When a PPPoE session works in permanent on-line mode, if it is terminated by the
reset pppoe-client command, the firewall will automatically recreate a PPPoE session
in 16 seconds. When a PPPoE session works in packet triggering mode, if it is
terminated via the reset pppoe-client command, the firewall will recreate a PPPoE
session only upon data transmission.
No matter a PPPoE session works in permanent on-line mode or in packet triggering
mode, it will be deleted permanently by the undo pppoe-client command. If it is
necessary to recreate a PPPoE session, the user must reconfigure it.

3.3 Displaying and Debugging the PPPoE Client

Execute the display command in all views and the debugging command in user view.
Table 3-5 Displaying and Debugging the PPPoE client
Display the status and statistics of a
PPPoE session
Enable the PPPoE client debugging

3.4 Typical PPPoE Client Configuration Example

3.4.1 Typical PPPoE Client Configuration Example
I. Network requirements
SecPath1 and SecPath2 are connected using interface Ethernet1/0/0. SecPath1
authenticates SecPath2 using PAP or CHAP.
II. Network diagram
SecPath1
Figure 3-2 Network diagram for PPPoE client
III. Configuration procedure
When PAP authentication applies, configure the firewalls as follows:
1) Configure SecPath1
Operation
e1/0/0
Chapter 3 PPPoE Client Configuration
display pppoe-client session
{ summary | packet }
[ dial-bundle-number number ]
debugging pppoe-client { all | data |
error | event | packet | verbose }
[ interface type number ]
e1/0/0
SecPath2
3-5
