- Page 2 Owner’s Manual and supplementary manuals so you will have a better understanding of your vehicle’s capabilities and limitations. Your dealership and the entire staff of Toyota Motor Sales, U.S.A., Inc. wish you many years of satisfied driving in your new Venza.
-
Page 3: Table Of Contents
EMERGENCY FEATURES Seatbelts Seatbelts-Shoulder belt anchor Spare tire & tools Tire Pressure Monitoring (warning) System 24 Visit your Toyota dealer for information on customizing this feature. Programmable by customer. Refer to the Owner’s Manual for instructions and more information. HomeLink ®... -
Page 4: Instrument Panel
OVERVIEW Instrument panel Steering wheel controls Steering wheel audio controls Telephone controls Voice command button Cruise control Engine switch (standard key) Headlight, turn signal and front fog light controls Wiper and washer controls “ENGINE START STOP” switch (Smart Key) Multi-information display Audio system Emergency flasher button Multi-information display switches... - Page 5 With navigation system Without navigation system Automatic Air Conditioning system Manual Air Conditioning system Air Conditioning controls Outside rearview mirrors /Rear window defogger button/Windshield wiper de-icer VSC/TRAC OFF switch Power back door switch Power rearview mirror controls Power back door main switch If equipped Vehicles with navigation system: for details, refer to the “Navigation System Owner’s Manual.”...
-
Page 6: Instrument Cluster
Active torque control 4WD system warning If indicator does not turn off within a few seconds of starting engine, there may be a malfunction. Have vehicle inspected by your Toyota dealer. If this light flashes, refer to “Cruise control,” Section 2-4, 2009 Owner’s Manual. - Page 7 Electric power steering system warning Low windshield washer fluid level warning Smart Key system warning Low fuel level warning Open door warning Airbag SRS warning Master warning Low Tire Pressure Warning Headlight low/high beam indicator Turn signal indicator Fog light indicator Slip indicator Cruise control indicator Anti-lock Brake System warning...
-
Page 8: Keyless Entry
OVERVIEW Keyless entry Locking operation Without Smart Key system With Smart Key system Push Unlocking operation Without Smart Key system With Smart Key system Push ONCE: Driver door TWICE: All doors NOTE: If a door is not opened within 60 seconds of unlocking, all doors will relock for safety. - Page 9 Smart Key system (if equipped) Start function Green indicator ON Depress Push brake pedal Carrying NOTE: Gear shift lever must be in Park and brake pedal depressed. Power (without starting engine) Without depressing the brake pedal, pressing the “ENGINE START STOP” switch will change the operation mode in succession from: ACCESSORY Accessories such as the radio will operate.
-
Page 10: Fuel Tank Door Release And Cap Hood Release
OVERVIEW Fuel tank door release and cap Turn Pull Store NOTE: Tighten until one click is heard. If the cap is not tightened enough, Check Engine “ ” indicator may illuminate. Hood release Pull Pull up latch and raise hood Engage support rod... -
Page 11: Light Control-Instrument Panel
Light control-Instrument panel Brightness control Engine maintenance Engine coolant reservoir Engine oil filler cap Engine oil level dipstick Windshield washer fluid tank Note: Regularly scheduled maintenance, including oil changes, will help extend the life of your vehicle and maintain performance. Please refer to the “Owner’s Warranty Information Booklet,”... -
Page 12: Automatic Transmission
FEATURES/OPERATIONS Automatic Transmission Park* Reverse Neutral Drive “D” “S” mode “S” * The “ENGINE START STOP” switch/engine switch must be “ON” and the brake pedal depressed to shift from Park. “S” (Sequential) mode Shift the shift lever to “S” position from “D” position. Floor shift type: : Upshift (push and release) : Downshift (pull and release) -
Page 13: Auto Lock Functions 1
Auto lock functions Automatic door locks can be programmed to operate in two different modes, or turned OFF. -Doors lock when shifting from Park. -Doors lock when the vehicle speed is approximately 12 mph or higher. -Doors unlock when shifting into Park. -Doors unlock when the driver’s door is opened within 10 seconds after turning the “ENGINE START STOP”... -
Page 14: Seats-Head Restraints
FEATURES/OPERATIONS Seats-Head restraints Rear center Front and rear (excluding center) seats Height Lock release button Lock release button Seats-Folding rear row seats From inside From outside Pull Pull Left side remote Right side remote seat release seat release (1) Stow the seatbelt buckles. (2) Hook the seatbelt to the seatbelt hangers. -
Page 15: Windows-Power
Windows-Power Window lock switch Down Automatic operation Push the switch completely down or pull it completely up and release to fully open or close. To stop window midway, lightly push the switch in the opposite direction. Window lock switch Deactivates all passenger windows. Driver’s window remains operable. -
Page 16: Lights & Turn Signals
FEATURES/OPERATIONS Lights & turn signals Headlights Headlights Parking lights Auto DRL OFF Without automatic high beam Low beam High beam flasher High beam -Daytime Running Light system (DRL) Automatically turns on the headlights at a reduced intensity. -Automatic light cut off system Automatically turns lights off after a delay of 30 seconds, or the lock switch on remote may be pushed after locking. -
Page 17: Windshield Wipers & Washers
Front fog lights (if equipped) Turn Front fog lights come on only when the headlights are on low beam. Turn signals Right turn Lane change Lane change Left turn Windshield wipers & washers Front Single wipe Adjust frequency* Interval wipe Slow Pull to wash Fast... -
Page 18: Seat Heaters
FEATURES/OPERATIONS Seat heaters (if equipped) Driver’s seat Front passenger’s seat Turn Air Conditioning/Heating Manual Air Conditioning Temperature selector Airflow vent In “ ” mode, use fresh air (“ ” indicator OFF) to reduce window fogging. “ ” mode uses fresh air only. Fan speed Air Conditioning ON/OFF Use fresh air to quickly cool interior, then change to recirculate for... -
Page 19: Vsc Off Button
Automatic Air Conditioning (if equipped) Push: Automatic climate control ON Adjusting the temperature setting will cause the airflow vents, air intake and fan to adjust automatically. Turn: Temperature selector (driver side) Fan speed Airflow vent In “ ” mode, use fresh air (“ ”... - Page 20 FEATURES/OPERATIONS Audio Audio Type 1 Preset buttons - functions in other modes indicated above number Push to turn ON/OFF Eject CD Load CD(s) Push to adjust tone Station/CD & balance track scan View CD text Push to skip up/down folder Seek station/ Mode and radio category type...
- Page 21 CD PLAYER To scan tracks on a disc Push and hold “SCAN.” Push again to hold selection. CD changer (Types 1 and 2 only) -To load one disc Push “LOAD” and insert one disc. -To load multiple discs Push and hold “LOAD” until you hear a beep. Insert one disc.
-
Page 22: Cruise Control
FEATURES/OPERATIONS Rear seat entertainment system (if equipped) Front audio system Display DVD player Remote controller A/V input adapter 120V AC Power outlet Cruise control Turning system ON/OFF System ON/OFF Functions Resume Increase speed Cancel Decrease speed The set speed may also be cancelled by depressing the brake pedal. The set speed may be resumed once vehicle speed exceeds 25 mph. -
Page 23: Power Outlets-12V Dc
Power outlets-12V DC Instrument panel Inside center console Luggage compartment NOTE: Designed for car accessories. Engine switch/“ENGINE START STOP” switch must be in the ACCESSORY or ON position to be used. Power outlet-120V AC (if equipped) NOTE: Engine switch/“ENGINE START STOP” switch must be in the “ON” position to be used. -
Page 24: Multi-Information Display (Clock) 2
FEATURES/OPERATIONS Multi-information display (clock) TFT type* LCD type Push “INFO” or “INFO-CLOCK” to change information in the following: (1) Average fuel economy (AVERAGE ECON) (2) Current fuel economy (CURRENT ECON) (3) Distance to empty (RANGE) (4) Average speed (AVERAGE SPEED) (5) Trip timer (TFT type only) Setting the clock TFT type* (1) Press the “SETUP”... -
Page 25: Telephone Controls (Bluetooth
Telephone controls (Bluetooth ® (if equipped) Audio unit Microphone Steering wheel telephone switches Start call End call Volume Voice command button Bluetooth technology allows dialing or receipt of calls without taking ® hands from the steering wheel or using a cable to connect the telephone and the system. -
Page 26: Seatbelts-Shoulder Belt Anchor
Correctly adjusting tire inflation will turn off the light after a few minutes. If the light does not turn off, have the system checked by your Toyota dealer. Refer to the Owner’s Manual for more details. -
Page 27: Spare Tire & Tools
Doors-Child safety locks Rear door Moving the lever to “LOCK” will allow the door to be opened only from the outside. Spare tire & tools Tool location Jack Jack handle Wheel nut wrench Removing the spare tire Loosen and remove the bolt Refer to the Owner’s Manual for tire changing and jack positioning procedures. - Page 28 MN 00505-QRG09-VEN Printed in the USA 10/08...
