TP48200A-DX12A1 Telecom Power
User Manual
Figure 3-7 FE/RS485/RS232 port pins
Table 3-6 Pin definitions for the FE port
Pin
1
2
3
6
4, 5, 7, 8
Table 3-7 Pin definitions for the RS485/RS232 port
Pin
1
2
4
5
3
7
6
8
Issue 07 (2019-11-15)
Signal
TX+
TX-
RX+
RX-
NA
Signal
TX+
TX-
RX+
RX-
RX232
TX232
PGND
NA
Copyright © Huawei Technologies Co., Ltd.
3 Components
Description
Transmits data over FE.
Receives data over FE.
-
Description
Transmits data over RS485.
Receives data over RS485.
Receives data over RS232.
Transmits data over RS232.
Connects to the ground.
–
