INSTALLATION INSTRUCTIONS
1
Installing Decorative Arms
Top Arm Ring
Set Screw
DECORATIVE ARM
OPTIONAL A
Attach the decorative arms to the top and bottom arm rings as shown.
Secure them together with the provided set screws. Hand tighten until
snug.
Loosen the stem top and remove it from the top end of the stem.
customersupport@voltlighting.com • 813.978.3700
Decorative Pieces
3601/3602 Series
Set Screw
Decorative Arm
Bottom Arm Ring
Top Arm Ring
DECORATIVE ARM
OPTIONAL B
- 1 -
Set Screw
Decorative Arm
Bottom Arm Ring
Set Screw
Advertisement
Table of Contents
Related Manuals for Volt 3602 Series
Summary of Contents for Volt 3602 Series
- Page 1 INSTALLATION INSTRUCTIONS Decorative Pieces 3601/3602 Series Installing Decorative Arms Top Arm Ring Top Arm Ring Set Screw Set Screw Decorative Arm Decorative Arm Bottom Arm Ring Set Screw Bottom Arm Ring Set Screw DECORATIVE ARM DECORATIVE ARM OPTIONAL B OPTIONAL A Attach the decorative arms to the top and bottom arm rings as shown.
- Page 2 Install Stem Top to Decorative Pieces Stem Top Stem Top Neck Top Arm Ring Neck Set Screw Set Screw Decorative Tube Decorative Arms Assembly INSTALL DECORATIVE ARM INSTALL DECORATIVE TUBE Insert the neck of the stem top to the top arm ring of the decorative arm assembly or to the decorative tube.
- Page 3 Install Decorative Pieces to Stem Stem Top Stem Top Decorative Tube Decorative Arms Assembly Stem Stem INSTALL STEM TO INSTALL STEM TO DECORATIVE ARMS ASSEMBLY DECORATIVE TUBE Place the stem top with decorative arms assembly or the stem top with the decorative tube over the bulb.
- Page 4 . v o l t l i g h t i n g . c o m Specifications and product details subject to change without notice. © Copyright 2019, VOLT Lighting, Lutz FL USA 33549 • All rights reserved.
