ground wire from
i431-411EX
remove cap
PCIII USB EX
connector
PCIII USB EX
12 Locate the white 2-pin connector taped to the
main wiring harness.
This connector is located under the left hand
side cover.
13 Remove the tape securing this connector to
the main wiring harness and remove the cap as
shown in Figure G.
14 Attach the red wire from the PCIII USB EX
harness to the stock wiring harness as shown
in Figure H.
15 Attach the ground wire from the PCIII USB EX
to the negative side of the battery as shown in
Figure I.
2008 Yamaha Roadstar - PCIII USB EX - 4
