time 200,000 hours
between failures
(MTBF)
Issue 07 (2019-11-15) Copyright © Huawei Technologies Co., Ltd.
A Technical Specifications
Frequency range: 45–66 Hz; nominal
frequency: 50 Hz or 60 Hz
≥ 0.99 (rated input; rated load)
≤ 5% (Vin: 208 V AC, 220 V AC, or 230 V
AC; load: 50%–100%)
–42 V DC to –58 V DC
–53.5 V DC
Maximum output power = Output power of
a single rectifier x Number of rectifiers
≤ ±1%
≤ 200 mVp-p
≤ 2 mV
< ± 5% (50%–100% load)
> 300 V AC
When the voltage is restored to 290 V AC,
the output resumes.
< 85 V AC
When the voltage is restored to 90 V AC,
the output resumes.
–58.5 V DC to –60.5 V DC
1. If overvoltage occurs inside a rectifier,
the rectifier locks out.
2. If the external voltage is greater than
–63 V for more than 500 ms, the
rectifier locks out.
