Page 2 Pictorial index Search by illustration For safety Make sure to read through them and security Instrument How to read the gauges and meters, the variety of cluster warning lights and indicators, etc. Operation of Opening and closing the doors and windows, each component adjustment before driving, etc.
Page 3: Table Of Contents
TABLE OF CONTENTS For your information .......8 Instrument cluster Reading this manual.....12 How to search ......13 Pictorial index .......14 Instrument cluster Warning lights and For safety and security indicators......128 Gauges and meters... 136 Drive monitor display..140 1-1. For safe use Multi-information display ...
Page 4: Table Of Contents
4-5. Using the driving support (vehicles without a smart systems entry & start system)..220 Cruise control ....275 Engine (ignition) switch Toyota parking (vehicles with a smart assist-sensor ....279 entry & start system)..223 Stop & Start system ..288 Continuously variable transmission Driving assist systems..
Page 5: Table Of Contents
TABLE OF CONTENTS ® 5-6. Using Bluetooth Audio system devices ® Bluetooth audio/phone ..347 Using the steering 5-1. Basic Operations wheel switches ....353 Audio system types....310 ® Registering a Bluetooth Steering wheel audio device......354 switches......313 5-7. “SETUP” menu AUX port/USB port.....316 Using the “SETUP”...
Page 6: Table Of Contents
Interior features Maintenance and care 6-1. Using the air conditioning 7-1. Maintenance and care system and defogger Cleaning and protecting Manual air conditioning the vehicle exterior..422 system ......386 Cleaning and protecting Automatic air conditioning the vehicle interior... 426 system ......393 7-2.
Page 7: Table Of Contents
TABLE OF CONTENTS 8-2. Steps to take in When trouble arises an emergency If your vehicle needs to be towed ......514 8-1. Essential information If you think something is Emergency flashers ...510 wrong ......520 If your vehicle has to Fuel pump shut off be stopped in system......
Page 8: Index
Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...586 Fuel information ....612 9-2. Customization Customizable features ..615 9-3. Initialization Items to initialize ....619 Index What to do if... (Troubleshooting) ....622 Alphabetical index....627 VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 9: For Your Information
Accessories, spare parts and modification of your Toyota A wide variety of non-genuine spare parts and accessories for Toyota vehi- cles are currently available in the market. Using these spare parts and acces-...
Page 10: Driving
SRS airbag system Seat belt pretensioner system ● Be sure to check with your Toyota dealer for precautionary measures or spe- cial instructions regarding installation of an RF-transmitter system. Further information regarding frequency bands, power levels, antenna posi- tions and installation provisions for the installation of RF-transmitters, is avail- able on request at your Toyota dealer.
Page 11 EDR. ● Disclosure of the EDR data Toyota will not disclose the data recorded in an EDR to a third party except when: • An agreement from the vehicle’s owner (or the lessee for a leased vehi- cle) is obtained •...
Page 12 Be sure to have the systems of the SRS airbag and seat belt pretensioner removed and disposed of by a qualified service shop or by your Toyota dealer before you scrap your vehicle.
Page 13: Reading This Manual
Reading this manual WARNING: Explains something that, if not obeyed, could cause death or serious injury to people. NOTICE: Explains something that, if not obeyed, could cause damage to or a malfunction in the vehicle or its equipment. Indicates operating or working procedures. Follow the steps 1 2 3 in numerical order.
Page 14: How To Search
How to search Searching by name ■ • Alphabetical index ..P. 627 Searching installation ■ position • Pictorial index....P. 14 Searching by symptom or ■ sound • What to do if... (Troubleshooting) ..P. 622 Searching by title ■...
Page 15: Pictorial Index
Pictorial index Pictorial index ■ Exterior The shape of the headlights may differ depending on the grade, etc. (P. 488) Doors ......... . . P. 161 Locking/unlocking .
Page 16 Pictorial index Windshield wipers ....... . . P. 262 Precautions against winter season ..... P. 302 Precautions against car wash .
Page 17 Pictorial index ■ Instrument panel (left-hand drive vehicles) Engine switch ....... . P. 220, 223 Starting the engine/changing the positions .
Page 18: Audio System
Pictorial index Drive monitor display ......P. 140 Multi-information display ......P. 144 If a warning message or indicator is displayed .
Page 19 ..... . P. 255 Toyota parking assist-sensor switch ....P. 280 VSC off switch .
Page 20 Pictorial index Audio remote control switches ..... P. 313 Paddle shift switches ......P. 234, 235 Telephone switches .
Page 21 Pictorial index ■ Interior (left-hand drive vehicles) SRS airbags ........P. 39 Floor mats .
Page 22 Pictorial index Inside rear view mirror ......P. 193 Sun visors ........P. 415 Vanity mirrors .
Page 23 Pictorial index ■ Instrument panel (right-hand drive vehicles) Engine switch ....... . P. 220, 223 Starting the engine/changing the positions .
Page 24 Pictorial index Drive monitor display ......P. 140 Multi-information display ......P. 144 If a warning message or indicator is displayed .
Page 25 ........P. 297 Toyota parking assist-sensor switch .
Page 26 Pictorial index Audio remote control switches ..... P. 313 Paddle shift switches ......P. 234, 235 Telephone switches .
Page 27 Pictorial index ■ Interior (right-hand drive vehicles) SRS airbags ........P. 39 Floor mats .
Page 28 Pictorial index Inside rear view mirror ......P. 193 Sun visors ........P. 415 Vanity mirrors .
Page 29 Pictorial index Air circulator ........P. 401 : If equipped VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 30 For safety and security 1-1. For safe use Before driving.......30 For safe driving ....32 Seat belts......34 SRS airbags......39 Exhaust gas precautions ..52 1-2. Child safety Riding with children....53 Child restraint systems (except for Argentina, Brazil, Colombia, Paraguay, Uruguay and Malaysia)..54 Child restraint systems (for Argentina, Brazil, Colombia, Paraguay,...
Page 31: For Safe Use Before Driving
1-1. For safe use Before driving Floor mat Use only floor mats designed specifically for vehicles of the same model and model year as your vehicle. Fix them securely in place onto the carpet. Insert the retaining hooks (clips) into the floor mat eyelets. Turn the upper knob of each retaining hook (clip) to secure the floor mats in place.
Page 32 When installing the driver’s floor mat Do not use floor mats designed for other models or different model year ● vehicles, even if they are Toyota Genuine floor mats. ● Only use floor mats designed for the driver’s seat. Always install the floor mat securely using the retaining hooks (clips) pro- ●...
Page 33: For Safe Driving
1-1. For safe use For safe driving For safe driving, adjust the seat and mirror to an appropriate position before driving. Correct driving posture Adjust angle seatback so that you are sitting straight up and so that you do not have to lean forward to steer.
Page 34 1-1. For safe use Adjusting the mirrors Make sure that you can see the rear of the vehicle clearly, by adjust- ing the inside and outside mirrors properly. (P. 193, 195) WARNING Observe the following precautions. Failure to do so may result in death or serious injury. Do not adjust the position of the driver’s seat while driving.
Page 35: Seat Belts
1-1. For safe use Seat belts Make sure that all occupants are wearing their seat belts before driving the vehicle. Correct use of the seat belts ● Extend the shoulder belt so that it comes fully over the shoulder, but does not come into contact with the neck or slide off the shoulder.
Page 36 1-1. For safe use Adjusting the seat belt shoulder anchor height (front seats only) Push the seat belt shoulder Release button anchor down while pressing the release button. Push the seat belt shoulder anchor up. Move the height adjuster up and down as needed until you hear a click.
Page 37 Seat belt regulations ■ If seat belt regulations exist in the country where you reside, please contact your Toyota dealer for seat belt replacement or installation. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 38 Each seat belt should be used by one person only. Do not use a seat belt for more than one person at once, including children. Toyota recommends that children be seated in the rear seat and always ● use a seat belt and/or an appropriate child restraint system.
Page 39 Ensure that the belt and plate are locked and the belt is not twisted. ● If the seat belt does not function correctly, immediately contact your Toyota dealer. ● Replace the seat assembly, including the belts, if your vehicle has been involved in a serious accident, even if there is no obvious damage.
Page 40: Srs Airbags
1-1. For safe use SRS airbags The SRS airbags inflate when the vehicle is subjected to certain types of severe impacts that may cause significant injury to the occupants. They work together with the seat belts to help reduce the risk of death or serious injury. ◆...
Page 41 1-1. For safe use SRS airbag system components Seat belt pretensioners and Driver airbag force limiters SRS warning light Side impact sensors (front) Driver’s knee airbag Side airbags Airbag sensor assembly Curtain shield airbags Front impact sensor Side impact sensors (rear) Front passenger airbag : If equipped The main SRS airbag system components are shown above.
Page 42 1-1. For safe use WARNING SRS airbag precautions ■ Observe the following precautions regarding the SRS airbags. Failure to do so may cause death or serious injury. The driver and all passengers in the vehicle must wear their seat belts ●...
Page 43 An infant or child who is too small to use a seat belt should be properly secured using a child restraint sys- tem. Toyota strongly recommends that all infants and children be placed in the rear seats of the vehicle and properly restrained. The rear seats are safer for infants and children than the front passenger seat.
Page 44 1-1. For safe use WARNING SRS airbag precautions ■ ● Vehicles with SRS side airbags: Do not allow anyone to kneel on the passenger seats toward the door or put their head or hands outside the vehicle. Do not attach anything to or lean any- ●...
Page 45 Vehicles without SRS curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad, are damaged or cracked, have them replaced by your Toyota dealer. Vehicles with SRS curtain shield airbags: If the areas where the SRS airbags are stored, such as the steering wheel pad and front and rear pillar garnishes, are damaged or cracked, have them replaced by your Toyota dealer.
Page 46 ■ Do not dispose of your vehicle or perform any of the following modifications without consulting your Toyota dealer. The SRS airbags may malfunction or deploy (inflate) accidentally, causing death or serious injury. Installation, removal, disassembly and repair of the SRS airbags ●...
Page 47 1-1. For safe use ■ If the SRS airbags deploy (inflate) ● Slight abrasions, burns, bruising, etc., may be sustained from SRS airbags, due to the extremely high speed deployment (inflation) by hot gases. ● A loud noise and white powder will be emitted. ●...
Page 48 1-1. For safe use ■ Conditions under which the SRS airbags may deploy (inflate), other than a collision  Except for Philippines The SRS front airbags, SRS side and curtain shield airbags (if equipped) may also deploy if a serious impact occurs to the underside of your vehicle. Some examples are shown in the illustration.
Page 49 1-1. For safe use ■ Types of collisions that may not deploy the SRS airbags (SRS front airbags) The SRS front airbags do not generally inflate if the vehicle is involved in a side or rear collision, if it rolls over, or if it is involved in a low-speed frontal collision.
Page 50 1-1. For safe use  Except for Philippines The SRS side and curtain shield airbags do not generally inflate if the vehicle is involved in a rear collision, if it rolls over, or if it is involved in a low-speed side or low-speed frontal collision.
Page 51 1-1. For safe use ■ When to contact your Toyota dealer In the following cases, the vehicle will require inspection and/or repair. Con- tact your Toyota dealer as soon as possible. Any of the SRS airbags have been inflated. ● ●...
Page 52 1-1. For safe use ● Vehicles with curtain shield airbags: The portion of the front pillars, rear pillars or roof side rail garnishes (padding), containing the curtain shield airbags inside, is scratched, cracked, or otherwise damaged. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 53: Exhaust Gas Precautions
Keep the trunk lid closed. If you smell exhaust gases in the vehicle even when the trunk lid is closed, ● open the windows and have the vehicle inspected at your Toyota dealer as soon as possible. ■ When parking If the vehicle is in a poorly ventilated area or a closed area, such as a ●...
Page 54 1-2. Child safety Riding with children Observe the following precautions when children are in the vehi- cle. Use a child restraint system appropriate for the child, until the child becomes large enough to properly wear the vehicle’s seat belt. ● It is recommended that children sit in the rear seats to avoid acci- dental contact with the shift lever, wiper switch, etc.
Page 55: Child Restraint Systems
1-2. Child safety Child restraint systems (except for Argentina, Brazil, Colombia, Paraguay, Uruguay and Malaysia) Before installing a child restraint system in the vehicle, there are precautions that need to be observed, different types of child restraint systems, as well as installation methods, etc., written in this manual.
Page 56 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the weight and size of the child, installed on the rear seat. Accord- ing to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 57 1-2. Child safety WARNING Handling the child restraint system ■ If the child restraint system is not properly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving, or an accident. If the vehicle were to receive a strong impact from an accident, etc., it is ●...
Page 58 1-2. Child safety When using a child restraint system When installing a child restraint system to a front passenger ■ seat (except for Taiwan) For the safety of a child, install a child restraint system to a rear seat. When installing a child restraint system to a front passenger seat is unavoidable, adjust the seat as follows and install the child restraint system.
Page 59 1-2. Child safety WARNING When using a child restraint system ■ Observe the following precautions. Failure to do so may result in death or serious injury. Except for Taiwan: Never use a rear- ● facing child restraint system on the front passenger seat.The force of the rapid inflation of the front passenger airbag can cause death or serious injury to...
Page 60 1-2. Child safety WARNING When using a child restraint system ■ ● For Taiwan: Never use a child restraint system on the front passenger seat. The force of the rapid inflation of the front passenger airbag can cause death or serious injury to children in the event of an accident.
Page 61 1-2. Child safety WARNING When using a child restraint system ■ ● Except for Taiwan: Only put a forward- facing child restraint system on the front seat when unavoidable. When installing a forward-facing child restraint on the front passenger seat, move the seat as far back as possible.
Page 62 1-2. Child safety Child restraint system compatibility for each seating position Child restraint system compatibility for each seating position ■ Compatibility of each seating position with child restraint systems (P. 63, 68, 73, 79) displays the type of child restraint systems that can be used and possible seating positions for installation using symbols.
Page 63 1-2. Child safety Example of the displayed regulation number UN(ECE) R44 approval mark The weight range of the child who is applicable for an UN(ECE) R44 approval mark is indicated. UN(ECE) R129 approval mark The height range of the child who is applicable as well as available weights for an UN(ECE) R129 approval mark is indicated.
Page 64 1-2. Child safety Compatibility of each seating position with child restraint sys- ■ tems (for Egypt, Algeria and South Africa)  Left-hand drive vehicle  Right-hand drive vehicle 1, 2, 3 Suitable for “universal” category child restraint system fixed with the seat belt. Suitable for ISOFIX child restraint system.
Page 65 1-2. Child safety : Move the front seat fully rearward. If the passenger seat height can be adjusted, move it to the upper most position. : Adjust the seatback angle to the most upright position. When installing a forward-facing child seat, if there is a gap between the child seat and the seatback, adjust the seatback angle...
Page 66 1-2. Child safety Detail information for Child Restraint Systems installation (for ■ Egypt, Algeria and South Africa) Seating position Seat position number Seating position suitable for univer- (Forward- sal belted (Yes/No) facing only) i-Size seating position (Yes/No) Seating position suitable for lateral fixture (L1/L2/No) Suitable rearward facing fixture R1, R2X,...
Page 67 1-2. Child safety Fixture Description Full-height, forward-facing child restraint systems Reduced-height forward-facing child restraint systems Reduced-height forward-facing child restraint systems Full-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Rearward-facing infant seat Left lateral-facing (carrycot) infant seat Right lateral-facing (carrycot) infant seat Junior seat Junior seat...
Page 68 1-2. Child safety ● If the seat belt shoulder anchor is ahead of the child seat belt guide, move the seat cushion forward. ● When installing a junior seat, if the child in your child restraint system is in a very upright position, adjust the seatback angle to the most comfortable position.
Page 69 1-2. Child safety Compatibility of each seating position with child restraint sys- ■ tems (for ASEAN countries : Brunei, Myanmar, Cambodia, Laos, Vietnam, Singapore, Thailand, Indonesia and Philippines  Left-hand drive vehicle  Right-hand drive vehicle 1, 2, 3 VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 70 1-2. Child safety Suitable for “universal” category child restraint system fixed with the seat belt. Suitable child restraint systems given recommended child restraint systems and compatibility table (P. 72). Suitable for i-Size and ISOFIX child restraint system. Includes a top tether anchorage point. Not suitable for child restraint system.
Page 71 1-2. Child safety Detail information for Child Restraint Systems installation (for ■ ASEAN countries : Brunei, Myanmar, Cambodia, Laos, Vietnam, Singapore, Thailand, Indonesia and Philippines Seating position Seat position number Seating position suitable for universal (Forward- belted (Yes/No) facing only) i-Size seating position (Yes/No) Seating position suitable for lateral fixture (L1/L2/No)
Page 72 1-2. Child safety Fixture Description Full-height, forward-facing child restraint systems Reduced-height forward-facing child restraint systems Reduced-height forward-facing child restraint systems Full-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Rearward-facing infant seat Left lateral-facing (carrycot) infant seat Right lateral-facing (carrycot) infant seat Junior seat Junior seat...
Page 73 1-2. Child safety Recommended child restraint systems and Compatibility table ■ (ASEAN countries : Brunei, Myanmar, Cambodia, Laos, Vietnam, Singapore, Thailand, Indonesia and Philippines Seating position Recommended Child Restraint System i-Size child restraint i-Size MIDI (Yes/No) systems The child restraint systems mentioned in the table may not be avail- able outside the ASEAN area.
Page 74 1-2. Child safety Compatibility of each seating position with child restraint sys- ■ tems (for Ecuador) 1, 2, 3 Suitable for “universal” category child restraint system fixed with the seat belt. Suitable child restraint systems given recommended child restraint systems and compatibility table (P.
Page 75 1-2. Child safety : Move the front seat fully rearward. If the passenger seat height can be adjusted, move it to the upper most position. : Adjust the seatback angle to the most upright position. When installing a forward-facing child seat, if there is a gap between the child seat and the seatback, adjust the seatback angle...
Page 76 1-2. Child safety Detail information for Child Restraint Systems installation (for ■ Ecuador) Seating position Seat position number Seating position suitable for univer- (Forward- sal belted (Yes/No) facing only) i-Size seating position (Yes/No) Seating position suitable for lateral fixture (L1/L2/No) Suitable rearward facing fixture R1, R2X, R1, R2X,...
Page 77 1-2. Child safety Fixture Description Full-height, forward-facing child restraint systems Reduced-height forward-facing child restraint systems Reduced-height forward-facing child restraint systems Full-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Rearward-facing infant seat Left lateral-facing (carrycot) infant seat Right lateral-facing (carrycot) infant seat Junior seat Junior seat...
Page 78 1-2. Child safety Recommended child restraint systems and Compatibility table ■ (for Ecuador) Seating position Recommended Child Mass groups Restraint System 0,0+ Up to 13kg MIDI 2 (Yes/No) (28 lb.) 9 to 18 kg MIDI 2 (Yes/No) (20 to 39 lb.) The child restraint systems mentioned in the table may not be avail- able outside the LATIN area.
Page 79 1-2. Child safety ● If the seat belt shoulder anchor is ahead of the child seat belt guide, move the seat cushion forward. ● When installing a junior seat, if the child in your child restraint system is in a very upright position, adjust the seatback angle to the most comfortable position.
Page 80 1-2. Child safety Compatibility of each seating position with child restraint sys- ■ tems (for Taiwan) If your child restraint system is of “universal” category, you can install it on the positions mentioned by U or UF in the table below (UF is for forward-facing child restraint systems only).
Page 81 1-2. Child safety Key of letters inserted in the above table: X: Not suitable seat position for children in this mass group. U: Suitable for “universal” category child restraint systems approved for use in this mass group. : If the head restraint interferes with your child restraint system, and the head restraint can be removed, remove the head restraint.
Page 82 1-2. Child safety Child restraint system installation method Confirm with the operation manual enclosed with the child restraint system about the installation of the child restraint system. Installation method Page Seat belt attach- P. 83 ment Type A  ISOFIX lower anchorage attach- P.
Page 83 1-2. Child safety Installation method Page Top tether anchor- P. 88 age attachment VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 84 1-2. Child safety Installing child restraint system using a seat belt ■ Install the child restraint system in accordance to the operation manual enclosed with the child restraint system. If the child restraint system on hand is not within the “universal” cat- egory (or the necessary information is not in the table), refer to the “Vehicle List”...
Page 85 You may need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Toyota dealer: Locking clip for child restraint system (Part No. 73119-22010) WARNING When installing a child restraint system ■...
Page 86 1-2. Child safety Child restraint system fixed with an ISOFIX lower anchorages ISOFIX lower anchorages (ISOFIX child restraint system) ■ Lower anchorages are provided for the rear outboard seats. (Tags displaying the location of the anchorages are attached to the seats.) Type A Type B...
Page 87 1-2. Child safety Check the positions of the exclusive fixing bars, and install the child restraint system to the seat. The bars are installed behind the seat cushion and accessed via the access holes. Check to make sure the seat belt will not be clamped between the anchor and buckle.
Page 88 1-2. Child safety ■ When using a “MIDI 2” (for Latin American countries Adjust the support leg and ISOFIX connectors as follows: Lock the ISOFIX connectors where number 3 can be seen. Lock the support leg where 7 holes can be seen.
Page 89 1-2. Child safety Using a top tether anchorages Top tether anchorages ■ Top tether anchorages are pro- vided for the outboard rear seat. Use top tether anchorages when fixing the top strap. Top tether anchorages Top strap Fixing the top strap to the top tether anchorages ■...
Page 90 1-2. Child safety WARNING When installing a child restraint system ■ Observe the following precautions. Failure to do so may result in death or serious injury. Firmly attach the top strap and make sure that the belt is not twisted. ●...
Page 91 1-2. Child safety Child restraint systems (for Argentina, Brazil, Colombia, Paraguay, Uruguay and Malaysia) Before installing a child restraint system in the vehicle, there are precautions that need to be observed, different types of child restraint systems, as well as installation methods, etc., written in this manual.
Page 92 ● Toyota strongly urges the use of a proper child restraint system that con- forms to the weight and size of the child, installed on the rear seat. Accord- ing to accident statistics, the child is safer when properly restrained in the rear seat than in the front seat.
Page 93 1-2. Child safety WARNING Handling the child restraint system ■ If the child restraint system is not properly fixed in place, the child or other passengers may be seriously injured or even killed in the event of sudden braking, sudden swerving, or an accident. If the vehicle were to receive a strong impact from an accident, etc., it is ●...
Page 94 1-2. Child safety When using a child restraint system When installing a child restraint system to a front passenger ■ seat For the safety of a child, install a child restraint system to a rear seat. When installing a child restraint system to a front passenger seat is unavoidable, adjust the seat as follows and install the child restraint system.
Page 95 1-2. Child safety WARNING When using a child restraint system ■ Observe the following precautions. Failure to do so may result in death or serious injury. Never use a rear-facing child restraint ● system on the front passenger seat.The force of the rapid inflation of the front passenger airbag can cause death or serious injury to children in the event of an accident.
Page 96 1-2. Child safety WARNING When using a child restraint system ■ ● Only put a forward-facing child restraint system on the front seat when unavoid- able. When installing a forward-facing child restraint on the front passenger seat, move the seat as far back as pos- sible.
Page 97 1-2. Child safety Child restraint system compatibility for each seating position Child restraint system compatibility for each seating position ■ Compatibility of each seating position with child restraint systems (P. 98, 103) displays the type of child restraint systems that can be used and possible seating positions for installation using sym- bols.
Page 98 1-2. Child safety Example of the displayed regulation number UN(ECE) R44 approval mark The weight range of the child who is applicable for an UN(ECE) R44 approval mark is indicated. UN(ECE) R129 approval mark The height range of the child who is applicable as well as available weights for an UN(ECE) R129 approval mark is indicated.
Page 99 1-2. Child safety Compatibility of each seating position with child restraint sys- ■ tems (except for Malaysia) 1, 2, 3 Suitable for fixed with vehicle seat belt “universal” cate- gory child restraint system. Suitable particular child restraints given recommended child restraint systems and compatibility table (P.
Page 100 1-2. Child safety : Move the front seat fully rearward. If the passenger seat height can be adjusted, move it to the upper most position. : Adjust the seatback angle to the most upright position. When installing a forward-facing child seat, if there is a gap between the child seat and the seatback, adjust the seatback angle...
Page 101 1-2. Child safety Detail information for CRS installation (except for Malaysia) ■ Seating position Seat position number Seating position suitable for universal belted (yes/no) i-Size seating position (yes/no) Seating position suitable for lateral fixture (L1/L2) Suitable rearward facing fixture R1, R2 R1, R2 (R1/R2/R3) Suitable forward facing fixture...
Page 102 Mass groups Restraint System TOYOTA G0+, 0,0+ BABY SAFE PLUS Up to 13kg (28 lb.) MIDI 2 TOYOTA DUO PLUS ISO fix ISO fix 9 to 18 kg only only (20 to 39 lb.) MIDI 2 The child restraint systems mentioned in the table may not be avail- able outside the LATIN area.
Page 103 1-2. Child safety ● If the seat belt shoulder anchor is ahead of the child seat belt guide, move the seat cushion forward. ● When installing a junior seat, if the child in your child restraint system is in a very upright position, adjust the seatback angle to the most comfortable position.
Page 104 1-2. Child safety Compatibility of each seating position with child restraint sys- ■ tems (for Malaysia only) 1, 2, 3 Suitable for “universal” category child restraint system fixed with the seat belt. Suitable child restraint systems given recommended child restraint systems and compatibility table (P.
Page 105 1-2. Child safety : Move the front seat fully rearward. If the passenger seat height can be adjusted, move it to the upper most position. : Adjust the seatback angle to the most upright position. When installing a forward-facing child seat, if there is a gap between the child seat and the seatback, adjust the seatback angle...
Page 106 1-2. Child safety Detail information for child restraint systems installation (for ■ Malaysia only) Seating position Seat position number Seating position suitable for universal (Forward- belted (Yes/No) facing only) i-Size seating position (Yes/No) Seating position suitable for lateral fixture (L1/L2/No) Suitable rearward facing fixture R1, R2X, R1, R2X,...
Page 107 1-2. Child safety Fixture Description Full-height, forward-facing child restraint systems Reduced-height forward-facing child restraint systems Reduced-height forward-facing child restraint systems Full-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Reduced-size, rearward-facing child restraint systems Rearward-facing infant seat Left lateral-facing (carrycot) infant seat Right lateral-facing (carrycot) infant seat Junior seat Junior seat...
Page 108 1-2. Child safety Recommended child restraint systems and Compatibility table ■ (for Malaysia only) Seating position Recommended Child Restraint System i-Size child restraint i-Size MIDI (Yes/No) systems The child restraint systems mentioned in the table may not be avail- able outside the ASEAN area. When securing some types of child restraint systems in rear seat, it may not be possible to properly use the seat belts in positions next to the child restraint without interfering with it or affecting seat belt...
Page 109 1-2. Child safety Child restraint system installation method Confirm with the operation manual enclosed with the child restraint system about the installation of the child restraint system. Installation method Page Seat belt attach- P. 109 ment ISOFIX lower anchorage attach- P.
Page 110 1-2. Child safety Installing child restraint system using a seat belt ■ Install the child restraint system in accordance to the operation manual enclosed with the child restraint system. If the child restraint system on hand is not within the “universal” cat- egory (or the necessary information is not in the table), refer to the “Vehicle List”...
Page 111 You may need a locking clip to install the child restraint system. Follow the instructions provided by the manufacturer of the system. If your child restraint system does not provide a locking clip, you can purchase the following item from your Toyota dealer: Locking clip for child restraint system (Part No. 73119-22010) WARNING When installing a child restraint system ■...
Page 112 1-2. Child safety Child restraint system fixed with an ISOFIX lower anchorages ISOFIX lower anchorages (ISOFIX child restraint system) ■ Lower anchorages are provided for the rear outboard seats. (Tags displaying the location of the anchorages are attached to the seats.) Installation with ISOFIX lower anchorage (ISOFIX child ■...
Page 113 1-2. Child safety ■ When using a “TOYOTA DUO+” (except for Malaysia) Adjust it to the most reclined position. ■ When using a “MIDI 2” (except for Malaysia) Adjust the support leg and ISOFIX connectors as follows: Lock the ISOFIX connectors where number 3 can be seen.
Page 114 1-2. Child safety Using a top tether anchorages Top tether anchorages ■ Top tether anchorages are pro- vided for the outboard rear seat. Use top tether anchorages when fixing the top strap. Top tether anchorages Top strap Fixing the top strap to the top tether anchorages ■...
Page 115 1-2. Child safety WARNING When installing a child restraint system ■ Observe the following precautions. Failure to do so may result in death or serious injury. Firmly attach the top strap and make sure that the belt is not twisted. ●...
Page 116: Engine Immobilizer System
1-3. Theft deterrent system  Engine immobilizer system The vehicle’s keys have built-in transponder chips that prevent the engine from starting if a key has not been previously regis- tered in the vehicle’s on-board computer. Never leave the keys inside the vehicle when you leave the vehi- cle.
Page 117 1-3. Theft deterrent system ■ System maintenance The vehicle has a maintenance-free type engine immobilizer system. ■ Conditions that may cause the system to malfunction ● If the grip portion of the key is in contact with a metallic object If the key is in close proximity to or touching a key to the security system ●...
Page 118 1-3. Theft deterrent system ■ Certifications for the engine immobilizer system (vehicles without a smart entry & start system)  For vehicles sold in the Dominican Republic  For vehicles sold in Jamaica  For vehicles sold in Brazil VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 119 1-3. Theft deterrent system ■ Certifications for the engine immobilizer system (vehicles with a smart entry & start system)  For vehicles sold in the Dominican Republic  For vehicles sold in Singapore  For vehicles sold in Taiwan  For vehicles sold in Vietnam VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 120 1-3. Theft deterrent system  For vehicles sold in Brazil  For vehicles sold in Jamaica NOTICE ■ To ensure the system operates correctly Do not modify or remove the system. If modified or removed, the proper operation of the system cannot be guaranteed. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 121: Alarm
1-3. Theft deterrent system  Alarm The alarm The alarm uses light and sound to give an alert when an intrusion is detected. The alarm is triggered in the following situations when the alarm is set: ● A locked door or trunk is opened in any way other than using the entry function (vehicles with a smart entry &...
Page 122 1-3. Theft deterrent system Deactivating or stopping the alarm Do one of the following to deactivate or stop the alarm: ● Unlock the doors or trunk using the entry function (vehicles with a smart entry & start system) or wireless remote control. ●...
Page 123 1-3. Theft deterrent system ■ Triggering of the alarm The alarm may be triggered in the following situations: (Stopping the alarm deactivates the alarm system.) ● The doors are unlocked using the key (vehicles without a smart entry & start system) or mechanical key (vehicles with a smart entry &...
Page 124 1-3. Theft deterrent system Intrusion sensor (if equipped) The intrusion sensor detects intruders or movement in the vehicle. When an intruder or movement is detected, the alarm will be trig- gered. This system is designed to deter and prevent vehicle theft but does not guarantee absolute security against all intrusions.
Page 125 1-3. Theft deterrent system ■ Canceling and automatic re-enabling of the intrusion sensor ● The alarm will still be set even when the intrusion sensor is canceled. ● Vehicles without a smart entry & start system: After the intrusion sensor is canceled, turn the engine switch to the “ON”...
Page 126 1-3. Theft deterrent system ● Unstable items, such as dangling acces- sories or clothes hanging on the coat hooks, are in the vehicle. The vehicle is parked in a place where ● extreme vibrations or noises occur, such as in a parking garage. Ice or snow is removed from the vehicle, ●...
Page 127 Do not spray air fresheners or other ● products directly into the sensor holes. Installing accessories other than genuine Toyota parts or leaving objects ● between the driver’s seat and front passenger’s seat may reduce the detection performance.
Page 128 Instrument cluster Instrument cluster Warning lights and indicators ......128 Gauges and meters ...136 Drive monitor display ..140 Multi-information display ..144 VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 129: Indicators
2. Instrument cluster Warning lights and indicators The warning lights and indicators on the instrument cluster and center panel inform the driver of the status of the vehicle’s vari- ous systems. For the purpose of explanation, the following illustration dis- plays all warning lights and indicators illuminated.
Page 130 2. Instrument cluster ● Vehicles with a multi-information display Vehicles without a Stop & Start system   Vehicles with a Stop & Start system The units used on the meters and some indicators may differ depend- ing on the target region. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 131 2. Instrument cluster Warning lights Warning lights inform the driver of malfunctions in the indicated vehi- cle’s systems. 2, 3 Cruise control indicator Brake system warning (P. 277) light (P. 524) (Yellow) 1, 2 1, 3, 9 Charging system Stop & Start cancel warning light (P.
Page 132 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : Vehicles with a drive monitor display : If equipped : The light turns on to indicate a malfunction.
Page 133 2. Instrument cluster Indicators The indicators inform the driver of the operating state of the vehicle’s various systems. 1, 5 Cruise control indicator Turn signal indicator (P. 275) (P. 247) (Green) 1, 5 Tail light indicator “SET” indicator (P. 250) (P.
Page 134 There may be a malfunction in a system if a light does not come on, or if the lights do not turn off. Have the vehicle inspected by your Toyota dealer. : The light flashes to indicate that the system is operating.
Page 135 2. Instrument cluster ■ Eco Driving Indicator Light (if equipped) Vehicles with a manual transmission: During Eco-friendly acceleration and in Eco-friendly shift position (Eco driving), Eco Driving Indicator Light will turn on. When the accelerator pedal is depressed excessively, or when the vehicle is stopped, the light turns off.
Page 136 Have the vehicle inspected by your Toyota dealer immedi- ately if this occurs.
Page 137: Gauges And Meters
2. Instrument cluster Gauges and meters  Vehicles with a drive monitor display Vehicles with a multi-information display  VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 138 2. Instrument cluster Tachometer Displays the engine speed in revolutions per minute. Speedometer Displays the vehicle speed. Outside temperature display Displays the outside temperature within the range of -40 °C (-40 °F) to 50 °C (122° F). Vehicles with a multi-information display: Low outside temperature indicator comes on when the ambient tempera- ture is 3 °C (37 °F) or lower.
Page 139 2. Instrument cluster Changing the display  Vehicles with a drive monitor display  P. 140 Vehicles with a multi-information display  Switches the items of the odome- ter and trip meter display by pressing the “TRIP” switch. When the trip meter is displayed, pressing and holding the “TRIP”...
Page 140 ● When “--” is displayed, the system may be malfunctioning. Take your vehicle to your Toyota dealer. The temperature range that can be displayed is from -40 °C (-40 °F) to ● 50 °C (122 °F).
Page 141: Drive Monitor Display
2. Instrument cluster  Drive monitor display Display contents  Clock ( P. 138) Outside temperature display  P. 139) Shift position and gear step position indicator  P. 232, 234, 235, 240)  Drive information ( P. 141) Changing the display Items displayed can be switched by pressing the button.
Page 142 2. Instrument cluster Drive information Odometer and trip meter display ■ P. 137 Stop & Start system total operation time (if equipped) ■ Displays the total amount of time that the engine has been stopped due to operation of the Stop & Start system since the system was last reset.
Page 143 2. Instrument cluster Instrument cluster light control (if equipped) The brightness level of the instrument cluster can be adjusted when the Instrument cluster light customization display is displayed. Pressing and holding the display change button for more than 1 second will adjust the brightness.
Page 144 2. Instrument cluster ■ When disconnecting and reconnecting battery terminals The following information data will be reset. ● Average fuel consumption ● Driving range Average vehicle speed ● ■ Liquid crystal display Small spots or light spots may appear on the display. This phenomenon is characteristic of liquid crystal display, and there is no problem continuing to use the display.
Page 145: Multi-Information Display
2. Instrument cluster  Multi-information display Display contents The multi-information display presents the driver with a variety of vehi- cle data. ● Menu icons Displays the following informa- tion when an icon is selected. (P. 144) Some of the information may be displayed automatically depending on the situation.
Page 146 2. Instrument cluster Driving Information Items displayed can be switched by pressing “<” or “>” of the meter control switches to select and pressing “” or “”. ● Average fuel consumption (after reset/after start) Displays the average fuel consumption since the function was reset, or the engine was started.
Page 147 2. Instrument cluster Eco information Items displayed can be switched by pressing “” or “” of the meter control switches to select and pressing “” or “” Eco Driving Indicator Zone Display (if equipped) ■  P. 149 Eco Savings (if equipped) ■...
Page 148 2. Instrument cluster Past Record ■ Displays average fuel consumption history. The current month, the last 3 months and the same month last year are displayed, enabling a comparison to be made. The function can be reset via the option screen. Press and hold display option screen.
Page 149 2. Instrument cluster Settings Items displayed can be switched by pressing “<” or “>” of the meter control switches to select and pressing “” or “” Language ■ Select to change the language on the display. Units ■ Select to change the unit of measure for the multi-information dis- play.
Page 150 2. Instrument cluster ■ Pop-up guidance In some situations, such as when a switch operation is performed, a pop-up guidance will be temporarily displayed on the multi-information display. The pop-up guidance function can be set on/off. ■ Setting display automatic cancelation “Settings”...
Page 151 2. Instrument cluster ■ Trip Summary Display When the engine switch is turned off, each of the following will be displayed on the multi-information display, and will extinguish after approximately 30 seconds. ● Distance ● Elapsed time Average fuel consumption ●...
Page 152 Operation of each component 3-1. Key information Keys........152 3-2. Opening, closing and locking the doors Doors .........161 Trunk........168 Smart entry & start system .....173 3-3. Adjusting the seats Front seats......184 Rear seats (fold-down type)....186 Head restraints ....189 3-4. Adjusting the steering wheel and mirrors Steering wheel ....191 Inside rear view mirror ..193...
Page 153: Key Information Keys
3-1. Key information Keys The keys The following keys are provided with the vehicle.  Vehicles without a smart entry & start system (type A) Keys Key number plate  Vehicles without a smart entry & start system (type B) Key (with a wireless remote control function) Operating the wireless remote con-...
Page 154 3-1. Key information  Vehicles without a smart entry & start system (type D) Master key (with a wireless remote control function) Operating the wireless remote con- trol function Master key (without a wireless remote control function) Valet key (without a wireless remote control function) Key number plate ...
Page 155 3-1. Key information  Vehicles without a smart entry & start system (type G) Master keys Valet key Wireless remote control Operating the wireless remote con- trol function Key number plate Vehicles without a smart entry & start system (type H) ...
Page 156 3-1. Key information Wireless remote control (if equipped)  Vehicles without a smart entry & start system (type A) Locks all the doors (P. 161) Unlocks all the doors (P. 161) Open the trunk (press and hold) (P. 169)  Vehicles without a smart entry &...
Page 157 ■ If you lose your keys New genuine keys can be made by your Toyota dealer using the other key and the key number stamped on your key number plate. Keep the plate in a safe place such as your wallet, not in the vehicle.
Page 158 Vehicles with a smart entry & start system P. 178 ■ Replacing the battery P. 479 Confirmation of the registered key number ■ The number of keys already registered to the vehicle can be confirmed. Ask your Toyota dealer for details. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 159 3-1. Key information ■ Certification for wireless remote control  For vehicles sold in Taiwan  For vehicles sold in Vietnam  For vehicles sold in Jamaica  For vehicles sold in Pakistan VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 160 3-1. Key information  For vehicles sold in Brazil VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 161 Take your vehicle with all the electronic keys provided with your vehicle to your Toyota dealer. ■ When a key is lost If the key remains lost, the risk of vehicle theft increases significantly. Visit your Toyota dealer immediately with all remaining keys that were provided with your vehicle. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 162 3-2. Opening, closing and locking the doors Doors The vehicle can be locked and unlocked using the entry func- tion, wireless remote control, key or door lock switch. Unlocking and locking the doors from the outside ◆ Entry function (vehicles with a smart entry & start system) While carrying the electronic key, press the button to lock and unlock.
Page 163 3-2. Opening, closing and locking the doors  Vehicles with a smart entry & start system Locks all the doors Check that the door is securely locked. Unlocks all the doors ◆ Keys Vehicles without a smart entry & start system ...
Page 164 3-2. Opening, closing and locking the doors ■ Impact detection door lock release system (if equipped) In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, how- ever, the system may not operate.
Page 165 3-2. Opening, closing and locking the doors Unlocking and locking the doors from the inside ◆ Door lock switches (if equipped) Locks all the doors Unlocks all the doors ◆ Inside lock buttons Locks the door Unlocks the door The driver’s door can be opened by pulling the inside handle even if the lock button is in the lock position.
Page 166 3-2. Opening, closing and locking the doors Locking the front doors from the outside without a key Move the inside lock button to the lock position. Close the door while pulling the door handle. Vehicles without a smart entry & start system (equipped with a ...
Page 167 3-2. Opening, closing and locking the doors Automatic door locking and unlocking systems (if equipped) The following functions can be set or canceled: Function Operation All the doors are automatically locked when vehicle speed Speed linked door locking function approximately 20 km/h (12 mph) or higher.
Page 168 3-2. Opening, closing and locking the doors ■ Impact detection door lock release system (if equipped) In the event that the vehicle is subject to a strong impact, all the doors are unlocked. Depending on the force of the impact or the type of accident, however, the system may not operate.
Page 169: Trunk
3-2. Opening, closing and locking the doors Trunk The trunk can be opened using the trunk opener, entry function, wireless remote control or key. Opening the trunk from inside the vehicle Release the trunk lid. Opening the trunk from outside the vehicle ◆...
Page 170 3-2. Opening, closing and locking the doors ◆ Wireless remote control (if equipped)  Vehicles without a smart entry & start system (type A) Press and hold the switch.  Vehicles without a smart entry & start system (type B) Press and hold the switch.
Page 171 3-2. Opening, closing and locking the doors ◆ Key (vehicles without a wireless remote control and smart entry & start system) Turn the key clockwise to release the trunk lid. ■ Operation signals (vehicles with a smart entry & start system) Except for Malaysia, India, Egypt: A buzzer sounds to indicate that the trunk has been unlocked.
Page 172 3-2. Opening, closing and locking the doors WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Before driving Make sure that the trunk lid is fully closed. If the trunk lid is not fully closed, ●...
Page 173 ● Do not attach any accessories other than genuine Toyota parts to the trunk lid. Such additional weight on the trunk lid may cause the lid to suddenly shut again after it is opened.
Page 174: Smart Entry & Start System
3-2. Opening, closing and locking the doors  Smart entry & start system The following operations can be performed simply by carrying the electronic key on your person, for example in your pocket. The driver should always carry the electronic key. ●...
Page 175 3-2. Opening, closing and locking the doors ■ Effective range (areas within which the electronic key is detected)  Left-hand drive vehicles  Right-hand drive vehicles When locking or unlocking the doors The system can be operated when the electronic key is within about 0.7 m (2.3 ft.) either of the outside front door handles.
Page 176 3-2. Opening, closing and locking the doors Alarm Situation/Correction procedure An attempt was made to lock any door by open- ing a door and putting the inside lock button into Interior alarm pings the lock position, then closing the door by pulling once and exterior alarm on the outside door handle with the electronic key sounds once for 5 sec-...
Page 177 3-2. Opening, closing and locking the doors ■ Battery-saving function The battery-saving function will be activated in order to prevent the electronic key battery and the battery from being discharged while the vehicle is not in operation for a long time. ■...
Page 178 3-2. Opening, closing and locking the doors ● When other wireless keys (that emit radio waves) are being used nearby ● When carrying the electronic key together with the following devices that emit radio waves • Portable radio, cellular phone, cordless phone or other wireless commu- nication device •...
Page 179 3-2. Opening, closing and locking the doors ■ When the vehicle is not driven for extended periods To prevent theft of the vehicle, do not leave the electronic key within 2 m ● (6 ft.) of the vehicle. The smart entry & start system can be deactivated in advance. (P. 615) ●...
Page 180 3-2. Opening, closing and locking the doors ■ When the electronic key battery is fully depleted P. 479 Customization that can be configured at Toyota dealer ■ Settings (e. g. smart entry & start system) can be changed. (Customizable features: P. 615) If the smart entry &...
Page 181 3-2. Opening, closing and locking the doors ■ Certification for the smart entry & start system  For vehicles sold in the Dominican Republic  For vehicles sold in Singapore  For vehicles sold in Taiwan  For vehicles sold in Pakistan VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 182 3-2. Opening, closing and locking the doors  For vehicles sold in Vietnam  For vehicles sold in United Arab Emirates  For vehicles sold in Jamaica VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 183 3-2. Opening, closing and locking the doors  For vehicles sold in Brazil VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 184 (P. 173) The radio waves may affect the operation of such devices. If necessary, the entry function can be disabled. Ask your Toyota dealer for details, such as the frequency of radio waves and timing of the emitted radio waves.
Page 185: Adjusting The Seats Front Seats
3-3. Adjusting the seats Front seats Adjustment procedure Manual seat  Seat position adjustment lever Seatback angle adjustment lever Vertical height adjustment lever (if equipped) : Driver’s seat only VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 186 3-3. Adjusting the seats  Power seat (driver’s seat only) Seat position adjustment switch Seatback angle adjustment switch Seat cushion (front) angle adjustment switch Vertical height adjustment switch WARNING When adjusting the seat position ■ ● Take care when adjusting the seat position to ensure that other passen- gers are not injured by the moving seat.
Page 187 3-3. Adjusting the seats Rear seats (fold-down type) The seatbacks of the rear seats can be folded down. Folding down the rear seatbacks Lower the rear center seat head restraint to the lowest position. (P. 189) Stow the rear center seat belt buckles as shown.
Page 188 3-3. Adjusting the seats Returning rear seatbacks Lift up the seatback until it locks. Remove the seat belt from guide ■ If the seat belt interferes with luggage on the folded seats, remove the seat belt from the guide. Make sure to pass the seat belt through the guide, when the seat belt is being used.
Page 189 3-3. Adjusting the seats WARNING After returning the rear seatback to the upright position ■ Observe the following precautions. Failure to do so may result in death or serious injury. Make sure that the seatback is securely ● locked in position by lightly pushing it back and forth.
Page 190: Head Restraints
3-3. Adjusting the seats Head restraints Head restraints are provided for all seats. Adjusting the head restraints (front seats and rear center seat) Pull the head restraints up. Down Push the head restraint down while pressing the lock release button. Lock release button Removing the head restraints...
Page 191 3-3. Adjusting the seats ■ Adjusting the height of the head restraints (front seats) Make sure that the head restraints are adjusted so that the center of the head restraint is closest to the top of your ears. Adjusting the rear center seat head restraint ■...
Page 192 3-4. Adjusting the steering wheel and mirrors Steering wheel Adjustment procedure Hold the steering wheel and push the lever down. Adjust to the ideal position by moving the steering wheel verti- cally. After adjustment, pull the lever up to secure the steering wheel. Horn To sound the horn, press on or close to the...
Page 193 3-4. Adjusting the steering wheel and mirrors ■ After adjusting the steering wheel Make sure that the steering wheel is securely locked. The horn may not sound if the steering wheel is not securely locked. WARNING Caution while driving ■ Do not adjust the steering wheel while driving.
Page 194: Inside Rear View Mirror
3-4. Adjusting the steering wheel and mirrors Inside rear view mirror The rear view mirror’s position can be adjusted to enable suffi- cient confirmation of the rear view. Adjusting the height of rear view mirror (if equipped) The height of the rear view mirror can be adjusted to suit your driving posture.
Page 195 3-4. Adjusting the steering wheel and mirrors  Auto anti-glare inside rear view mirror Responding to the level of brightness of the headlights of vehicles behind, the reflected light is automatically reduced. Changing automatic anti-glare function mode ON/OFF When the automatic anti-glare function is in ON mode, the indica- tor illuminates.
Page 196: Outside Rear View Mirrors
3-4. Adjusting the steering wheel and mirrors Outside rear view mirrors Adjustment procedure Manually-adjustable type  Adjust the mirror up, down, in or out by pushing the mirror surface.  Power-adjustable type To select a mirror to adjust, turn the switch. Left Right To adjust the mirror, operate the...
Page 197 3-4. Adjusting the steering wheel and mirrors Folding the mirrors  Manual type Push the mirror back in the direc- tion of the vehicle’s rear.  Power type Press the switch. Folds the mirrors Extends the mirrors This type can also be folded manu- ally.
Page 198 3-4. Adjusting the steering wheel and mirrors WARNING Important points while driving ■ Observe the following precautions while driving. Failure to do so may result in loss of control of the vehicle and cause an accident, resulting in death or serious injury. Do not adjust the mirrors while driving.
Page 199: Moon Roof Power Windows
3-5. Opening and closing the windows and moon roof Power windows Opening and closing procedures The power windows can be opened and closed using the switches. Operating the switch moves the windows as follows: Type A  Closing One-touch closing (driver’s win- dow only) Opening One-touch opening...
Page 200 3-5. Opening and closing the windows and moon roof Window lock switch Press the switch to lock the pas- senger window switches. Use this switch to prevent children from accidentally opening or clos- ing a passenger window. ■ The power windows can be operated when ...
Page 201 If you release the switch while the window is moving, start again from the beginning. If the window continues to close but then re-open slightly even after perform- ing the above procedure correctly, have the vehicle inspected by your Toyota dealer. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 202 3-5. Opening and closing the windows and moon roof WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ Closing the windows The driver is responsible for all the power window operations, including the ●...
Page 203: Moon Roof
3-5. Opening and closing the windows and moon roof  Moon roof Use the overhead switches to open and close the moon roof and tilt it up and down. Opening and closing Opens the moon roof The moon roof stops slightly before the fully open position to reduce wind noise.
Page 204 3-5. Opening and closing the windows and moon roof ■ The moon roof can be operated when The engine switch is in IGNITION ON mode. ■ Jam protection function If an object is detected between the moon roof and the frame while closing or tilting down, travel is stopped and the moon roof opens slightly.
Page 205 3-5. Opening and closing the windows and moon roof WARNING Observe the following precautions. Failing to do so may cause death or serious injury. ■ Opening the moon roof Do not allow any passengers to put their hands or heads outside the vehi- ●...
Page 206 (vehicles with a smart 4-5. Using the driving support entry & start system)..223 systems Continuously variable Cruise control.....275 transmission Toyota parking (except for Thailand)..232 assist-sensor ....279 Continuously variable Stop & Start system ...288 transmission Driving assist systems ..296 (for Thailand) ....240 4-6.
Page 207: Driving The Vehicle
4-1. Before driving Driving the vehicle The following procedures should be observed to ensure safe driving: Starting the engine P. 220, 223 Driving  Continuously variable transmission With the brake pedal depressed, shift the shift lever to D. (P. 232, 240) Release the parking brake.
Page 208 4-1. Before driving Parking the vehicle  Continuously variable transmission With the shift lever in D, depress the brake pedal. Set the parking brake (P. 249), and shift the shift lever to P (P. 232, 240). Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK”...
Page 209 4-1. Before driving Starting off on a steep uphill  Continuously variable transmission Firmly set the parking brake with the brake pedal depressed, and then shift the shift lever to D. Release the brake pedal and gently depress the accelerator pedal. Release the parking brake.
Page 210 Restraining the engine output (Brake Override System) When the accelerator and brake pedals are depressed at the same time, the engine output may be restrained. Breaking in your new Toyota ■ To extend the life of the vehicle, observing the following precautions is recom-...
Page 211 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When starting the vehicle (vehicles with a continuously variable trans- mission) Always keep your foot on the brake pedal while stopped with the engine running.
Page 212 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When driving on slippery road surfaces Sudden braking, acceleration and steering may cause tire slippage and ● reduce your ability to control the vehicle. Sudden acceleration, engine braking due to shifting, or changes in engine ●...
Page 213 ■ If you hear a squealing or scraping noise (brake pad wear indicators) Have the brake pads checked and replaced by your Toyota dealer as soon as possible. Rotor damage may result if the pads are not replaced when needed.
Page 214 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When the vehicle is parked Do not leave glasses, cigarette lighters, spray cans, or soft drink cans in ● the vehicle when it is in the sun. Doing so may result in the following: •...
Page 215 4-1. Before driving WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ When taking a nap in the vehicle Always turn the engine off. Otherwise, if you accidentally move the shift lever or depress the accelerator pedal, this could cause an accident or fire due to engine overheating.
Page 216 4-1. Before driving NOTICE When driving the vehicle ■  Vehicles with a continuously variable transmission ● Do not depress the accelerator and brake pedals at the same time during driving, as this may restrain engine output. Do not use the accelerator pedal or depress the accelerator and brake ●...
Page 217 Short in electrical components Engine damage caused by water immersion ● In the event that you drive on a flooded road and the vehicle is flooded, be sure to have your Toyota dealer check the following: Brake function ● ●...
Page 218: Cargo And Luggage
4-1. Before driving Cargo and luggage Take notice of the following information about storage precau- tions, cargo capacity and load: WARNING ■ Things that must not be carried in the trunk The following things may cause a fire if loaded in the trunk: Receptacles containing gasoline ●...
Page 219 4-1. Before driving WARNING Load and distribution ■ ● Do not overload your vehicle. ● Do not apply loads unevenly. Improper loading may cause deterioration of steering or braking control which may cause death or serious injury. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 220: Trailer Towing
Trailer towing Toyota does not recommend towing a trailer with your vehicle. Toyota also does not recommend the installation of a tow hitch or the use of a tow hitch carrier for a wheelchair, scooter, bicy- cle, etc. Your vehicle is not designed for trailer towing or for the use of tow hitch mounted carriers.
Page 221: Engine (Ignition) Switch
4-2. Driving procedures Engine (ignition) switch (vehicles without a smart entry & start system) Starting the engine Check that the parking brake is set. Check that the shift lever is set in P (continuously variable transmis- sion) or N (manual transmission). ...
Page 222 ■ If the engine does not start (vehicles with an engine immobilizer system) The engine immobilizer system may not have been deactivated. (P. 115) Contact your Toyota dealer. ■ When the steering lock cannot be released When starting the engine, the engine switch may seem stuck in the “LOCK”...
Page 223 Do not crank the engine for more than 30 seconds at a time. This may ● overheat the starter and wiring system. ● Do not race a cold engine. If the engine becomes difficult to start or stalls frequently, have your vehi- ● cle checked by your Toyota dealer immediately. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 224: Continuously Variable
4-2. Driving procedures Engine (ignition) switch (vehicles with a smart entry & start system) Performing the following operations when carrying the elec- tronic key on your person starts the engine or changes engine switch mode. Starting the engine Check that the parking brake is set. Check that the shift lever is set in P (continuously variable transmis- sion) or N.
Page 225 4-2. Driving procedures  Vehicles with a multi-information display Firmly depress the brake pedal (continuously variable transmis- sion) or clutch pedal (manual transmission). and message will be displayed on the multi-information display. If it is not displayed, the engine cannot be started. Press the engine switch shortly and firmly.
Page 226 4-2. Driving procedures Stopping the engine  Continuously variable transmission Stop the vehicle. Set the parking brake (P. 249), and shift the shift lever to P. Press the engine switch. Vehicles with drive monitor display: Release the brake pedal and check that the smart entry &...
Page 227 4-2. Driving procedures Changing engine switch modes Modes can be changed by pressing the engine switch with brake pedal (continuously variable transmission) or clutch pedal (manual transmission) released. (The mode changes each time the switch is pressed.)  Vehicles with a drive monitor display The emergency flashers can be used.
Page 228 4-2. Driving procedures  Vehicles with a multi-information display The emergency flashers can be used. The multi-information display will not be displayed. ACCESSORY mode Some electrical components such as the audio system can be used. “ACCESSORY” will be displayed on the multi-information display. IGNITION ON mode All electrical components can be used.
Page 229 4-2. Driving procedures When stopping the engine with the shift lever in a position other than P (vehicles with a continuously variable transmission) If the engine is stopped with the shift lever in a position other than P, the engine switch will not be turned off but instead be turned to ACCESSORY mode.
Page 230 If the engine does not start The engine immobilizer system may not have been deactivated. (P. 115) ● Contact your Toyota dealer. ● Vehicles with a continuously variable transmission: Check that the shift lever is securely set in P or N. The engine may not start if the shift lever is dis- placed out of P or N.
Page 231 4-2. Driving procedures ■ If the system is malfunctioning P. 526, 535 If the electronic key battery is depleted ■ P. 479 Operation of the engine switch ■ If the switch is not pressed shortly and firmly, the engine switch mode may ●...
Page 232 ● ● If the engine becomes difficult to start or stalls frequently, have your vehi- cle checked by your Toyota dealer immediately. Symptoms indicating a malfunction with the engine switch ■ If the engine switch seems to be operating somewhat differently than usual, such as the switch sticking slightly, there may be a malfunction.
Page 233 4-2. Driving procedures Continuously variable transmission  (except for Thailand) Shifting the shift lever Vehicles without a smart entry & start system  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 234 4-2. Driving procedures Shift position purpose Shift position Function Parking the vehicle or starting the engine Reversing Neutral (Condition in which the power is not transmitted) Normal driving 7-speed sport sequential shiftmatic mode driving (P. 235) : To improve fuel consumption and reduce noises, set the shift lever in the D position for normal driving.
Page 235 4-2. Driving procedures Sport mode ■ Use sport mode for sporty driving or driving in mountainous regions. Press the “SPORT” button to select sport mode. The “SPORT” indicator light will come on. Press the button again to cancel sport mode. Temporally gear steps selection mode in the D position (vehicles with paddle shift switches) To drive in temporary gear steps selection mode, operate the “-”...
Page 236 4-2. Driving procedures Changing gear steps in the M position To enter 7-speed sport sequential shiftmatic mode, shift the lever to M. Gear steps can then be selected by operating the shift lever or paddle shift switches (if equipped), allowing you to drive in the gear step of your choosing.
Page 237 M This may indicate a malfunction in the continuously variable transmission system. Have the vehicle inspected by your Toyota dealer immediately. (In this situation, the transmission will operate in the same manner as when the shift lever is in D.)
Page 238 4-2. Driving procedures ■ Downshift restriction warning buzzer To help ensure safety and driving performance, downshifting operation may sometimes be restricted. In some circumstances, downshifting may not be possible even when the shift lever or shift switches (if equipped) switches are operated.
Page 239 If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 240 4-2. Driving procedures  Type B Set the parking brake. Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK” position. Vehicles with a smart entry & start system: Turn the engine switch off. Depress the brake pedal. Press the shift lock override button.
Page 241 4-2. Driving procedures Continuously variable transmission (for Thailand) Shifting the shift lever Vehicles without a smart entry & start system  While the engine switch is in the “ON” position, move the shift lever with the brake pedal depressed. When shifting the shift lever between P and D, make sure that the vehicle is completely stopped.
Page 242 4-2. Driving procedures Shift position purpose Shift position Function Parking the vehicle or starting the engine Reversing Neutral (Condition in which the power is not transmitted) Normal driving Engine braking Maximum engine braking : Shifting to the D position allows the system to select a gear suitable for the driving conditions.
Page 243 If the shift lever cannot be shifted with your foot on the brake pedal, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. The following steps may be used as an emergency measure to ensure that the shift lever can be shifted.
Page 244: Manual Transmission
4-2. Driving procedures  Manual transmission Shifting the shift lever 5-speed transmission  Fully depress the clutch pedal before operating the shift lever, and then release it slowly. If it is difficult to shift in reverse, shift the shift lever to N, release the clutch pedal momentarily, and then try again.
Page 245 4-2. Driving procedures  6-speed transmission Fully depress the clutch pedal before operating the shift lever, and then release it slowly. Shifting the shift lever to R (6-speed transmission) Shift the shift lever to R while lift- ing up the ring section. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 246 4-2. Driving procedures ■ Maximum allowable speeds Observe the following maximum allowable speeds in each gear when maxi- mum acceleration is necessary.  5-speed transmission km/h (mph) Shift position 2NR-FE 47 (29) 87 (54) 127 (79) 171 (106) engine Maximum speed 1NR-FE 48 (30)
Page 247 4-2. Driving procedures NOTICE To prevent damage to the transmission (6-speed transmission) ■ ● Do not shift the shift lever to R without depressing the clutch pedal. ● Do not lift up the ring section except when shifting the lever to R. ●...
Page 248: Turn Signal Lever
4-2. Driving procedures Turn signal lever Operation instructions Left-hand drive vehicles  Right turn Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever. Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever.
Page 249 4-2. Driving procedures  Right-hand drive vehicles Left turn Lane change to the left (push and hold the lever partway) The left hand signals will flash until you release the lever. Lane change to the right (push and hold the lever partway) The right hand signals will flash until you release the lever.
Page 250: Parking Brake
4-2. Driving procedures Parking brake Operation instructions To set the parking brake, fully pull the parking brake lever while depressing the brake pedal. To release the parking brake, slightly raise the lever and lower it completely while press- ing the button. ■...
Page 251: Headlight Switch
4-3. Operating the lights and wipers Headlight switch The headlights can be operated manually. Operation instructions Operating the switch turns on the lights as follows:  Type A Vehicles without daytime running light system: Off Vehicles with daytime running light system: The daytime running lights...
Page 252 4-3. Operating the lights and wipers  Type B The headlights, daytime running lights (if equipped) (P. 256) and all the lights listed below turn on and off automatically. (When the engine switch is in the “ON” position [vehi- cles without a smart entry &...
Page 253 4-3. Operating the lights and wipers  Type C The front position, tail, license plate and instru- ment panel lights turn on. The headlights and all lights listed above turn on. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 254 4-3. Operating the lights and wipers  Type D The headlights, daytime running lights (if equipped) (P. 256) and all the lights listed below turn on and off automatically. (When the engine switch is in the “ON” position [vehi- cles without a smart entry &...
Page 255 4-3. Operating the lights and wipers Follow me home system (if equipped) This system allows the headlights to be turned on for 30 seconds when the engine switch is turned off. Pull the lever toward you and release it with the light switch in after turning the engine switch off.
Page 256 4-3. Operating the lights and wipers Manual headlight leveling dial (if equipped) The level of the headlights can be adjusted according to the number of passengers and the loading condition of the vehicle. Raises the level of the head- lights Lowers the level of the head- lights Guide to dial settings...
Page 257 4-3. Operating the lights and wipers ■ Daytime running light system (if equipped) To make your vehicle more visible to other drivers during daytime driving, the daytime running lights turn on automatically whenever the engine is started and the parking brake is released with the headlight switch to Daytime running lights are not designed for use at night.
Page 258 4-3. Operating the lights and wipers ■ Battery-saving function (vehicles with a power door lock system) In all conditions following below, the headlights and the other remaining lights will go off automatically after 20 minutes in order to prevent the vehicle bat- tery from being discharged: ●...
Page 259: Fog Light Switch
4-3. Operating the lights and wipers  Fog light switch The fog lights secure excellent visibility in difficult driving con- ditions, such as in rain and fog. Operation instructions Front fog light switch ■ Type A  Turns the front fog lights Turns the front fog lights ...
Page 260 4-3. Operating the lights and wipers  Type B Turns the front fog lights Turns the front fog lights Rear fog light switch ■  Type A Turns the rear fog light Turns the rear fog light On some models: Releasing the switch ring returns it to Operating the switch ring again turns only the rear fog...
Page 261 4-3. Operating the lights and wipers  Type B Turns the rear fog light Turns the rear fog light Releasing the switch ring returns it to Operating the switch ring again turns only the rear fog lights off. Front and rear fog light switch ■...
Page 262 4-3. Operating the lights and wipers  Type B Turns the front and rear fog lights off Turns the front fog lights Turns both front and rear fog lights on Releasing the switch ring returns it to Operating the switch ring again turns only the rear fog lights off.
Page 263: Windshield Wipers And Washer
4-3. Operating the lights and wipers Windshield wipers and washer Operating the wiper lever Operating the lever operates the wipers or washer as follows. Without intermittent windshield wipers ■ Type A  Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer operation...
Page 264 4-3. Operating the lights and wipers  Type B Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer operation Pulling the lever operates the washer. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 265 4-3. Operating the lights and wipers Intermittent windshield wipers ■ Type A  Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation Temporary operation Washer/wiper dual operation Pulling the lever operates the wipers and washer. Wipers will automatically oper- ate a couple of times after the washer squirts.
Page 266 4-3. Operating the lights and wipers Interval adjustment type only: Wiper intervals can be adjusted when intermittent operation is selected. Increases intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Type B  Intermittent windshield wiper operation Low speed windshield wiper operation High speed windshield wiper operation...
Page 267 4-3. Operating the lights and wipers Interval adjustment type only: Wiper intervals can be adjusted when intermittent operation is selected. Increases intermittent windshield wiper frequency Decreases the intermittent windshield wiper frequency Rain-sensing windshield wipers ■ When is selected, the wiper will operate automatically when the sensor detects falling rain.
Page 268 4-3. Operating the lights and wipers Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation Pulling the lever operates the wipers and washer. The wiper will automatically operate a couple of times after the washer squirts. (After operating several times, the wiper operate one more time after a short delay to prevent dripping.)
Page 269 4-3. Operating the lights and wipers Increases the sensitivity Decreases the sensitivity Washer/wiper dual operation Pulling the lever operates the wipers and washer. The wiper will automatically operate a couple of times after the washer squirts. (After operating several times, the wiper operate one more time after a short delay to prevent dripping.)
Page 270 4-3. Operating the lights and wipers ■ The windshield wipers and washer can be operated when  Vehicles without a smart entry & start system The engine switch is in the “ON” position.  Vehicles with a smart entry & start system The engine switch is in IGNITION ON mode.
Page 271 Damage to the washer fluid pump may be caused if the lever is pulled toward you and held continually. When a nozzle becomes blocked ■ In this case, contact your Toyota dealer. Do not try to clear it with a pin or other object. The nozzle will be damaged. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 272: Opening The Fuel Tank Cap
4-4. Refueling Opening the fuel tank cap Perform the following steps to open the fuel tank cap: Before refueling the vehicle ● Vehicles without a smart entry & start system: Turn the engine switch to the “LOCK” position and ensure that all the doors and windows are closed.
Page 273 4-4. Refueling WARNING When refueling the vehicle ■ Observe the following precautions while refueling the vehicle. Failure to do so may result in death or serious injury. After exiting the vehicle and before opening the fuel door, touch an ● unpainted metal surface to discharge any static electricity.
Page 274 4-4. Refueling NOTICE Refueling ■ ● Do not spill fuel during refueling. Doing so may damage the vehicle, such as causing the emission control system to operate abnormally, or damaging fuel system components or the vehicle’s painted surface. 2NR-FBE engine only: Fill the fuel tank with a full tank of gasoline at least ●...
Page 275 WARNING ■ When replacing the fuel tank cap Do not use anything but a genuine Toyota fuel tank cap designed for your vehicle. Doing so may cause a fire or other incident which may result in death or serious injury.
Page 276 4-5. Using the driving support systems  Cruise control Summary of functions Use the cruise control to maintain a set speed without depressing the accelerator pedal. Indicators Cruise control switch Setting the vehicle speed Press the “ON-OFF” button to activate the cruise control. Cruise control indicator will come Press the button again to deacti- vate the cruise control.
Page 277 4-5. Using the driving support systems Adjusting the set speed To change the set speed, operate the lever until the desired set speed is obtained. Increases the speed Decreases the speed Fine adjustment: Momentarily move the lever in the desired direc- tion.
Page 278 If the cruise control speed cannot be set or if the cruise control cancels imme- diately after being activated, there may be a malfunction in the cruise control system. Have the vehicle inspected by your Toyota dealer. If “Cruise Control Malfunction Visit Your Dealer” is displayed on the ■...
Page 279 4-5. Using the driving support systems WARNING To avoid operating the cruise control by mistake ■ Switch the cruise control off using the “ON-OFF” button when not in use. ■ Situations unsuitable for cruise control Do not use cruise control in any of the following situations. Doing so may result in loss of control and could cause an accident resulting in death or serious injury.
Page 280: Toyota Parking Assist-Sensor
4-5. Using the driving support systems  Toyota parking assist-sensor The Toyota parking assist-sensor is a supplemental device to assist the driver when parking. The distance from your vehicle to nearby obstacles when parallel parking or maneuvering into a garage is measured by the sensors and communicated via a buzzer.
Page 281 4-5. Using the driving support systems Toyota parking assist-sensor switch Turn Toyota parking assist-sensor On/off When on, the indicator light comes on to inform the driver that the sys- tem is operational. Display (6 sensor models) When the sensors detect an obstacle, a graphic is shown on the multi- information display depending on the position and distance to the obstacle.
Page 282 4-5. Using the driving support systems The distance display and buzzer When a sensor detects an obstacle, the direction of and the approxi- mate distance to the obstacle are displayed and the buzzer sounds. The volume and timing of the buzzer can be changed. (P. 615) Front corner sensors (6 sensor models) ■...
Page 283 4-5. Using the driving support systems Rear corner sensors (6 sensor models) ■ Approximate distance to Multi-information Buzzer obstacle display 60 to 45 cm Intermittent (2.0 to 1.5 ft.) 45 to 35 cm Fast intermittent (1.5 to 1.1 ft.) Less than 35 cm Continuous (1.1 ft.) VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 284 4-5. Using the driving support systems Rear center sensors ■ Approximate distance to Multi-information Buzzer obstacle display 150 to 65 cm Intermittent (4.9 to 2.1 ft.) 65 to 50 cm Fast intermittent (2.1 to 1.6 ft.) 50 to 40 cm Very fast intermittent (1.6 to 1.3 ft.) Less than 40 cm...
Page 285 ■ The Toyota parking assist-sensor can be operated when Vehicles without a smart entry & start system: The engine switch is in the “ON” position. Vehicles with a smart entry & start system: The engine switch is in IGNITION ON mode.
Page 286 • There is ice, snow or mud on a sensor. • A sensor is frozen. If the sensor is deiced, the Toyota parking assist-sen- sor will work properly. • A sensor is covered with something.
Page 287 When the system malfunctions If the buzzer sounds when there is no obstacle, clean the sensors with soft cloth. If the buzzer does not stop after cleaning the sensor, contact your Toyota dealer. ■ Customization (6 sensor models only) Setting of buzzer volume and sensor sensitivity can be changed.
Page 288 When using Toyota parking assist-sensor ■ In the following situations, the system may not function correctly due to a sensor malfunction etc. Have the vehicle checked by your Toyota dealer. If the buzzer sounds when there is no obstacle around the vehicle. ●...
Page 289: Stop & Start System
4-5. Using the driving support systems  Stop & Start system The Stop & Start system stops and starts the engine according to brake pedal or shift lever operation when the vehicle is stopped, such as at a stoplight, intersection, etc., in order to improve fuel economy and reduce noise pollution caused by the engine idling.
Page 290 ● Installation and removal of electrical components and wireless devices may affect the Stop & Start system. Contact your Toyota dealer for details. When stopping the vehicle for a longer period of time, turn the engine switch ● off to stop the engine completely.
Page 291 4-5. Using the driving support systems ● In the following situations the engine may not be stopped by the Stop & Start system. This is not a malfunction of the Stop & Start system. • When the air conditioning system is being used. •...
Page 292 4-5. Using the driving support systems ■ When the hood is opened If the hood is opened while the engine is stopped by the Stop & Start sys- ● tem, the engine will stall and will not be able to be restarted by the automatic engine start function.
Page 293 A battery not designed for use with a Stop & Start “Non-Dedicated system may have been installed.  Have the vehicle inspected by your Toyota Battery” dealer. • The battery charge may be low.  Stopping of the engine is temporarily prohib- ited to prioritize charging of the battery.
Page 294 4-5. Using the driving support systems Message Details/Actions • The air conditioning system has been turned on or “For Climate Con- is being used. trol” • The windshield defogger has been turned on. When the engine automatically restarts while stopped by the Stop & Start ●...
Page 295 ■ If the Stop & Start cancel indicator flashes continuously The system may be malfunctioning. Have the vehicle inspected by your Toyota dealer. ■ If “Stop & Start System Malfunction Visit Your Dealer” is displayed on the multi-information display (if equipped) The system may be malfunctioning.
Page 296 To ensure the system operates correctly If any of the following situations occur, the Stop & Start system may not operate correctly. Have your vehicle inspected by your Toyota dealer. While the driver’s seat belt is fastened, the driver’s and front passenger’s ●...
Page 297: Driving Assist Systems
4-5. Using the driving support systems Driving assist systems To keep driving safety and performance, the following systems operate automatically in response to various driving situations. Be aware, however, that these systems are supplementary and should not be relied upon too heavily when operating the vehi- cle.
Page 298 4-5. Using the driving support systems When the TRC/VSC systems are operating The slip indicator light will flash while the TRC/VSC systems are operating. Disabling the TRC system If the vehicle gets stuck in mud, dirt or snow, the TRC system may reduce power from the engine to the wheels.
Page 299 ■ pressed (vehicles with a drive monitor display) TRC is temporary deactivated. If the indicator light continues to remain on, contact your Toyota dealer. When the message is displayed on the multi-information display show- ■ ing that TRC has been disabled even if...
Page 300 4-5. Using the driving support systems ■ Automatic system cancelation of hill-start assist control The hill-start assist control will turn off in any of the following situations: Vehicles with a continuously variable transmission: The shift lever is shifted ● to P or N. ●...
Page 301 4-5. Using the driving support systems ■ Reduced effectiveness of the EPS system The effectiveness of the EPS system is reduced to prevent the system from overheating when there is frequent steering input over an extended period of time. The steering wheel may feel heavy as a result. Should this occur, refrain from excessive steering input or stop the vehicle and turn the engine off.
Page 302 The ABS, TRC and VSC systems will not function correctly if different tires are installed on the vehicle. Contact your Toyota dealer for further information when replacing tires or wheels. ■ Handling of tires and the suspension Using tires with any kind of problem or modifying the suspension will affect the driving assist systems, and may cause a system to malfunction.
Page 303: Driving Tips Winter Driving Tips
4-6. Driving tips Winter driving tips Carry out the necessary preparations and inspections before driving the vehicle in winter. Always drive the vehicle in a man- ner appropriate to the prevailing weather conditions. Preparation for winter ● Use fluids that are appropriate to the prevailing outside tempera- tures.
Page 304 If the shift lever can be shifted from P, there may be a problem with the shift lock system. Have the vehicle inspected by your Toyota dealer immediately. Selecting tire chains Use the correct tire chain size when mounting the tire chains.
Page 305 4-6. Driving tips  Vehicles with 175/65R14 or 185/60R15 tires : Tire chains cannot be mounted on the spare tire of a different size from the installed tires. When the installing tire chains: P. 566 Side chain: 3 mm (0.12 in.) in diameter 10 mm (0.39 in.) in width 30 mm (1.18 in.) in length Cross chain:...
Page 306 Repairing or replacing snow tires (vehicles with the tire pressure warn- ■ ing system) Request repairs or replacement of snow tires from Toyota dealers or legiti- mate tire retailers. This is because the removal and attachment of snow tires affects the opera- tion of the tire pressure warning valves and transmitters.
Page 307: Eco-Friendly Driving Tips
4-6. Driving tips Eco-friendly driving tips For improved fuel economy and reduced CO2 emissions, pay attention to the following points: ◆ Using Eco drive mode (vehicles with an “ECO MODE” button) When using Eco drive mode, the torque corresponding to the acceler- ator pedal depression amount can be generated more smoothly than it is in normal conditions.
Page 308 4-6. Driving tips ◆ When braking Observe conditions in front of and around the vehicle, and estimate your stopping position. Release the accelerator pedal early and con- tinue coasting. Use the brake pedal to adjust your stopping position. Make sure to operate the brake pedal gently. ◆...
Page 309 4-6. Driving tips ◆ Performing idling stops ● Avoid unnecessary idling. Stop the engine when parking the vehicle to reduce excessive fuel consumption, even it is only for a short period of time. ● Except in severe environment, such as when the outside tempera- ture is extremely low, warming up the engine before driving is unnecessary.
Page 310 Audio system ® 5-1. Basic Operations 5-6. Using Bluetooth devices ® Audio system types ...310 Bluetooth audio/phone..347 Steering wheel audio Using the steering switches......313 wheel switches ....353 ® AUX port/USB port ....316 Registering a Bluetooth device ......354 5-2. Using the audio system 5-7.
Page 311: Audio System Types
5-1. Basic Operations  Audio system types  Type A  : If equipped VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 312 5-1. Basic Operations  Type B This illustration is for a left-hand drive vehicle. Depending on the des- tination, some button positions are reversed and screen display items are changed for right-hand drive vehicles. ■ Using cellular phones Interference may be heard through the audio system’s speakers if a cellular phone is being used inside or close to the vehicle while the audio system is operating.
Page 313 5-1. Basic Operations NOTICE To prevent battery discharge ■ Do not leave the audio system on longer than necessary when the engine is stopped. To avoid damaging the audio system ■ Take care not to spill drinks or other fluids over the audio system. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 314: Steering Wheel Audio Switches
5-1. Basic Operations  Steering wheel audio switches Some audio features can be controlled using the switches on the steering wheel. Operation may differ depending on the type of audio system. For details, refer to the manual provided with the audio system. Operating the audio system using the steering wheel switches Type A Type B...
Page 315 5-1. Basic Operations Turning on the power Press the “MODE” switch when the audio system is turned off. Changing the audio source Press the “MODE” switch when the audio system is turned on. The audio source changes as follows each time the button is pressed. If a mode cannot be used, it will be skipped.
Page 316 5-1. Basic Operations Selecting a track/file or song ® Press the “MODE” switch to select the CD, Bluetooth audio, iPod or USB memory mode. Press the “” or “” switch to select the desired track/file or song. Selecting an album ®...
Page 317: Aux Port/Usb Port
5-1. Basic Operations  AUX port/USB port Connect an iPod, USB memory device or portable audio player to the AUX port/USB port as indicated below. Press the “MODE” button to select “iPod”, “USB” or “AUX”. Connecting using the AUX port/USB port ●...
Page 318: Optimal Use Of The Audio System
5-2. Using the audio system  Optimal use of the audio system The sound quality, volume balance and ASL settings can be adjusted. Displays the “SETUP” menu/ Selecting the mode Changes the following settings • Sound quality and volume balance P.
Page 319 5-2. Using the audio system Adjusting sound quality ■ Pressing the “TUNE >” or “< SELECT” button adjusts the level. Turn to the Turn to the Sound Mode Level Press the Press the quality mode displayed “< SELECT” “TUNE >” Bass “BASS”...
Page 320 5-3. Using the radio  Radio operation Press the “MODE” button until “AM” or “FM” is displayed.  Type A Power Adjusting the frequency Volume Seeking the frequency AM/FM mode button Station selectors  : If equipped VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 321 5-3. Using the radio  Type B Power AM/FM mode button Volume Adjusting the frequency Seeking the frequency Station selectors VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 322 5-3. Using the radio Setting station presets Search for the desired stations by pressing the “TUNE >”, “< SELECT”, “SEEK >” or “< TRACK” button. Press and hold one of the station selectors ( to be set until you hear a beep. When the battery is disconnected ■...
Page 323: Mp3/Wma Discs Cd Player Operation
5-4. Playing audio CDs and MP3/WMA discs  CD player operation Insert a disc, press the “MODE” button to begin listening to a Type A  Disc eject Selecting a track, fast forward- ing or rewinding Power Random play or back button Volume Repeat play Changing the audio source/...
Page 324 5-4. Playing audio CDs and MP3/WMA discs  Type B Disc eject Moving the cursor to select a desired item from the list Power Selecting a folder Volume Random play or back button Selecting a track, fast forward- ing or rewinding Repeat play Changing the audio source/ Displaying track list...
Page 325 5-4. Playing audio CDs and MP3/WMA discs Loading CDs or MP3 and WMA discs Insert a disc. Ejecting CDs or MP3 and WMA discs Press and remove the disc. Using the CD player Selecting a track ■ Press the “SEEK >” or “< TRACK” button to move up or down until the desired track number is displayed.
Page 326 5-4. Playing audio CDs and MP3/WMA discs Playing back MP3 and WMA discs Selecting folders one at a time ■ Press (“<FOLDER”) or (“FOLDER>”) or the “<FOLDER” or “FOLDER>” button to select the desired folder. Selecting a folder and file from folder list ■...
Page 327 Wait for a while and then “WAIT” press the “MODE” button. If the CD still cannot be played back, contact your Toyota dealer. This indicates that the MP3/WMA file is not “NO SUPPORT” included in the CD.
Page 328 5-4. Playing audio CDs and MP3/WMA discs ■ CD player protection feature To protect the internal components, playback is automatically stopped when a problem is detected while the CD player is being used. If a CD is left inside the CD player or in the ejected position for extended ■...
Page 329 5-4. Playing audio CDs and MP3/WMA discs ● Compatible media Media that can be used for MP3 and WMA playback are CD-Rs and CD-RWs. Playback in some instances may not be possible, depending on the status of the CD-R or CD-RW. Playback may not be possible or the audio may jump if the disc is scratched or marked with fingerprints.
Page 330 5-4. Playing audio CDs and MP3/WMA discs ● MP3 and WMA playback When a disc containing MP3 or WMA files is inserted, all files on the disc are first checked. Once the file check is finished, the first MP3 or WMA file is played.
Page 331 5-4. Playing audio CDs and MP3/WMA discs NOTICE Discs and adapters that cannot be used ■ Do not use the following types of discs. Also, do not use 8 cm (3 in.) disc adapters, Dual Discs or printable discs. Doing so may damage the player and/or the disc insert/eject function. Discs that have a diameter that is not 12 cm (4.7 in.).
Page 332 5-5. Using an external device  Listening to an iPod Connecting an iPod enables you to enjoy music from the vehicle speakers. Connecting an iPod P. 316 Control panel  Type A Power Selecting a song, fast-forward- ing or rewinding Volume Random play or back button Changing the audio source/...
Page 333 5-5. Using an external device  Type B Power Moving the cursor to select a desired item from the list Volume Random play or back button Selecting a song, fast-forward- ing or rewinding Repeat play Changing the audio source/ iPod menu mode, playback playback Displaying song list Selecting an iPod menu/song...
Page 334 5-5. Using an external device Selecting a play mode Press (“MENU”) to select iPod menu mode. Pressing the “TUNE >” button changes the play mode in the follow- ing order: “Playlists”“Artists”“Albums”“Songs”“Podcasts”“Genres” “Composers”“Audiobooks” Press the “SETUP·ENTER” button to select the desired play mode. Play mode list ■...
Page 335 5-5. Using an external device Selecting a list ■ Press the “TUNE >” or “< SELECT” button to display the first selection list. Press the “SETUP·ENTER” button to select the desired item and display the second selection list. Repeat the same procedure to select the desired item. To return to the previous selection list, press (“BACK”).
Page 336 5-5. Using an external device Random play Pressing (“RDM”) changes modes in the following order: Track random  Album random  Off. Switching the display Press (“TEXT”) to display or hide the album title. If there are continuing texts, is displayed. Press and hold (“TEXT”) to display the remaining texts.
Page 337 ■ If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the iPod or its “ERROR”...
Page 338 5-5. Using an external device ■ Compatible models ® ® ® ® ® The following iPod , iPod nano , iPod classic , iPod touch and iPhone devices can be used with this system. Made for ● • iPod (5th generation) •...
Page 339 5-5. Using an external device WARNING While driving ■ Do not connect iPod or operate the controls. Doing so may cause an accident, resulting in death or serious injury. NOTICE ■ To prevent damage to iPod ● Do not leave iPod in the vehicle. The temperature inside the vehicle may become high, resulting in damage to the iPod.
Page 340: Listening To A Usb Memory Device
5-5. Using an external device  Listening to a USB memory device Connecting a USB memory enables you to enjoy music from the vehicle speakers. Connecting a USB memory P. 316 Control panel  Type A Power Selecting a file, fast-forward- ing or rewinding Volume Random play or back button...
Page 341 5-5. Using an external device  Type B Power Moving the cursor to select a desired item from the list Volume Selecting a folder Selecting a file, fast-forwarding or rewinding Random play or back button Changing the audio source/ Repeat play playback Displaying folder list Selecting a file or folder from...
Page 342 5-5. Using an external device Selecting a folder Selecting folders one at a time ■ Press (“<FOLDER”) or (“FOLDER>”) or the “<FOLDER” or “FOLDER>” button to select the desired folder. Selecting a folder and file from folder list ■ Press (“LIST”).
Page 343 Error messages If an error message is displayed, refer to the following table and take the appropriate measures. If the problem is not rectified, take the vehicle to your Toyota dealer. Message Cause/Correction procedures This indicates a problem in the USB memory “ERROR”...
Page 344 5-5. Using an external device ■ USB memory Compatible devices ● USB memory that can be used for MP3 and WMA playback ● Compatible device formats The following device formats can be used: • USB communication formats: USB2.0 FS (12 mbps) •...
Page 345 5-5. Using an external device ● WMA file compatibility • Compatible standards WMA Ver. 7, 8, 9 • Compatible sampling frequencies 32, 44.1, 48 (kHz) • Compatible bit rates (only compatible with 2-channel playback) Ver. 7, 8: CBR 48—192 (kbps) Ver.
Page 346 5-5. Using an external device ● Extensions If the file extensions .mp3 and .wma are used for files other than MP3 and WMA files, they will be skipped (not played). ● Playback • To play MP3 files with steady sound quality, we recommend a fixed bit rate of at least 128 kbps and a sampling frequency of 44.1 kHz.
Page 347: Using The Aux Port
5-5. Using an external device  Using the AUX port This port can be used to connect a portable audio device and lis- ten to it using the vehicle’s speakers. Connecting a portable player P. 316 ■ Operating portable audio devices connected to the audio system The volume can be adjusted using the vehicle’s audio controls.
Page 348 ® 5-6. Using Bluetooth devices  ® Bluetooth audio/phone ® The following can be performed using Bluetooth wireless com- munication: ® ◆ Bluetooth audio ® The Bluetooth audio system enables you to enjoy music played on a portable digital audio player (portable player) from the vehicle speakers via wireless communication.
Page 349 ® 5-6. Using Bluetooth devices Device registration/connection flow ® 1. Register the Bluetooth device to be used with audio system (P. 354) ® 2. Connect the registered Bluetooth device to be used (P. 355, 357) 3. Set automatic connection of the device (P.
Page 350 ® 5-6. Using Bluetooth devices Audio unit ® Bluetooth connection condi- tion If “BT” is not displayed, the ® Bluetooth audio/phone cannot be used. Display A message, name, number, etc., is displayed. Lower-case characters and special characters may not be displayed. “SETUP·ENTER”...
Page 351 ® 5-6. Using Bluetooth devices Microphone You can use the microphone when talking on the phone. The person you are speaking to can be heard from the speakers. To use the hands-free system, you ® must register your Bluetooth phone in the system. (P. 354) VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 352 ® 5-6. Using Bluetooth devices ® Menu list of the Bluetooth audio/phone First menu Second menu Third menu Operation details Registering “Pairing” ® Bluetooth device Listing the regis- “List phone” tered cellular phones Listing the regis- “List audio” tered portable players Changing “Passkey”...
Page 353 ® 5-6. Using Bluetooth devices First menu Second menu Third menu Operation details Adding a new num- “Add contacts” Registering a speed “Add SD” dial Deleting a number “Delete call stored in the call his- “Phonebook” history” tory Deleting a number “Delete contacts”...
Page 354: Using The Steering Wheel Switches
® 5-6. Using Bluetooth devices  Using the steering wheel switches The steering wheel switches can be used to operate a connected cellular phone, or portable digital audio player (portable player). ® Operating Bluetooth phone using the steering wheel switches ...
Page 355 ® 5-6. Using Bluetooth devices  ® Registering a Bluetooth device ® Before using the Bluetooth audio/phone, it is necessary to reg- ® ister a Bluetooth device in the system. Follow the procedure below to register (pair) a device: ® How to register a Bluetooth device Press the “SETUP·ENTER”...
Page 356: Using The "Setup" Menu
5-7. “SETUP” menu Using the “SETUP” menu (“Bluetooth*”  menu) ® Registering a Bluetooth device in the system allows the system to function. The following functions can be used for registered devices: Functions and operation procedures Press the “SETUP·ENTER” button. Select “Bluetooth*”...
Page 357 5-7. “SETUP” menu ® Registering a Bluetooth device ® Register the Bluetooth device to be used with audio system (P. 354) ® ● If a Bluetooth device is not connected currently ® Perform the procedure for registering a Bluetooth device from step .
Page 358 5-7. “SETUP” menu ● Disconnecting the registered cellular phone from the audio system Select the name of the cellular phone to be disconnected using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. Select “Disconnect” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER”...
Page 359 5-7. “SETUP” menu ● Disconnecting the registered portable player from the audio system Select the name of the portable player to be disconnected using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. Select “Disconnect” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER”...
Page 360 5-7. “SETUP” menu Setting automatic connection of the device on or off If “BT power” is set to on, the registered device will be connected automatically when the engine switch is turned to the “ACC” position (vehicles without a smart entry & start system) or ACCESSORY mode (vehicles with a smart entry &...
Page 361 5-7. “SETUP” menu Initialization Select “Initialize” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. ● Initializing the sound settings Select “Sound setting” using the “TUNE >” or “< SELECT” button and press (“YES”). For details about sound settings: P. 317 ●...
Page 362 5-7. “SETUP” menu Using the “SETUP” menu (“PHONE” or  “TEL” menu) Functions and operation procedures To enter the menu for each function, press the “SETUP·ENTER” but- ton and follow the steps below using the “TUNE >” or “< SELECT” but- ton: ●...
Page 363 5-7. “SETUP” menu Adding a new phone number Select “Add contacts” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. ● Transferring all contacts from the cellular phone Select “Overwrite all” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER”...
Page 364 5-7. “SETUP” menu ● Deleting incoming call history Select “Incoming calls” using the “TUNE >” or “< SELECT” but- ton, and press the “SETUP·ENTER” button. Select the desired phone number using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. Press (“YES”).
Page 365 5-7. “SETUP” menu Deleting a registered phone number Select “Delete contacts” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. Select the desired phone number using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. Press (“YES”).
Page 366 5-7. “SETUP” menu Setting call volume Select “Call volume” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. Change the call volume. To decrease the volume: Press the “< SELECT” button. To increase the volume: Press the “TUNE >” button. To set the volume, press (“BACK”).
Page 367 5-7. “SETUP” menu ■ Phone number Up to 1000 names can be stored. ■ Call history Up to 10 numbers can be stored in each of the outgoing, incoming and missed call history memories. Limitation of number of digits ■ A phone number that exceeds 24 digits cannot be registered.
Page 368 ® 5-8. Bluetooth Audio ® Operating a Bluetooth enabled portable  player Power Random play or back button Volume Repeat play Changing the audio source/ Selecting an album playback Playback/pause Selecting a track, fast-forward- Displaying text message ing or rewinding ...
Page 369 ® 5-8. Bluetooth Audio Selecting an album Press (“<FOLDER”) or (“FOLDER>”) to select desired album. Selecting a track Press the “SEEK >” or “< TRACK” button to select the desired track. Fast-forwarding and rewinding tracks Press and hold the “SEEK >” or “< TRACK” button. Repeat play Pressing (“RPT”) changes modes in the following order:...
Page 370 ® 5-8. Bluetooth Audio Playing and pausing tracks Press Switching the display Press (“TEXT”) to display or hide the album title. If there are continuing texts, is displayed. Press and hold the button to display the remaining texts. ® Bluetooth audio system functions ■...
Page 371 ® 5-9. Bluetooth Phone  Making a phone call To enter the “PHONE” or “TEL” mode, press the off-hook switch. Dialing by selecting a name Select “Phonebook” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. Select the desired name using the “TUNE >”...
Page 372 ® 5-9. Bluetooth Phone Dialing from call histories Select “All calls”, “Missed calls”, “Incoming calls” or “Outgoing calls” using the “TUNE >” or “< SELECT” button, and press the “SETUP·ENTER” button. Select a desired number using the “TUNE >” or “< SELECT” button, and press the off-hook switch.
Page 373: Receiving A Phone Call
® 5-9. Bluetooth Phone  Receiving a phone call Answering the phone Press the off-hook switch. Refusing the call Press the on-hook switch. Receiving a call when on another call Press the off-hook switch. Pressing the off-hook switch again returns you to the previous call. Adjusting the ring tone volume when receiving a call To decrease the volume: Press the “VOL -”...
Page 374: Speaking On The Phone
® 5-9. Bluetooth Phone  Speaking on the phone Transferring a call A call can be transferred between the cellular phone and system while dialing, receiving a call, or during a call. Use one of the following methods: a. Operate the cellular phone. Refer to the manual that comes with the cellular phone for the operation of the phone.
Page 375 ® 5-9. Bluetooth Phone ■ When talking on the phone ● Do not talk simultaneously with the other party. ● Keep the volume of the received voice down. Otherwise, voice echo will increase. ■ Automatic volume adjustment When vehicle speed is 80 km/h (50 mph) or more, the volume automatically increases.
Page 376 ® 5-10. Bluetooth ® Bluetooth Conditions affecting operation ■ ® The Bluetooth audio/phone may not operate normally in the following situ- ● ations: ® • The portable player does not support Bluetooth • The cellular phone is located outside the service area ®...
Page 377: Bluetooth Bluetooth
® 5-10. Bluetooth ® ■ About Bluetooth ® Bluetooth is a registered trademark of Bluetooth SIG, Inc. ® The Bluetooth word mark and logos are registered trademarks owned Bluetooth SIG, Inc. and any use of such marks by Panasonic Corporation is under license.
Page 378 ® 5-10. Bluetooth ■ Certification for the audio system  For vehicles sold in the Dominican Republic  For vehicles sold in Jamaica  For vehicles sold in Taiwan VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 379 ® 5-10. Bluetooth  For vehicles sold in St. Maarten VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 380 ® 5-10. Bluetooth VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 381 ® 5-10. Bluetooth VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 382 ® 5-10. Bluetooth VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 383 ® 5-10. Bluetooth VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 384 ® 5-10. Bluetooth  For vehicles sold in Paraguay  For vehicles sold in Brazil WARNING Caution while driving ■ Observe the following precautions to avoid an accident that could result in death or serious injuries. ● Do not use a cellular phone. ®...
Page 385 ® 5-10. Bluetooth VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 386 Interior features 6-1. Using the air conditioning system and defogger Manual air conditioning system ......386 Automatic air conditioning system ......393 Air circulator.......401 6-2. Using the interior lights Interior lights list....403 • Interior light....405 • Personal lights....406 • Air circulator illumination ....407 6-3.
Page 387: System
6-1. Using the air conditioning system and defogger  Manual air conditioning system Air conditioning controls The illustration below is for left-hand drive vehicles. Some button posi- tions are reversed for right-hand drive vehicles. Vehicles without a heater  Vehicles with a heater ...
Page 388 6-1. Using the air conditioning system and defogger Adjusting the fan speed setting ■ To adjust the fan speed, turn the fan speed control dial the clockwise (increase) or the counterclockwise (decrease). Set the dial to “0” turns off the fan.
Page 389 6-1. Using the air conditioning system and defogger Changing the air flow mode ■ To select the air outlets, set the air outlet selector dial to the desired position. The positions between the air outlet selections can also be selected for more delicate adjustment.
Page 390 6-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time is pressed. Defogging the windshield (vehicle with a heater) ■...
Page 391 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected airflow mode. : Vehicles with a heater Adjusting the position of and opening and closing the air out- ■...
Page 392 6-1. Using the air conditioning system and defogger Fogging up of the windows ■ ● The windows will easily fog up when the humidity in the vehicle is high. Vehicles with a : Turning on will dehumidify the air from the out- lets and defog the windshield effectively.
Page 393 6-1. Using the air conditioning system and defogger WARNING To prevent the windshield from fogging up (vehicles with heater) ■ ● Do not set the air outlet selector dial to during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, blocking your vision.
Page 394: Automatic Air Conditioning System
6-1. Using the air conditioning system and defogger  Automatic air conditioning system Air outlets and fan speed are automatically adjusted according to the temperature setting. Air conditioning controls The illustration below is for left-hand drive vehicles. Some dial and button positions are reversed for right-hand drive vehicles.
Page 395 6-1. Using the air conditioning system and defogger Adjusting the fan speed setting ■ To adjust the fan speed, press “” on to increase the fan speed and “” on to decrease the fan speed. Press to turn the fan off. Adjusting the temperature setting ■...
Page 396 6-1. Using the air conditioning system and defogger  Vehicles with a heater To change the airflow mode, press outlets used switched each time the button is pressed. Air flows to the upper body Air flows to the upper body and feet Air flows to the feet Air flows to the feet and the windshield defogger operates...
Page 397 6-1. Using the air conditioning system and defogger Other functions Switching between outside air and recirculated air modes ■ Press The mode switches between outside air mode (indicator off) and recir- culated air mode (indicator on) each time is pressed. Defogging the windshield (vehicle with a heater) ■...
Page 398 6-1. Using the air conditioning system and defogger Air outlets Location of air outlets ■ The air outlets and air volume changes according selected airflow mode. : Vehicles with a heater Adjusting the position of and opening and closing the air out- ■...
Page 399 6-1. Using the air conditioning system and defogger ■ Using automatic mode Fan speed is adjusted automatically according to the temperature setting and the ambient conditions. Therefore, the fan may stop for a while until warm or cool air is ready to flow immediately after is pressed.
Page 400 6-1. Using the air conditioning system and defogger ■ When the outside temperature falls to nearly 0C (32F)  Vehicles without a heater The dehumidification function may not operate even when is pressed.  Vehicles with a heater The dehumidification function may not operate even when is pressed.
Page 401 6-1. Using the air conditioning system and defogger WARNING To prevent the windshield from fogging up (vehicles with a heater) ■ ● Do not use during cool air operation in extremely humid weather. The difference between the temperature of the outside air and that of the windshield can cause the outer surface of the windshield to fog up, block- ing your vision.
Page 402: Air Circulator
6-1. Using the air conditioning system and defogger  Air circulator Operation method Press “” on to increase the fan speed and “” on decrease the fan speed. When airflow level lights comes on, the system is operational. Press “” until the airflow level is zero in order to turn off the fan. Adjusting the position of the air outlets Direct air flow to the up or down.
Page 403 6-1. Using the air conditioning system and defogger WARNING Precaution air circulator inlet vent ■ Do not bring your head close to the fan inlet vent. It is possible to get your hair caught in the fan resulting in serious injury. NOTICE To prevent damage to rear ceiling air vents ■...
Page 404 6-2. Using the interior lights Interior lights list  Vehicles without an air circulator Vanity lights (if equipped) (P. 416) Front interior light/personal lights (P. 405, 406) Rear interior light (if equipped) (P. 406) Engine switch light (vehicles with a smart entry & start system) Cup holder illumination VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 405 6-2. Using the interior lights  Vehicles with an air circulator Front interior light/personal lights (P. 405, 406) Rear personal light (P. 407) Engine switch light (vehicles with a smart entry & start system) Cup holder illumination Air circulator illumination (P. 407) VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 406: Interior Light
6-2. Using the interior lights Interior light Front ■  Type A Door position Type B  Door position Type C  Door position VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 407: Personal Lights
6-2. Using the interior lights Rear (if equipped) ■ Door position Personal lights Front ■ Type A  On/off When a light is on due to its door link switch, the light will not turn off even if the lens is pressed. Type B ...
Page 408: Air Circulator Illumination
6-2. Using the interior lights  Type C On/off When a light is on due to its door link switch, the light will not turn off even if the lens is pressed. Rear (vehicles with an air circulator) ■ On/off Air circulator illumination (vehicles with an air circulator) There are 4 brightness levels which can be adjusted each time the switch is pressed.
Page 409 6-2. Using the interior lights ■ Illuminated entry system (if equipped)  Vehicles without a smart entry & start system When the interior light switch is in the door position, the interior lights auto- matically turn on/off according to the engine switch position, whether the doors are locked/unlocked and whether the doors are open/closed.
Page 410 6-3. Using the storage features List of storage features Cup holders (P. 411) Bottle holders (P. 412) Glove box (P. 410) Console box (if equipped) (P. 410) Auxiliary boxes (P. 413) WARNING Do not leave glasses, lighters or spray cans in the storage spaces, as this ●...
Page 411: Glove Box
6-3. Using the storage features Glove box Pull up the lever to open the glove box. Using the glove box vent (if equipped) ■ Air from the air conditioning system can be distributed into the glove box by open- ing and closing the vent. The air is conditioned the same as the air for the passenger side vent.
Page 412: Cup Holders
6-3. Using the storage features Cup holders Front ■ Rear ■ Type A (without console box) Type B (with rear armrest)   Pull the armrest down. WARNING Do not place anything other than cups or beverage cans in the cup holders. Other items may be thrown out of the holders in the event of sudden brak- ing, sudden swerving or an accident, cause injury.
Page 413: Bottle Holders
6-3. Using the storage features Bottle holders  Front  Rear ● When storing a bottle, close the cap. The bottle may not be stored depending on its size or shape. ● WARNING Do not place anything other than a bottle in the bottle holders. Other items may be thrown out of the holders in the event of an accident or sudden braking and cause injury.
Page 414: Auxiliary Boxes
6-3. Using the storage features Auxiliary boxes  Type A  Type B Pull the tab to open.  Type C (if equipped) Press in the lid. WARNING Type C only: Do not store items heavier than 0.2 kg (0.4 lb.). Doing so may cause the auxiliary box to open and the items inside may fall out, resulting in an accident.
Page 415: Trunk Features
6-3. Using the storage features Trunk features Auxiliary boxes (if equipped) Remove the covers. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 416: Sun Visors
6-4. Other interior features Other interior features Sun visors To set the visor in the forward position, flip it down. To set the visor in the side posi- tion, flip down, unhook, and swing it to the side. Vanity mirrors (if equipped) Slide the cover to open.
Page 417 6-4. Other interior features ■ Vanity lights (if equipped) Turns the light on Turns the light off Vanity lights can be used when ■  Vehicles without a smart entry & start system The engine switch is in the “ACC” or “ON” position. ...
Page 418: Power Outlets
6-4. Other interior features Power outlets Please use as a power supply for electronic goods that use less than 12 VDC/10A (power consumption of 120 W). When using electronic goods, make sure that the power consumption of all the connected power outlets is less than 120W. Open the lid.
Page 419: Rear Armrest
6-4. Other interior features Rear armrest (if equipped) Fold down the armrest for use. NOTICE To prevent damage to the armrest, do not apply too much load on the arm- rest. Rear sunshade (if equipped) Pull the tab of the shade and hook the shade on the anchors.
Page 420: Assist Grips
6-4. Other interior features Assist grips (if equipped) An assist grip installed on the ceil- ing can be used to support your body while sitting on the seat. WARNING Do not use the assist grip when getting in or out of the vehicle or rising from your seat.
Page 421 6-4. Other interior features VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 422 Maintenance and care 7-1. Maintenance and care 7-3. Do-it-yourself maintenance Cleaning and protecting Do-it-yourself service the vehicle exterior ..422 precautions ......440 Cleaning and protecting Hood ........443 the vehicle interior ...426 Positioning a floor jack..445 7-2. Maintenance Engine compartment..447 Maintenance Tires........462 requirements....429 Tire inflation pressure ..472 Scheduled maintenance ..432...
Page 423: The Vehicle Exterior
7-1. Maintenance and care Cleaning and protecting the vehicle exterior Perform the following to protect the vehicle and maintain it in prime condition: ● Working from top to bottom, liberally apply water to the vehicle body, wheel wells and underside of the vehicle to remove any dirt and dust.
Page 424 7-1. Maintenance and care ■ Bumpers Do not scrub with abrasive cleaners. Plated portions (if equipped) ■ If dirt cannot be removed, clean the parts as follows: Use a soft cloth dampened with an approximately 5% solution of neutral ● detergent and water to clean the dirt off.
Page 425 7-1. Maintenance and care NOTICE To prevent paint deterioration and corrosion on the body and compo- ■ nents (aluminum wheels etc.) ● Wash the vehicle immediately in the following cases: • After driving near the sea coast • After driving on salted roads •...
Page 426 7-1. Maintenance and care NOTICE To prevent damage to the antenna (pole type) ■ Remove the antenna in the following situations: ● When the antenna will touch the ceiling of a garage or other such places When a car cover is to be used to cover the vehicle ●...
Page 427: Cleaning And Protecting The Vehicle Interior
7-1. Maintenance and care Cleaning and protecting the vehicle interior The following procedures will help protect your vehicle’s interior and keep it in top condition: Protecting the vehicle interior ● Remove dirt and dust using a vacuum cleaner. Wipe dirty surfaces with a cloth dampened with lukewarm water.
Page 428 7-1. Maintenance and care ■ Caring for leather areas Toyota recommends cleaning the interior of the vehicle at least twice a year to maintain the quality of the vehicle’s interior. ■ Shampooing the carpets There are several commercial foaming-type cleaners available. Use a sponge or brush to apply the foam.
Page 429 7-1. Maintenance and care NOTICE Cleaning detergents ■ ● Do not use the following types of detergent, as they may discolor the vehi- cle interior or cause streaks or damage to painted surfaces: • Non-seat portions: Organic substances such as benzene or gasoline, alkaline or acidic solutions, dye, and bleach •...
Page 430: Maintenance Requirements
● Where to go for maintenance service? It makes good sense to take your vehicle to your local Toyota dealer for maintenance service as well as other inspections and repairs. Toyota technicians are well-trained specialists receiving the latest service information through technical bulletins, service tips and in-dealership train- ing programs.
Page 431 Engine coolant temperature continually higher than normal ● If you notice any of these clues, take your vehicle to your Toyota dealer as soon as possible. Your vehicle may need adjustment or repair. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 432 7-2. Maintenance WARNING If your vehicle is not properly maintained ■ Improper maintenance could result in serious damage to the vehicle and possible death or serious injury. Handling of the battery ■ Battery posts, terminals and related accessories contain lead and lead com- pounds which are known to cause brain damage.
Page 433: Scheduled Maintenance
7-2. Maintenance Scheduled maintenance Perform maintenance by the schedule as follows: Maintenance schedule requirements Your vehicle needs to be serviced according to the normal maintenance schedule. (See “Maintenance schedule”.) If you mainly operate your vehicle under one or more of the spe- cial operating conditions below, some of the maintenance sched- ule items need to be serviced more frequently in order to keep your vehicle in good condition.
Page 434 7-2. Maintenance Maintenance schedule Maintenance operations: I = Inspect, correct or replace as necessary; R = Replace or change or lubricate SERVICE ODOMETER READING INTERVAL: (Odometer MONTHS x1000 km 10 20 30 40 50 60 70 80 reading or months, whichever x1000 miles 6 12 18 24 30 36 42 48 comes first.)
Page 435 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary; R = Replace or change or lubricate SERVICE ODOMETER READING INTERVAL: (Odometer MONTHS x1000 km 10 20 30 40 50 60 70 80 reading or months, whichever x1000 miles 6 12 18 24 30 36 42 48 comes first.) Fuel tank cap, fuel lines, connections...
Page 436 7-2. Maintenance Maintenance operations: I = Inspect, correct or replace as necessary; R = Replace or change or lubricate SERVICE ODOMETER READING INTERVAL: (Odometer MONTHS x1000 km 10 20 30 40 50 60 70 80 reading or months, whichever x1000 miles 6 12 18 24 30 36 42 48 comes first.) Continuously variable...
Page 437 7-2. Maintenance Additional maintenance schedule Refer to the following table for normal maintenance schedule items requiring more frequent service specific to the type of severe condi- tions. (For outline, see “Maintenance schedule requirements”.) A-1: Operating on rough or muddy roads, or roads with melted snow. ...
Page 438 7-2. Maintenance A-2: Operating on dusty roads. (Roads in areas where their pavement rate is low, or a cloud of dust often arises and the air is dry.) Every 5000 km (3000 miles) or  Replacement of engine oil 6 months Every 5000 km (3000 miles) or ...
Page 439 7-2. Maintenance B-1: Heavily loaded vehicle. (Example: Using a car top carrier, etc.) Every 5000 km (3000 miles) or  Replacement of engine oil 6 months Every 5000 km (3000 miles) or  Replacement of engine oil filter 6 months ...
Page 440 7-2. Maintenance B-3: Repeated short trips less than 15 km (9 miles). (Engine temperature will not reach to normal temperature.) (for 2NR-FBE engine) Every 5000 km (3000 miles) or  Replacement of engine oil 6 months Every 5000 km (3000 miles) or ...
Page 441: Do-It-Yourself Service Precautions
• Grease Battery condition • Conventional wrench (for terminal clamp bolts) (P. 455) • Distilled water • “Toyota Super Long Life Coolant” or a similar high quality ethylene glycol-based non-silicate, non- amine, non-nitrite and non-borate coolant with long- Engine coolant life hybrid organic acid technology level (P.
Page 442 7-3. Do-it-yourself maintenance WARNING The engine compartment contains many mechanisms and fluids that may move suddenly, become hot, or become electrically energized. To avoid death or serious injury, observe the following precautions. ■ When working on the engine compartment Keep hands, clothing and tools away from the moving fan and engine ●...
Page 443 7-3. Do-it-yourself maintenance NOTICE If you remove the air cleaner filter ■ Driving with the air cleaner filter removed may cause excessive engine wear due to dirt in the air. If the fluid level is low or high ■ It is normal for the brake fluid level to go down slightly as the brake pads wear or when the fluid level in the accumulator is high.
Page 444: Hood
7-3. Do-it-yourself maintenance Hood Release the lock from the inside of the vehicle to open the hood. Pull the hood lock release lever. The hood will pop up slightly. Pull up the auxiliary catch lever and lift the hood. Hold the hood open by inserting the supporting rod into the slot.
Page 445 7-3. Do-it-yourself maintenance WARNING Pre-driving check ■ Check that the hood is fully closed and locked. If the hood is not locked properly, it may open while the vehicle is in motion and cause an accident, which may result in death or serious injury. When opening the hood ■...
Page 446: Positioning A Floor Jack
7-3. Do-it-yourself maintenance Positioning a floor jack When using a floor jack, follow the instructions in the manual provided with the jack and perform the operation safely. When raising your vehicle with a floor jack, position the jack cor- rectly. Improper placement may damage your vehicle or cause injury.
Page 447 7-3. Do-it-yourself maintenance WARNING When raising your vehicle ■ Make sure to set the jack attachment properly at the jack point. Raising the vehicle with an improperly positioned floor jack will damage the vehicle and may cause the vehicle to fall off the floor jack.
Page 448: Engine Compartment
7-3. Do-it-yourself maintenance Engine compartment 3NR-FE engine ■ Washer fluid tank (P. 459) Fuse box (P. 484) Engine oil filler cap Engine coolant reservoir (P. 451) (P. 453) Engine oil level dipstick Radiator cap (P. 450) Electric cooling fan Air cleaner (P.
Page 449 7-3. Do-it-yourself maintenance Except for 3NR-FE engine ■ Accessory shapes may differ depending on the engine, grade, etc. Washer fluid tank (P. 459) Fuse box (P. 484) Engine oil filler cap Air cleaner (P. 460) (P. 451) Engine coolant reservoir Engine oil level dipstick (P.
Page 450 7-3. Do-it-yourself maintenance Engine compartment cover Removing the engine compartment cover ■ The engine compartment cover design may differ depending on the target region. Installing the clips ■ Push up center portion Insert Press NOTICE ■ Checking the engine compartment cover after installation Make sure that the cover is securely installed in its original position.
Page 451 7-3. Do-it-yourself maintenance Engine oil With the engine at operating temperature and turned off, check the oil level on the dipstick. Checking the engine oil ■ Park the vehicle on level ground. After warming up the engine and turning it off, wait more than 5 minutes for the oil to drain back into the bottom of the engine.
Page 452 7-3. Do-it-yourself maintenance Adding engine oil ■ If the oil level is below or near the low level mark, add engine oil of the same type as that already in the engine. 3NR-FE engine Except for 3NR-FE engine   Make sure to check the oil type and prepare the items needed before adding oil.
Page 453 Call your Toyota dealer, service station or auto parts store for information concerning recycling or disposal. Do not leave used engine oil within the reach of children.
Page 454 If the coolant level drops within a short time of replenishing Visually check the radiator, hoses, engine coolant reservoir caps, drain cock and water pump. If you cannot find a leak, have your Toyota dealer test the cap and check for leaks in the cooling system. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 455 Radiator and condenser Check the radiator and condenser and clear away any foreign objects. If either of the above parts is extremely dirty or you are not sure of their condition, have your vehicle inspected by your Toyota dealer. WARNING ■...
Page 456 7-3. Do-it-yourself maintenance Battery Check the battery as follows. Caution symbols ■ The meanings of each caution symbol on the top of the battery are as follows: No smoking, no naked Battery acid flames, no sparks Note operating instruc- Shield eyes tions Keep away from children Explosive gas...
Page 457 7-3. Do-it-yourself maintenance Checking battery fluid ■ Check that the level is between the upper and lower lines. Upper line Lower line If the fluid level is at or below the lower line, add distilled water. Adding distilled water (battery with vent plugs) ■...
Page 458 Make sure to turn off the engine before disconnect the battery. Take extra care when connecting the battery if the engine switch mode prior to discharge is unknown. If the engine will not start even after multiple attempts, contact your Toyota dealer. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 459 7-3. Do-it-yourself maintenance WARNING Chemicals in the battery ■ Batteries contain poisonous and corrosive sulfuric acid and may produce hydrogen gas which is flammable and explosive. To reduce the risk of death or serious injury, take the following precautions while working on or near the battery: Do not cause sparks by touching the battery terminals with tools.
Page 460 7-3. Do-it-yourself maintenance NOTICE When recharging the battery ■ Never recharge the battery while the engine is running. Also, be sure all accessories are turned off. When adding distilled water (battery with vent plugs) ■ Avoid overfilling. Water spilled during battery recharging may cause corro- sion.
Page 461 7-3. Do-it-yourself maintenance Air cleaner filter Check the air cleaner filter as follows: 3NR-FE engine: Remove the engine cover. Release the clips. 3NR-FE engine Except for 3NR-FE engine   VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 462 7-3. Do-it-yourself maintenance Lift the cover and take out the air cleaner filter. 3NR-FE engine Except for 3NR-FE engine   Inspect the outer surface of the filter, and replace the filter if it is extremely dirty. If the filter is only moderately dusty, use compressed air to blow dust out of the filter.
Page 463: Tires
7-3. Do-it-yourself maintenance Tires Replace or rotate tires in accordance with maintenance sched- ules and treadwear. Checking tires Check if the treadwear indicators are showing on the tires. Also check the tires for uneven wear, such as excessive wear on one side of the tread.
Page 464 Front Front To equalize tire wear and help extend tire life, Toyota recommends that tire rotation is carried out approximately every 10000 km (6000 miles). Vehicles with the tire pressure warning system: When rotating front and rear tires which have different tire inflation pres- sures, do not fail to initialize the tire pressure warning system after tire rotation.
Page 465 ID codes must be registered in the tire pressure warning computer and the tire pressure warning system must be initialized. Have tire pressure warning valve and transmitter ID codes registered by your Toyota dealer. (P. 465) ◆ Initializing the tire pressure warning system The tire pressure warning system must be initialized in the fol- ■...
Page 466 A tire goes flat repeatedly or cannot be properly repaired due to the size or ● location of a cut or other damage If you are not sure, consult with your Toyota dealer. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 467 7-3. Do-it-yourself maintenance ■ Replacing tire and wheels (vehicles with a tire pressure warning system) If the ID code of the tire pressure warning valve and transmitter is not regis- tered, the tire pressure warning system will not work properly. After driving for about 10 minutes, the tire pressure warning light blinks for 1 minute and stays on to indicate a system malfunction.
Page 468 In the following cases, the tire pressure warning system may not operate ● properly. • If non-genuine Toyota wheels are used. • A tire has been replaced with a tire that is not an OE (Original Equipment) tire. • A tire has been replaced with a tire that is not of the specified size.
Page 469 If repeated attempts to record tire inflation pressure settings are unsuccessful, have the vehicle inspected by your Toyota dealer. When operating the tire pressure warning reset switch, the tire pressure ●...
Page 470 7-3. Do-it-yourself maintenance  For vehicles sold in Taiwan  For vehicles sold in United Arab Emirates  For vehicles sold in Jordan VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 471 Do not mix tires of different makes, models or tread patterns. ● Also, do not mix tires of remarkably different treadwear. ● Do not use tire sizes other than those recommended by Toyota. ● Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).
Page 472 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer or other qualified service shop as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repairing or replacing the tire.
Page 473: Tire Inflation Pressure
Reduced tire life due to wear ● Reduced safety ● Damage to the drive train If a tire needs frequent inflating, have it checked by your Toyota dealer. Instructions for checking tire inflation pressure ■ When checking tire inflation pressure, observe the following: ●...
Page 474 7-3. Do-it-yourself maintenance WARNING Proper inflation is critical to save tire performance ■ Keep your tires properly inflated. If the tires are not properly inflated, the following conditions may occur which could lead to an accident resulting in death or serious injury: Excessive wear ●...
Page 475: Wheels
● Used wheels ● Bent wheels that have been straightened Aluminum wheel precautions (if equipped) ● Use only Toyota wheel nuts and wrenches designed for use with your aluminum wheels. ● When rotating, repairing or changing your tires, check that the wheel nuts are still tight after driving 1600 km (1000 miles).
Page 476 ● Because tire repair or replacement may affect the tire pressure warning valves and transmitters, make sure to have tires serviced by your Toyota dealer or other qualified service shop. In addition, make sure to purchase your tire pressure warning valves and transmitters at your Toyota dealer.
Page 477: Air Conditioning Filter
7-3. Do-it-yourself maintenance Air conditioning filter The air conditioning filter must be changed regularly to maintain air conditioning efficiency. Removal method Turn the engine switch to the “LOCK” position (vehicles without a smart entry & start system) or off (vehicles with a smart entry & start system).
Page 478 7-3. Do-it-yourself maintenance With the glove box fully open, slightly lift up the glove box and pull toward the seat to detach the bottom of the glove box. Do not use excessive force if the glove box does not detach when lightly pulled.
Page 479 7-3. Do-it-yourself maintenance ■ Checking interval Inspect and replace the air conditioning filter according to the maintenance schedule. In dusty areas or areas with heavy traffic flow, early replacement may be required. (P. 432) If air flow from the vents decreases dramatically ■...
Page 480: Wireless Remote Control Electronic Key Battery
7-3. Do-it-yourself maintenance  Wireless remote control/electronic key battery Replace the battery with a new one if it is depleted. You will need the following items: ● Flathead screwdriver ● Small flathead screwdriver ● Lithium battery Vehicles without a smart entry & start system: CR1620 Vehicles with a smart entry &...
Page 481 7-3. Do-it-yourself maintenance Open the case cover using a coin protected with tape, etc., and remove the depleted bat- tery. Insert a new battery with the “+” terminal facing up. For Taiwan Vehicles without a smart entry & start system (type B) ...
Page 482 7-3. Do-it-yourself maintenance  Vehicles with a smart entry & start system Remove the cover. To prevent damage to the key, cover the tip of the flathead screw- driver with a tape. Remove the battery cover. Knob Pull the knob of the battery cover to remove.
Page 483 Vehicles without a smart entry & start system: CR1620 Vehicles with a smart entry & start system: CR2032 ● Batteries can be purchased at your Toyota dealer, local electrical appliance shops or camera stores. Replace only with the same or equivalent type recommended by the manu- ●...
Page 484 7-3. Do-it-yourself maintenance NOTICE For normal operation after replacing the battery ■ Observe the following precautions to prevent accidents: ● Always work with dry hands. Moisture may cause the battery to rust. Do not touch or move any other component inside the remote control. ●...
Page 485: Checking And Replacing Fuses
7-3. Do-it-yourself maintenance Checking and replacing fuses If any of the electrical components do not operate, a fuse may have blown. If this happens, check and replace the fuses as nec- essary. Turn the engine switch to the “LOCK” position (vehicles without a smart entry &...
Page 486 7-3. Do-it-yourself maintenance  Under the instrument panel (right-hand drive vehicles) Remove the lid. Remove the fuse with the pull- out tool. Only type A fuse can be removed using the pullout tool. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 487 7-3. Do-it-yourself maintenance Check if the fuse is blown. Normal fuse Blown fuse Replace the blown fuse with a new fuse of an appropriate amperage rat- ing. The amperage rating can be found on the fuse box lid. Type A Type B ...
Page 488 If the lights do not turn on even after the fuse has been replaced, a bulb may need replacement. (P. 488) ● If the replaced fuse blows again, have the vehicle inspected by your Toyota dealer. If there is an overload in a circuit ■...
Page 489: Light Bulbs
As there is a danger that components may be damaged, we recommend that replacement is carried out by your Toyota dealer. Preparing for light bulb replacement Check the wattage of the light bulb to be replaced. (P. 610) Removing the engine compartment cover P.
Page 490 7-3. Do-it-yourself maintenance Rear ■ Stop/tail lights (bulb type) High mounted stoplight (bulb type) Rear turn signal lights Rear fog lights (if equipped) Back-up lights License plate lights VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 491 7-3. Do-it-yourself maintenance Replacing light bulbs Headlight low beam ■ Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting and insert. Turn it clockwise to set.
Page 492 7-3. Do-it-yourself maintenance Headlight high beam ■ Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting and insert. Turn it clockwise to set. Install the connector.
Page 493 7-3. Do-it-yourself maintenance Front turn signal lights ■ Remove the engine compartment cover. (P. 449) Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 494 7-3. Do-it-yourself maintenance Front position lights (bulb type) ■ Remove the engine compartment cover. (P. 449) Turn the bulb base counter- clockwise. Remove the light bulb When installing, reverse the steps listed. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 495 7-3. Do-it-yourself maintenance Front fog lights (if equipped) ■ Remove the 3 screws and partly remove the fender liner. Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Set the new light bulb. Align the 3 tabs on the light bulb with the mounting, and insert.
Page 496 7-3. Do-it-yourself maintenance Install the connector. After installing the connector, shake the bulb base gently to check that it is not loose, turn the fog lights on once and visu- ally confirm that no light is leak- ing through the mounting. Reinstall the fender liner and install the 3 screws.
Page 497 7-3. Do-it-yourself maintenance Side turn signal lights (for Brazil, Argentina, Colombia, Paraguay ■ and Uruguay) Press the upper section of the mirror to create a gap in the lower section. To prevent damaging the vehi- cle, apply the protective tape as shown in the illustration.
Page 498 7-3. Do-it-yourself maintenance Release the claws of the bot- tom part of the cover and then remove the cover. Release claws remove the lens. Remove the socket from the side turn signal light housing. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 499 7-3. Do-it-yourself maintenance Remove the bulb. Replace the bulb and install the socket to the side turn signal light housing. Align the grooves of the socket to the side turn signal light hous- ing. Install the lens. Confirm that the claws are securely fitted.
Page 500 7-3. Do-it-yourself maintenance 11 10 11 Engage the 2 guides and the Guide Claw 2 claws, and install the outer mirror. Make sure to insert the guides and the claws as shown in the illustration, and push claws in until a click is heard. If you do not hear the click, do not force the claws in.
Page 501 7-3. Do-it-yourself maintenance Release the claw of the bot- tom part of the cover and then remove the cover. Insert a flathead screwdriver and remove the lens to the outside. Remove the socket from the side turn signal light housing. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 502 7-3. Do-it-yourself maintenance Remove the bulb. Replace the bulb and install the socket to the side turn signal light housing. Align the grooves of the socket to the side turn signal light hous- ing. Install the lens. Insert the claw of the lens.
Page 503 7-3. Do-it-yourself maintenance Insert the claw of the cover. Attach the claw on the bot- tom part of the cover. Attach the cover claws span- ning over the entire perime- ter. Finally, confirm that the outside claw is securely fitted. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 504 7-3. Do-it-yourself maintenance Stop/tail lights (bulb type) and rear turn signal lights ■ Open the trunk lid. Remove the clips on which- ever side you are replacing and open the cover of the trunk lid. Turn the bulb base counter- clockwise.
Page 505 7-3. Do-it-yourself maintenance Back-up lights ■ Open trunk remove the clips. Then partly remove the trunk panel cover. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 506 7-3. Do-it-yourself maintenance License plate lights ■ Open trunk remove the clips. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 507 7-3. Do-it-yourself maintenance High mounted stoplight (bulb type) ■ Remove the cover. Unplug the connector while pressing the lock release. Turn the bulb base counter- clockwise. Remove the light bulb. When installing, reverse the steps listed. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 508 Replacing the following bulbs ■ If any of the lights listed below has burnt out, have it replaced by your Toyota dealer. ● Front position lights (LED type) ● Daytime running lights (if equipped) ● Side turn signal lights (except for Brazil, Argentina, Colombia, Paraguay, Uruguay and India) ●...
Page 509 The front position lights (LED type), daytime running lights (if equipped), stop/ tail lights (LED type) and high mounted stoplight (LED type) consist of a num- ber of LEDs. If any of the LEDs burn out, take your vehicle to your Toyota dealer to have the light replaced.
Page 510: When Trouble Arises
When trouble arises 8-1. Essential information 8-2. Steps to take in an emergency Emergency flashers...510 If your vehicle needs to If your vehicle has to be towed ......514 be stopped in an emergency....511 If you think something is wrong.......520 If the vehicle is trapped in rising water ....513 Fuel pump shut off system ......521...
Page 511: Emergency Flashers
8-1. Essential information Emergency flashers The emergency flashers are used to warn other drivers when the vehicle has to be stopped in the road to a breakdown, etc. Press the switch. All the turn signal lights will flash. To turn them off, press the switch once again.
Page 512: Be Stopped In An Emergency
8-1. Essential information If your vehicle has to be stopped in an emergency Only in an emergency, such as if it becomes impossible to stop the vehicle in the normal way, stop the vehicle using the follow- ing procedure: Steadily step on the brake pedal with both feet and firmly depress it. Do not pump the brake pedal repeatedly as this will increase the effort required to slow the vehicle.
Page 513 8-1. Essential information WARNING If the engine has to be turned off while driving ■ ● Power assist for the brakes and steering wheel will be lost, making the brake pedal harder to depress and the steering wheel heavier to turn. Decelerate as much as possible before turning off the engine.
Page 514: If The Vehicle Is Trapped In Rising Water
However, an emergency hammer cannot shatter the windshield as it is lam- inated glass. : Contact your Toyota dealer or aftermarket accessory manufacturer for further information about an emergency hammer. ■ Escaping the vehicle from the window There are cases where escaping the vehicle from the window is not possi- ble due to seating position, passenger body type, etc.
Page 515: Be Towed
If your vehicle needs to be towed If towing is necessary, we recommend having your vehicle towed by your Toyota dealer or commercial towing service, using a wheel-lift type truck or flatbed truck. Use a safety chain system for all towing, and abide by all state/ provincial and local laws.
Page 516 8-2. Steps to take in an emergency Towing with a wheel-lift type truck  From the front  From the rear Release the parking brake. Use a towing dolly under the front wheels. Using a flatbed truck If your vehicle is transported by a Front flatbed truck, it should be tied down at the locations shown in the...
Page 517 8-2. Steps to take in an emergency Emergency towing If a tow truck is not available in an emergency, your vehicle may be temporarily towed using cables or chains secured to the emergency towing eyelets. This should only be attempted on hard surfaced roads for at most 80 km (50 miles) at under 30 km/h (18 mph).
Page 518 8-2. Steps to take in an emergency Securely attach cables or chains to the towing eyelet. Take care not to damage the vehicle body. Vehicles without a smart entry & start system: Enter the vehicle being towed and start the engine. If the engine does not start, turn the engine switch to the “ON”...
Page 519 8-2. Steps to take in an emergency WARNING Observe the following precautions. Failure to do so may result in death or serious injury. ■ While towing When towing using cables or chains, avoid sudden starts, etc., which ● place excessive stress on the towing eyelets, cables or chains. The towing eyelets, cables or chains may become damaged, broken debris may hit people, and cause serious damage.
Page 520 8-2. Steps to take in an emergency NOTICE To prevent damage to the vehicle when towing using a wheel-lift type ■ truck ● Vehicles without a smart entry & start system: Do not tow the vehicle from the rear when the engine switch is in the “LOCK” position or the key is removed.
Page 521: If You Think Something Is Wrong
8-2. Steps to take in an emergency If you think something is wrong If you notice any of the following symptoms, your vehicle proba- bly needs adjustment or repair. Contact your Toyota dealer as soon as possible. Visible symptoms ● Fluid leaks under the vehicle (Water dripping from the air conditioning after use is normal) ●...
Page 522: Fuel Pump Shut Off System
8-2. Steps to take in an emergency Fuel pump shut off system To minimize the risk of fuel leakage when the engine stalls or when an airbag inflates upon collision, the fuel pump shut off system stops the supply of fuel to the engine. Follow the procedure below to restart the engine after the system is activated.
Page 523: Fire Extinguisher
8-2. Steps to take in an emergency  Fire extinguisher A fire extinguisher is located under the front passenger’s seat. It is for use in emergencies, such as in the event of a fire. For information about usage, refer to the label on the fire extin- guisher.
Page 524 Replace it with a new one as soon as possible after using it. ● Use a genuine Toyota fire extinguisher when replacing. If a non-genuine Toyota fire extinguisher is used, it may not be possible to secure the fire extinguisher properly and it may come loose. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 525: Or A Warning Buzzer Sounds
• Low brake fluid • Malfunction in the brake system  Immediately stop the vehicle in a safe place and con- tact your Toyota dealer. Continuing to drive the vehi- cle may be dangerous. Charging system warning light Indicates a malfunction in the vehicle’s charging system.
Page 526 • The electronic throttle control system; • The electronic continuously variable transmission con- trol system (if equipped); or • The emission control system.  Have the vehicle inspected by your Toyota dealer immediately. SRS warning light Indicates a malfunction in: •...
Page 527 Electric power steering system warning light (warning buzzer) Indicates a malfunction in the EPS (Electric Power Steer- ing) system.  Have the vehicle inspected by your Toyota dealer (Red/yellow) immediately. Smart entry & start system indicator (warning buzzer) (if equipped) Indicates a malfunction in the smart entry &...
Page 528 When the light comes on after blinking for 1 minute: Malfunction in the tire pressure warning system. (P. 530)  Have the system checked by your Toyota dealer. Go to service warning light Indicates a malfunction in the electronic engine control systems.
Page 529 8-2. Steps to take in an emergency : Driver’s seat belt warning buzzer:  Except for GCC countries , Republic of Yemen, Jordan, Lebanon and Syrian Arab Republic The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat belt is not fastened.
Page 530 If the fuel tank is empty, refuel the vehicle imme- diately. The malfunction indicator lamp will go off after several trips. If the malfunction indicator lamp does not go off, contact your Toyota dealer as soon as possible.
Page 531 “ON” position (vehicles without a smart entry & start system) or the engine switch is turned to IGNITION ON mode (vehicles with a smart entry & start system), have it checked by your Toyota dealer. ■ Warning buzzer In some cases, the buzzer may not be heard because of noisy place or an audio sound.
Page 532 If both the ABS and the brake system warning lights remain on ■ Stop your vehicle in a safe place immediately and contact your Toyota dealer. The vehicle will become extremely unstable during braking, and the ABS system may fail, which could cause an accident resulting in death or serious injury.
Page 533 8-2. Steps to take in an emergency Follow the correction procedures (vehicles with smart entry & start system and a drive monitor display) After taking the specified steps to correct the suspected problem, check that the warning light goes off. Interior Exterior Warning...
Page 534 8-2. Steps to take in an emergency Interior Exterior Warning Warning light/Details/Actions buzzer buzzer light Smart entry & start system indicator Indicates that a door other than the driver’s door has been opened and closed with the engine switch in any mode other than off Once 3 times and the electronic key outside of the detec- (Flashes in...
Page 535 8-2. Steps to take in an emergency Interior Exterior Warning Warning light/Details/Actions buzzer buzzer light Smart entry & start system indicator • When the doors were unlocked with the mechanical key and then the engine switch was pressed, the electronic key could not be detected in the vehicle.
Page 536 Multi-information display If any of the warning messages are shown again after the following actions have been performed, contact your Toyota dealer. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 537 Messages and warnings The warning lights and warning buzzers operate as follows depending on the content of the message. If a message indicates the need for inspection by a dealer, have the vehicle inspected by your Toyota dealer immediately. System...
Page 538 If the following messages are shown, there may be a malfunction. Immediately stop the vehicle in a safe place and contact your Toyota dealer. Continuing to drive the vehicle may be dangerous. • “Braking Power Low Stop in a Safe Place See Owner’s Manual”...
Page 539: If You Have A Flat Tire
After temporar- ily repairing the tire with the kit, have the tire repaired or replaced by your Toyota dealer. WARNING ■...
Page 540 A flat tire that cannot be repaired with the emergency tire puncture repair ■ In the following cases, the tire cannot be repaired with the emergency tire puncture repair kit. Contact your Toyota dealer. When the tire is damaged due to driving without sufficient air pressure ●...
Page 541 8-2. Steps to take in an emergency Location of the emergency tire puncture repair kit and tools 1, 2 Jack attachment Wheel nut wrench Towing eyelet Emergency tire puncture repair kit 1, 2 Jack handle : If equipped : Use of the jack (if equipped)(P. 559), jack handle and wheel nut wrench. (P.
Page 542 8-2. Steps to take in an emergency Emergency tire puncture repair kit components Hose Power plug Air release cap Air pressure gauge Sticker Compressor switch VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 543 8-2. Steps to take in an emergency Taking out the emergency tire puncture repair kit Remove the covers. (P. 414) Take out the emergency tire puncture repair kit. (P. 540) ■ Taking out the jack P. 559 WARNING ■ After using the tools and jack Before driving, make sure all the tools and jack are securely in place in their storage location to reduce the possibility of personal injury during a collision or sudden braking.
Page 544 8-2. Steps to take in an emergency Emergency repair method Take out the repair kit from the plastic bag. Remove the valve cap from the valve of the punctured tire. Extend the hose. Remove the air release cap from the hose. Attach the sticker enclosed with the bottle on the specified locations.
Page 545 8-2. Steps to take in an emergency Connect the hose to the valve. Screw the end of the hose clock- wise as far as possible. Make sure that the compressor switch is off. Lift the rubber stopper on the compressor. Remove the power plug from the compressor.
Page 546 8-2. Steps to take in an emergency Connect the power plug to the power outlet socket. (P. 417) Front Rear (if equipped)   Connect the bottle to the com- pressor. As shown in the illustration, insert the bottle securely into the com- pressor until the upper side of the mark on the bottle is aligned with the upper end of the notch.
Page 547 8-2. Steps to take in an emergency Check the specified tire inflation pressure. Tire inflation pressure is specified on the label on the driver’s side pil- lar as shown. (P. 607) Start the engine. (P. 220, 223) To inject the sealant and inflate the tire, turn the compressor switch on.
Page 548 25 minutes, the tire is too damaged to be repaired. Turn the compressor switch off and contact your Toyota dealer. • If the tire inflation pressure exceeds the specified air pressure, let out some air to adjust the tire inflation pressure. (P. 607)
Page 549 If the tire inflation pressure is under 130 kPa (1.3 kgf/cm or bar, 19 psi): The puncture cannot be repaired. Contact your Toyota dealer. If the tire inflation pressure is 130 kPa (1.3 kgf/cm or bar, 19 psi) or higher, but less...
Page 550 Taking precautions to avoid sudden braking, sudden acceleration and sharp turns, drive carefully at under 80 km/h (50 mph) to the nearest Toyota dealer that is less than 100 km (62 miles) away for tire repair or replacement. When having the tire repaired or replaced, make sure to tell the Toyota dealer that the sealant is injected.
Page 551 8-2. Steps to take in an emergency ■ If the tire is inflated to more than the specified air pressure Disconnect the hose from the valve. Install the air release cap to the end of the hose and push the protrusion on the air release cap into the tire valve to let some air out.
Page 552 ● The sealant has a limited life span. The expiry date is marked on the bottle. ● The sealant should be replaced before the expiry date. Contact your Toyota dealer for replacement. ● The sealant stored in the emergency tire puncture repair kit can be used only once to temporarily repair a single tire.
Page 553 8-2. Steps to take in an emergency WARNING Do not drive the vehicle with a flat tire ■ Do not continue driving with a flat tire. Driving even a short distance with a flat tire can damage the tire and the wheel beyond repair.
Page 554 8-2. Steps to take in an emergency WARNING When fixing the flat tire ■ ● Stop your vehicle in a safe and flat area. ● Do not touch the wheels or the area around the brakes immediately after the vehicle has been driven. After the vehicle has been driven, the wheels and the area around the brakes may be extremely hot.
Page 555 8-2. Steps to take in an emergency WARNING Driving to spread the liquid sealant evenly ■ Observe the following precautions to reduce the risk of accidents. Failing to do so may result in a loss of vehicle control and cause death or serious injury.
Page 556 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when repair- ing or replacing the tire.(P.
Page 557 8-2. Steps to take in an emergency If you have a flat tire (vehicles with a spare tire) Your vehicle is equipped with a spare tire. The flat tire can be replaced with the spare tire. For details about tires: P. 462 WARNING If you have a flat tire ■...
Page 558 8-2. Steps to take in an emergency Location of the spare tire, jack and tool bag Location ■ Warning reflector Spare tire Jack Tool bag : If equipped Inside of the tool bag ■ Jack attachment Towing eyelet Spanners Jack handle Screwdriver Wheel nut wrench Pliers...
Page 559 8-2. Steps to take in an emergency WARNING Using the tire jack ■ Observe the following precautions. Improper use of the tire jack may cause the vehicle to suddenly fall off the jack, leading to death or serious injury. Do not use the tire jack for any purpose other than replacing tires or install- ●...
Page 560 8-2. Steps to take in an emergency Taking out the jack Move the front left seat to the front most position and remove the cover (if equipped). Take out the jack. For tightening For loosening VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 561 8-2. Steps to take in an emergency Taking out the spare tire Remove the cover.  Type A Loosen the center fastener that secures the spare tire.  Type B Remove the spare wheel cush- ion, then loosen the center fas- tener that secures the spare tire.
Page 562 8-2. Steps to take in an emergency NOTICE When stowing the tool bag ■ If the tool bag is not stored properly, the Luggage floor cover Luggage floor cover may be damaged. Tool bag Body Spare tire Replacing a flat tire Chock the tires.
Page 563 8-2. Steps to take in an emergency Slightly loosen the wheel nuts (one turn). Turn the tire jack portion “A” by hand until the notch of the jack is in contact with the jack point. The jack point guides are located under the rocker panel.
Page 564 • If there are any cracks or deformations in the bolt screws, nut threads or bolt holes of the wheel, have the vehicle inspected by your Toyota dealer. • When installing the wheel nuts, be sure to install them with the tapered ends facing inward.
Page 565 8-2. Steps to take in an emergency Installing the spare tire Remove any dirt or foreign mat- ter from the wheel contact sur- face. If foreign matter is on the wheel contact surface, the wheel nuts may loosen while the vehicle is in motion, causing the tire to come off.
Page 566 8-2. Steps to take in an emergency Lower the vehicle. Firmly tighten each wheel nut two or three times in the order shown in the illustration. Tightening torque: 103 N·m (10.5 kgf·m, 76 ft·lbf) Vehicles with a full cover wheel ornament (with a spare tire of the ...
Page 567 8-2. Steps to take in an emergency ■ The spare tire of a different tire size from the installed tires (except com- pact spare tire) Use the spare tire temporarily, and only in an emergency. ● ● Make sure to check the tire inflation pressure of the spare tire. (P. 607) ■...
Page 568 8-2. Steps to take in an emergency WARNING When using the spare tire of a different tire size from the installed tires ■ (except compact spare tire) ● Do not use more than one spare tire simultaneously. Replace the spare tire with a standard tire as soon as possible. ●...
Page 569 When a tire is repaired with liquid sealants, the tire pressure warning valve and transmitter may not operate properly. If a liquid sealant is used, contact your Toyota dealer as soon as possible. After use of liquid sealant, make sure to replace the tire pressure warning valve and transmitter when replac- ing the tire.
Page 570: If The Engine Will Not Start
8-2. Steps to take in an emergency If the engine will not start If the engine will not start even though correct starting proce- dures are being followed (P. 220, 223), consider each of the fol- lowing points: The engine will not start even though the starter motor operates normally.
Page 571 ● There may be a malfunction in the steering lock system (vehicles with a smart entry & start system). Contact your Toyota dealer if the problem cannot be repaired, or if repair procedures are unknown. Emergency start function (vehicles with a smart entry & start...
Page 572 8-2. Steps to take in an emergency If the electronic key does not operate properly (vehicles with a smart entry & start system) If communication between the electronic key and vehicle is interrupted (P. 176) or the electronic key cannot be used because the battery is depleted, the smart entry &...
Page 573 Vehicles with a multi-information display: Firmly depress the brake pedal (continuously variable transmission) or clutch pedal (manual transmission) and check that message is shown on the multi-infor- mation display. Press the engine switch. In the event that the engine still cannot be started, contact your Toyota dealer. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 574 8-2. Steps to take in an emergency ■ Stopping the engine Shift the shift lever to P (continuously variable transmission) or N (manual transmission) and press the engine switch as you normally do when stopping the engine. ■ Replacing the key battery As the above procedure is a temporary measure, it is recommended that the electronic key battery be replaced immediately when the battery is depleted.
Page 575: If The Vehicle Battery Is Discharged
The following procedures may be used to start the engine if the vehicle’s battery is discharged. You can also call your Toyota dealer or a qualified repair shop. If you have a set of jumper (or booster) cables and a second vehicle with a 12-volt battery, you can jump start your vehicle by following the steps below.
Page 576 8-2. Steps to take in an emergency  Except for 3NR-FE engine Connect a positive jumper cable clamp to the positive (+) battery terminal on your vehicle. Connect the clamp on the other end of the positive cable to the positive (+) battery terminal on the second vehicle.
Page 577 IGNITION ON mode. Once the vehicle’s engine has started, remove the jumper cables in the exact reverse order from which they were connected. Once the engine starts, have the vehicle inspected at your Toyota dealer as soon as possible. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 578 If an unsupported battery is used, Stop & Start system functions may be restricted to protect the battery. Also, battery performance may decrease and the engine may not be able to restart. Contact your Toyota dealer for details. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 579 • If the 20 hour rate capacity is low, even if the time period where the vehi- cle is not used is a short time, the battery may discharge and the engine may not be able to start. ● For details, consult your Toyota dealer. WARNING ■ Avoiding battery fires or explosions...
Page 580 8-2. Steps to take in an emergency WARNING Battery precautions ■ The battery contains poisonous and corrosive acidic electrolyte, while related parts contain lead and lead compounds. Observe the following pre- cautions when handling the battery: When working with the battery, always wear safety glasses and take care ●...
Page 581: If Your Vehicle Overheats
If you do not see steam: Carefully lift the hood. After the engine has cooled down sufficiently, inspect the hoses and radiator core (radia- tor) for any leaks. Radiator Cooling fan If a large amount of coolant leaks, immediately contact your Toyota dealer. VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 582 (The fan may not operate in freezing temperatures.) If the fan is not operating: Stop the engine immediately and contact your Toyota dealer. If the fan is operating: Have the vehicle inspected at the nearest Toyota dealer.
Page 583 8-2. Steps to take in an emergency WARNING When inspecting under the hood of your vehicle ■ Observe the following precautions. Failure to do so may result in serious injury such as burns. If steam is seen coming from under the hood, do not open the hood until ●...
Page 584: If The Vehicle Becomes Stuck
8-2. Steps to take in an emergency If the vehicle becomes stuck Carry out the following procedures if the tires spin or the vehicle becomes stuck in mud, dirt or snow: Stop the engine. Set the parking brake and shift the shift lever to P (continuously variable transmission) or N (manual transmission).
Page 585 8-2. Steps to take in an emergency WARNING When attempting to free a stuck vehicle ■ If you choose to push the vehicle back and forth to free it, make sure the surrounding area is clear to avoid striking other vehicles, objects or people. The vehicle may also lunge forward or lunge back suddenly as it becomes free.
Page 586 Vehicle specifications 9-1. Specifications Maintenance data (fuel, oil level, etc.)...586 Fuel information ....612 9-2. Customization Customizable features ..615 9-3. Initialization Items to initialize ....619 VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 587 9-1. Specifications Maintenance data (fuel, oil level, etc.) Dimensions Overall length 4425 mm (174.2 in.) Overall width 1730 mm (68.1 in.) 1475 mm (58.1 in.) Overall height 1495 mm (58.9 in.) Wheelbase 2550 mm (100.4 in.) 1475 mm (58.1 in.) 1460 mm (57.5 in.) Front 1480 mm (58.3 in.)
Page 588 ■ The vehicle identification number (VIN) is the legal identifier for your vehicle. This is the primary identification number for your Toyota. It is used in registering the ownership of your vehicle.  Type A This number is stamped under the right front seat.
Page 589 9-1. Specifications  Type D This number is also on the manu- facturer’s label on the lefthand side center pillar. Type E  This number is also stamped on the top left of the instrument panel. Type F  This number is also on the vehicle identification plate in the engine compartment.
Page 590 “E”, “M” or “U” as the last let- : Except for vehicles with model code that have “E”, “M”, “U” or “X” as the last letter nor manufactured by “Toyota do Brasil Ltda.” : For vehicles sold in Syria, or vehicles with model code that do not have “V”...
Page 591 9-1. Specifications Year of manufacture and country of origin ■ The year of the manufacture and country of origin are shown on the Certification Regulation label. : For vehicles with model code that has “V” (except for Syria) as the last letter : The model code is indicated on the manufacturer’s label or the Certifica- tion Regulation plate.
Page 592 9-1. Specifications Engine  3NR-FE and 3NR-FKE engines Model 3NR-FE and 3NR-FKE Type 4-cylinder in line, 4-cycle, gasoline Bore and stroke 72.5 x 72.5 mm (2.85 x 2.85 in.) Displacement 1197 cm (73.0 cu.in.) Valve clearance Automatic adjustment Drive belt tension Automatic adjustment ...
Page 593 9-1. Specifications  1NR-FE engine Model 1NR-FE Type 4-cylinder in line, 4-cycle, gasoline 72.5  80.5 mm (2.85  3.17 in.) Bore and stroke Displacement 1329 cm (81.1 cu.in.) Valve clearance Automatic adjustment Drive belt tension Automatic adjustment  Continuously variable transmission 160 km/h (99 mph) Maximum vehicle...
Page 594 3NR-FE, 2NR-FE and 1NR-FE engines For Argentina: Unleaded gasoline which does not contain metallic additives (Manganese-based, etc.) only Fuel type For details about gasoline, contact your Toyota dealer. Except for Argentina: Unleaded gasoline only Research Octane 91 (octane rating 87) or higher...
Page 595 9-1. Specifications Lubrication system ■ Oil capacity (Drain and refill — reference With filter 3.5 L (3.7 qt., 3.1 Imp.qt.) 3NR-FE 3NR-FKE engines Without filter 3.3 L (3.5 qt., 2.9 Imp.qt.) With filter 3.3 L (3.5 qt., 2.9 Imp.qt.) 2NR-FE 2NR-FBE engines Without filter 3.1 L (3.3 qt., 2.7 Imp.qt.) ...
Page 596 Engine oil selection ■ 3NR-FE, 2NR-FE and 1NR-FE engines  “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-20, 5W-20, 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN...
Page 597 9-1. Specifications Oil viscosity (0W-20 is explained here as an example): • The 0W in 0W-20 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 598 9-1. Specifications  2NR-FBE engine “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 5W-30 and 10W-30: API grade SL “Energy-Conserving”, SM “Energy-Conserving”, SN “Resource-Conserving”...
Page 599 9-1. Specifications Oil viscosity (5W-30 is explained here as an example): • The 5W in 5W-30 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 600 9-1. Specifications  3NR-FKE engine “Toyota Genuine Motor Oil” is used in your Toyota vehicle. Use Toyota approved “Toyota Genuine Motor Oil” or equivalent to satisfy the following grade and viscosity. Oil grade: 0W-16: API grade SN “Resource-Conserving” or SN PLUS “Resource-Con- serving”...
Page 601 9-1. Specifications Oil viscosity (0W-16 is explained here as an example): • The 0W in 0W-16 indicates the characteristic of the oil which allows cold startability. Oils with a lower value before the W allow for easier starting of the engine in cold weather. •...
Page 602 4.6 L (4.9 qt., 4.0 Imp.qt.) 4.8 L (5.1 qt., 4.2 Imp.qt.) 5.0 L (5.3 qt., 4.4 Imp.qt.) Use either of the following: • “Toyota Super Long Life Coolant” • A similar high-quality ethylene glycol- based non-silicate, non-amine, non- Coolant type...
Page 603 9-1. Specifications : For NSP152R-AEXRKT and NSP152R-AEXRBT models : For NSP151R-AEXRKT, NSP151R-AEXGKT, NSP151R-CEXDKD, NSP151R-CEXRKD, NSP151R-CEXGKD, NSP151R-BEXDKE, NSP151R-BEXRKE, NSP151R-BEXGKE, NSP151R-BEXVKE, NSP150L-DEXDKM, NSP150L-DEXRKM and NSP151L-DEXGKM mod- : For NSP150L-AEXDKV, NSP150L-AEXRKV, NSP150L-AEXGKV, NSP151L-AEXRKV, NSP151L-AEXGKV, NSP150R-AEXDK, NSP150R-AEXRK, NSP150R-AEXGK, NSP151R-AEXGK, NSP150L-AEXDK, NSP150L-AEXRK, NSP150L-AEXGK, NSP151L-AEXDK, NSP151L-AEXRK, NSP151L-AEXGK, NSP150L-CEXDKV, NSP150L-CEXRKV,...
Page 604 9-1. Specifications Ignition system Spark plug Make 3NR-FE, 2NR-FE 1NR-FE DENSO SC16HR11 1.1 mm (0.043 in.) engines 2NR-FBE engine DENSO FC20HR-G8 0.8 mm (0.032 in.) 3NR-FKE engine DENSO FC16HR-Q8 0.8 mm (0.032 in.) NOTICE Iridium-tipped spark plugs ■ Use only iridium-tipped spark plugs. Do not adjust the spark plug gap. Electrical system ...
Page 605 3NR-FKE 5.0 L (5.3 qt., 4.4 Imp.qt.) engine Fluid type Toyota Genuine CVT Fluid FE : The fluid capacity is the quantity of reference. If replacement is necessary, contact your Toyota dealer. NOTICE Continuously variable transmission fluid type ■...
Page 606 Toyota recommends to use “TOYOTA Genuine Manual Transmission Gear Oil LV GL-4 75W” to achieve optimal performance. Your Toyota vehicle is filled with “TOYOTA Genuine Manual Transmission ● Gear Oil LV GL-4 75W” at the factory.
Page 607 9-1. Specifications Clutch Pedal free play 5 — 15 mm (0.2 — 0.6 in.) SAE J1703 or FMVSS No. 116 DOT 3 or Fluid type SAE J1704 or FMVSS No. 116 DOT 4 : Follow the indications of the designated fluid types for the brake reservoir tank Brakes ...
Page 608 9-1. Specifications Tires and wheels ● Except for Thailand and Taiwan  14-inch tires Tire size 175/65R14 82T Tire inflation pressure Front wheel Rear wheel (Recommended cold kPa (kgf/cm or bar, psi) kPa (kgf/cm or bar, psi) tire inflation pressure) 230 (2.3, 33) 210 (2.1, 30) 14 ...
Page 609 9-1. Specifications ● For Thailand 14-inch tires  Tire size 175/65R14 82T Tire inflation pressure Front wheel Rear wheel (Recommended cold kPa (kgf/cm or bar, psi) kPa (kgf/cm or bar, psi) tire inflation pressure) 230 (2.3, 33) 210 (2.1, 30) 14 ...
Page 610 9-1. Specifications ● For Taiwan 14-inch tires  Tire size 175/65R14 82H Tire inflation pressure Front wheel Rear wheel (Recommended cold kPa (kgf/cm or bar, psi) kPa (kgf/cm or bar, psi) tire inflation pressure) 220 (2.2, 32) 220 (2.2, 32) 14 ...
Page 611 9-1. Specifications Light bulbs Light Bulbs Type Headlights  Low beam  High beam Front fog lights Front position lights (bulb type) Front turn signal lights Side turn signal lights Exterior Stop/tail lights 21/5 Rear turn signal lights Back-up lights Rear fog lights License plate lights High mounted stoplight (bulb type)
Page 612 9-1. Specifications A: H11 halogen bulbs B: HB3 halogen bulbs C: H16 halogen bulbs D: Wedge base bulbs (clear) E: Wedge base bulbs (amber) F: Double end bulbs : If equipped : Vehicles without moon roof : Vehicles with moon roof VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 613: Fuel Information
9-1. Specifications Fuel information 3NR-FE, 2NR-FE and 1NR-FE engines  For Argentina: You must only use unleaded gasoline. Select unleaded gasoline with a Research Octane Number of 91 or higher for optimum engine performance. Except for Argentina: You must only use unleaded gasoline. Select unleaded gasoline with a Research Octane Number of 91 (Octane rating 87) or higher for optimum engine performance.
Page 614  3NR-FE and 3NR-FKE engine Toyota allows the use of ethanol blended gasoline where the ethanol content is up to 20%. Make sure that the ethanol blended gasoline to be used has a Research Octane Number that follows the above.
Page 615 9-1. Specifications NOTICE Notice on fuel quality ■ ● Do not use improper fuels. If improper fuels are used, the engine will be damaged. Do not use gasoline with metallic additives, for example manganese, iron ● or lead, otherwise it may cause damage on your engine or emission con- trol system.
Page 616 P. 140, 148 Customizable features Some function settings are changed simultaneously with other func- tions being customized. Contact your Toyota dealer for further details. Settings that can be changed using the meter display Settings that can be changed by your Toyota dealer Definition of symbols: O = Available, —...
Page 617 9-2. Customization Gauges, meters and drive monitor display/multi-information ■ display (P. 140, 144) Default Customized Function setting setting Thai Arabic Indonesian Language English South America Portuguese South America Spanish Units km/L L/100 km Eco Driving Indicator Light Fuel consumption 10.0 1, 2 Eco saving comparison...
Page 618 — O tion Driver’s door linked door — O unlocking function : If equipped : Setting that can be changed manually (P. 166) or at your Toyota dealer. Smart entry & start system (P. 173) ■ Default Customized Function setting setting Smart entry &...
Page 619 9-2. Customization WARNING During customization ■ As the engine needs to be running during customization, ensure that the vehicle is parked in a place with adequate ventilation. In a closed area such as a garage, exhaust gases including harmful carbon monoxide (CO) may collect and enter the vehicle.
Page 620 9-3. Initialization Items to initialize The following items must be initialized for normal system opera- tion after such cases as the battery being reconnected, or main- tenance being performed on the vehicle: Item When to initialize Reference Power window • When functioning abnormally P.
Page 621 9-3. Initialization VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 622 Index What to do if... (Troubleshooting) .....622 Alphabetical index ......627 VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 623 The doors cannot be locked, unlocked, opened or closed You lose your keys ● If you lose your keys, new genuine keys can be made by your Toyota dealer. (P. 156) ● If you lose your electronic keys, the risk of vehicle theft increases signifi- cantly.
Page 624 What to do if... (Troubleshooting) The rear door cannot be opened ● Is the child-protector lock set? The rear door cannot be opened from inside the vehicle when the lock is set. Open the rear door from outside and then unlock the child-protector lock.
Page 625 What to do if... (Troubleshooting) The engine does not start (vehicles with a smart entry & start system) ● Vehicles with a continuously variable transmission: Did you press the engine switch while firmly depressing the brake pedal? (P. 223) ● Vehicles with a manual transmission: Did you press the engine switch while firmly depressing the clutch pedal? (P.
Page 626 What to do if... (Troubleshooting) The steering wheel cannot be turned after the engine is stopped ● Vehicles without a smart entry & start system: It is locked to prevent theft of the vehicle if the key is pulled from the engine switch.
Page 627 What to do if... (Troubleshooting) An alarm is activated and the horn sounds (vehicles with an alarm) ● Did anyone inside the vehicle open a door during setting the alarm? (P. 120) Do one of the following to deactivate or stop the alarm: ●...
Page 628 Alphabetical index Alphabetical index Airbags ........39 Airbag operating conditions ..46 A/C........386, 393 Airbag precautions for Air conditioning filter....476 your child ......41 Automatic air conditioning Airbag warning light ....525 system ........ 393 Correct driving posture ... 32 Manual air conditioning Curtain shield airbag system ........
Page 629 Alphabetical index Antennas (smart entry & start system) ......173 Back-up lights Anti-lock Brake System Replacing light bulb ....504 (ABS) ........296 Wattage ........ 610 Function ........ 296 Battery ........455 Warning light ......525 Battery checking ....455 Warning message ....
Page 630 Alphabetical index Child-protectors....... 165 Cleaning ......422, 426 Care........422, 426 Aluminum wheels....422 Aluminum wheels....422 Exterior ......... 422 Exterior........422 Interior........426 Interior........426 Seat belts......427 Seat belts ......427 Clock......... 136 CD player ........322 Clutch Chains........
Page 631 Alphabetical index (Child Restraint System)... 54, 90 Daytime running light Cruise control ......275 system........256 Warning lights ....277, 525 Defogger Warning messages ....277 Rear window ....389, 396 Cup holders......411 Windshield ....389, 396 Curtain shield airbags ....39 Dimensions ......
Page 632 Alphabetical index If the warning message is displayed ......535 Eco Driving Indicator Light..134 If you have a flat tire ..538, 556 Eco-friendly driving tips..306 If you think something is Electric Power Steering wrong........520 (EPS)........296 If your vehicle becomes Function ........
Page 633 Alphabetical index Engine compartment cover ..449 Engine coolant ......453 Fire extinguisher...... 522 Capacity ........ 601 Flat tire......538, 556 Checking ....... 453 Floor mats ........30 Preparing and checking Fluid before winter....... 302 Brake ........606 Engine coolant temperature Clutch........
Page 634 Alphabetical index Front seats ....... 184 Adjustment ......184 Gas station information ..644 Cleaning........ 426 Gauges ........136 Correct driving posture.... 32 Glove box ......... 410 Head restraints...... 189 Front turn signal lights.... 247 Replacing light bulbs..... 492 Hands-free system Turn signal lever ....
Page 635 Alphabetical index Identification ......587 Jack Engine........590 Positioning a floor jack..445 Vehicle ........587 Vehicle-equipped jack... 557 Ignition switch Jack handle ......557 (engine switch) ....220, 223 Jam protection function Illuminated entry system..408 Moon roof......203 Immobilizer system ....
Page 636 Alphabetical index Language Maintenance (multi-information display) ... 148 Do-it-yourself maintenance... 440 Lever Maintenance data ....586 Auxiliary catch lever ....443 Maintenance requirements ... 429 Hood lock release lever ..443 Scheduled maintenance ..432 Shift lever ....232, 240, 243 Malfunction indicator lamp..
Page 637 Alphabetical index Odometer........136 Parking assist sensors ... 279 Toyota parking Engine oil ......594 assist-sensor ...... 279 Manual transmission oil ..604 Paddle shift switches ..234, 235 Opener Parking brake......249 Fuel filler door ....... 273 Operation ......249 Hood ........
Page 638 Alphabetical index Radiator ........454 Scheduled maintenance ..432 Radio......... 319 Seat belt reminder light... 526 Rear fog light......258 Seat belts........34 Replacing light bulbs..... 507 Child restraint system Switch ........259 installation ...... 54, 90 Wattage......... 610 Cleaning and maintaining Rear seat........
Page 639 Intrusion sensor ....123 Spark plug ........ 603 Rain-sensing Specifications ......586 windshield wipers ....269 Speedometer......136 Toyota parking Sport mode....... 234 assist-sensor ...... 279 Steering lock ....221, 229 Shift lever ....232, 240, 243 Column lock release ..221, 229 7-speed sport sequential Steering wheel ......
Page 640 Warning light......527 Stop & Start cancel switch ..288 Telephone switches ....353 Tire pressure warning reset switch......464 Toyota parking assist-sensor switch ... 280 “TRIP” switch ......140 VSC off switch....... 297 Window lock switch....199 Windshield wipers and washer switch .....
Page 641 Emergency towing ....514 Wattage ........ 610 Turn signal lights..... 247 Towing eyelet......516 Trailer towing ......219 Replacing light Toyota parking bulbs... 492, 496, 499, 503, 507 assist-sensor ......279 Turn signal lever ....247 Traction control ....... 296 Wattage ........ 610...
Page 642 Alphabetical index USB memory ......339 Warning buzzers USB port ....316, 331, 339 Brake system ......524 Driver’s and front passenger’s seat belt reminder....526 Key reminder ......221 Valet key ........152 Open door......167 Vanity lights ......415 Smart entry &...
Page 643 Alphabetical index Washer........262 Checking ....... 459 Preparing and checking before winter....... 302 Switch ........262 Washing and waxing ....422 Wheels ........474 Replacing ......556 Size ........607 Window glasses....... 198 Window lock switch....199 Windows ........198 Power windows .....
Page 644 Alphabetical index VIOS_OM_GE_OM52L06E(TMT)_OM99V20b(TDB)_OM52L61E(TMP)_0D053(IMC)
Page 645 GAS STATION INFORMATION Auxiliary catch lever Trunk opener Fuel filler door P. 443 P. 168 P. 271 Hood lock release Fuel filler door opener Tire inflation pressure lever P. 443 P. 273 P. 607  3NR-FE, 3NR-FKE, 2NR-FE and 1NR-FE engines Fuel tank capacity 42 L (11.1 gal., 9.2 Imp.gal.)

This manual is also suitable for:

Yaris sedan

Toyota VIOS Owner's Manual

1 For Safety and Security

2 Instrument Cluster

4 Driving

5 Audio System

Quick Links

Troubleshooting

Related Manuals for Toyota VIOS

Summary of Contents for Toyota VIOS

This manual is also suitable for:

Table of Contents
