TP48200A-DX12A1 Telecom Power
User Manual
Button
NOTE
USB Ports
You can quickly deploy a site, import and export configuration files, export running logs, and
upgrade software by inserting the USB flash drive that is specially used for site deployment
into the USB port.
After installing the specific WiFi module using the USB port, you can access the WebUI
locally, which facilitates operations.
Using WiFi modules provided by another vendor may cause data loss or function exception.
Consequences arising from this will not be borne by Huawei.
Communications Ports
Table 3-5 Communication port description
Communications Port
FE
RS485/RS232
NOTE
Issue 07 (2019-11-15)
Name
The LCD screen becomes dark if no button is pressed within 30 seconds.
You need to log in again if no button is pressed within 1 minute.
To increase or decrease a parameter value quickly, hold down
To restart the SMU, hold down
To increase (or decrease) the LCD contrast ratio, hold down
seconds.
All these ports are protected by a security mechanism.
Copyright © Huawei Technologies Co., Ltd.
Description
and
for 10 seconds.
Communications
Parameter
10/100M autonegotiation
Baud rate: 1200bit/s,
2400bit/s, 4800bit/s,
9600bit/s, 14400bit/s,
19200bit/s, 115200bit/s
3 Components
or
.
and
(or
) for 2
Communications Protocol
HTTPS, NetEco protocol, SNMP
and TCP-Modbus protocol
Master/slave protocol, YDN
protocol, and Modbus protocol
25
